Intel
Intel Core Ultra 5 225 BX80768225 desktop processor
A 10-core Arrow Lake desktop CPU with six performance cores at 3.3 GHz, four efficient cores at 2.7 GHz, 20 MB L3 cache, 22 MB L2 cache, integrated Intel Graphics up to 1.8 GHz.
- Processors TypeDesktop
- NameCore Ultra 5 225
- CPU Socket TypeLGA 1851
- Core NameArrow Lake
- # of Cores10-Core (6P+4E)
- # of Threads10-Threads
- 10 cores at 3.3 GHz base handle heavy workloads
- 65 W power draw keeps thermals manageable
- 22 MB L2 plus 20 MB L3 cache speeds data access
- Intel Graphics runs up to 1.8 GHz for light media tasks
- DDR5 6400 MT/s support enables fast memory bandwidth
Core Ultra 5 225 desktop processor
The Intel Core Ultra 5 225 is a 10-core desktop CPU built on the Arrow Lake architecture. It combines six performance cores and four efficient cores for a total of 10 threads. Base clocks sit at 3.3 GHz for P-cores and 2.7 GHz for E-cores, with maximum turbo reaching 4.9 GHz and 4.4 GHz respectively. It targets builders who want modern 3 nm process technology in a 65 W package.
LGA 1851 platform with DDR5 support
The processor drops into the new LGA 1851 socket, so a compatible motherboard and DDR5 memory kit are required. The dual-channel controller officially supports up to 6400 MT/s and a maximum capacity of 256 GB. Integrated Intel Graphics run at a 300 MHz base and can boost to 1.8 GHz, providing a display output without a discrete card and freeing a PCIe slot for other add-in boards.
Sustained 65 W operation with large cache
With a 65 W base power rating, the chip is designed to maintain its performance cores near rated frequencies during extended workloads rather than only in short bursts. The 22 MB L2 and 20 MB L3 caches keep frequently used data close to the cores, reducing memory latency when the processor runs flat out for long periods. This combination of moderate power and generous cache helps deliver consistent throughput for rendering, compilation or multi-tasking sessions that last hours.
Highlights
- 10 cores at 3.3 GHz base handle heavy workloads
- 65 W power draw keeps thermals manageable
- 22 MB L2 plus 20 MB L3 cache speeds data access
- Intel Graphics runs up to 1.8 GHz for light media tasks
- DDR5 6400 MT/s support enables fast memory bandwidth
Specifications
| Brand | Intel |
|---|---|
| Processors Type | Desktop |
| Series | Core Ultra 5 (Series 2) |
| Name | Core Ultra 5 225 |
| Model | BX80768225 |
| CPU Socket Type | LGA 1851 |
| Core Name | Arrow Lake |
| # of Cores | 10-Core (6P+4E) |
| # of Threads | 10-Threads |
| Operating Frequency | Performance-core Base Frequency: 3.3 GHz Efficient-core Base Frequency: 2.7 GHz |
| Max Turbo Frequency | Max Turbo Frequency: 4.9 GHz P-core Max Turbo Frequency: Up to 4.9 GHz E-core Max Turbo Frequency: Up to 4.4 GHz |
| L2 Cache | 22MB |
| L3 Cache | 20MB |
| Manufacturing Tech | 3nm (TSMC N3B) |
| Memory Types | Up to DDR5 6400 MT/s |
| Memory Channel | 2 |
| Max Memory Size | 256 GB |
| Integrated Graphics | Intel Graphics |
| Graphics Base Frequency | 300 MHz |
| Graphics Max Dynamic Frequency | 1.8 GHz |
| Scalability | 1S Only |
| PCI Express Revision | 5.0 / 4.0 |
| PCI Express Configurations | Up to 1x16+2x4, 2x8+2x4, 1x8+4x4 |
| Max Number of PCI Express Lanes | 24 |
| Thermal Design Power | 65W |
| Max Turbo Power | 121W |
| Cooling Device | Intel Laminar RM2 |
| Compatible Desktop Chipsets | Intel 800 Series Chipset |
| Advanced Technologies | Intel Gaussian & Neural Accelerator: 3.5 Intel Thread Director: Yes Intel Speed Shift Technology: Yes Intel Turbo Boost Technology: 2.0 Intel Hyper-Threading Technology: No Intel 64: Yes Instruction Set: 64-bit Instruction Set Extensions: Intel SSE4.1, Intel SSE4.2, Intel AVX2 Idle States: Yes Enhanced Intel SpeedStep Technology: Yes Thermal Monitoring Technologies: Yes Intel Volume Management Device (VMD): Yes |
| Security & Reliability | Intel Threat Detection Technology (TDT): Yes Intel Active Management Technology (AMT): No Intel Standard Manageability (ISM): Yes Intel Remote Platform Erase (RPE): No Intel One-Click Recovery: No Intel Secure Key: Yes Intel Control-Flow Enforcement Technology: Yes Intel Total Memory Encryption - Multi Key: No Intel AES New Instructions: Yes Intel Trusted Execution Technology: Yes Execute Disable Bit: Yes Intel OS Guard: Yes Intel Boot Guard: Yes Mode-based Execute Control (MBEC): Yes Intel Stable IT Platform Program (SIPP): No Intel Virtualization Technology with Redirect Protection |
| Shipping weight | 0.45 kg |
| Package size | 127 × 108 × 76 mm |
Questions about this item
Does the 65 W base power hold steady during long renders?
The processor is rated at 65 W base power. Sustained workloads can push consumption above that figure depending on motherboard power limits and cooling capacity.
How loud or hot does the chip get when running all day?
Thermal output scales with the 65 W base rating and any higher PL2 setting the board applies. Acoustic results depend entirely on the cooler you install and the fan curves you configure.
What memory must already be in the system for this CPU to post?
The memory controller supports DDR5 up to 6400 MT/s in dual-channel mode with a maximum capacity of 256 GB.
