Square green circuit board with gold contacts and silver metal heat spreader marked Intel Core i5-12400

Intel

Intel Core i5-12400 BX8071512400 desktop processor

SKU CH-H624-2WD0C MPN BX8071512400

A 6-core, 12-thread desktop processor with a 2.5 GHz base clock, 4.4 GHz max turbo, 18 MB L3 cache, Intel UHD Graphics 730, and support for DDR4 3200 or DDR5 4800 memory

  • Processors TypeDesktop
  • NameCore i5-12400
  • CPU Socket TypeLGA 1700
  • Core NameAlder Lake
  • # of Cores6-Core
  • # of Threads12-Threads
  • 6 cores and 12 threads handle multitasking smoothly
  • Boost up to 4.4 GHz for responsive single-thread speed
  • 18 MB L3 cache keeps data close for fast access
  • Supports DDR4 3200 and DDR5 4800 memory for flexible builds
  • Intel UHD Graphics 730 provides video output without a discrete card

LGA 1700 desktop processor

The Intel Core i5-12400 is a 6-core, 12-thread desktop CPU built on the Alder Lake architecture using Intel 7 process technology. It operates at a 2.5 GHz base frequency and can reach a 4.4 GHz maximum turbo frequency. The processor includes Intel UHD Graphics 730 and supports both DDR4 3200 and DDR5 4800 memory in dual-channel mode. Total cache comprises 7.5 MB L2 and 18 MB L3.

Suitability and alternatives

This CPU suits builders targeting a 65 W base power platform with PCIe 5.0 support for graphics and storage. It provides 16 CPU PCIe 5.0 lanes and 4 CPU PCIe 4.0 lanes for modern expansion. Systems requiring more than 6 cores or higher sustained multi-thread throughput should consider a higher-tier model. A discrete graphics card is recommended for demanding 3D workloads.

Deciding specification

The LGA 1700 socket defines motherboard compatibility and cannot be changed later. This processor will not install in boards with a different socket. Maximum memory capacity is 128 GB with a peak bandwidth of 76.8 GB/s. Processor base power is 65 W and maximum turbo power is 117 W.

Highlights

  • 6 cores and 12 threads handle multitasking smoothly
  • Boost up to 4.4 GHz for responsive single-thread speed
  • 18 MB L3 cache keeps data close for fast access
  • Supports DDR4 3200 and DDR5 4800 memory for flexible builds
  • Intel UHD Graphics 730 provides video output without a discrete card

Specifications

BrandIntel
Processors TypeDesktop
SeriesCore i5 12th Gen
NameCore i5-12400
ModelBX8071512400
CPU Socket TypeLGA 1700
Core NameAlder Lake
# of Cores6-Core
# of Threads12-Threads
Operating Frequency2.5 GHz
Max Turbo Frequency4.4 GHz
L2 Cache7.5MB
L3 Cache18MB
Manufacturing TechIntel 7
Instruction Set64-Bit
Hyper-Threading SupportYes
Memory TypesDDR4 3200 / DDR5 4800
Memory Channel2
Max Memory Size128 GB
Max Memory Bandwidth76.8 GB/s
Virtualization Technology SupportYes
Integrated GraphicsIntel UHD Graphics 730
PCI Express Revision5.0 / 4.0 / 3.0
Max Number of PCI Express LanesCPU PCIe 5.0 Lanes: 16
CPU PCIe 4.0 Lanes: 4
Thermal Design PowerProcessor Base Power: 65W
Maximum Turbo Power: 117W
Cooling DeviceCooling device not included - Processor Only
Operating System SupportedWindows 11
Shipping weight0.48 kg
Package size116 × 101 × 44 mm
