Silver 2.5 inch U.2 SSD with Intel Optane label

Intel

Intel Optane D4800X 1.5TB NVMe U.2 2.5" internal SSD

SKU CH-5VWR-TVXH0

A 1.5 TB U.2 internal SSD delivering up to 2400 MBps sequential read and 550,000 IOPS random read for data-intensive workloads

  • Device TypeInternal Solid State Drive (SSD)
  • Form Factor2.5" U.2
  • Capacity1.5TB
  • InterfacePCI-Express 4.0 x4
  • Max Sequential ReadUp to 2400 MBps
  • Max Sequential WriteUp to 2300 MBps
  • High random read speed backed by 550000 IOPS
  • Fast sequential reads up to 2400 MBps
  • Strong random write performance at 520000 IOPS
  • High sequential write throughput up to 2300 MBps
  • Enterprise reliability with 2000000 hours MTBF

Intel Optane D4800X 1.5TB U.2 SSD

This Intel Optane D4800X is a 1.5TB internal solid-state drive built for enterprise workloads. It uses a 2.5 inch U.2 form factor and connects via PCI-Express 4.0 x4. The drive targets data-intensive applications requiring high random access performance.

PCI-Express 4.0 x4 interface limits

The drive operates on a PCI-Express 4.0 x4 interface, which sets the maximum throughput ceiling for sequential transfers. Sequential reads reach up to 2400 MBps while sequential writes reach up to 2300 MBps. Random 4KB reads hit up to 550,000 IOPS and random 4KB writes up to 520,000 IOPS. Active power draw is rated at 25W.

1.5TB capacity decides fit

The single specification that determines suitability is the 1.5TB capacity. It must match the storage space required for the target dataset or application. The drive also carries a 2,000,000 hour MTBF rating for endurance assurance.

Highlights

  • High random read speed backed by 550000 IOPS
  • Fast sequential reads up to 2400 MBps
  • Strong random write performance at 520000 IOPS
  • High sequential write throughput up to 2300 MBps
  • Enterprise reliability with 2000000 hours MTBF

Specifications

BrandIntel
Part NumberSSDPD21K015TAR
Device TypeInternal Solid State Drive (SSD)
Form Factor2.5" U.2
Capacity1.5TB
InterfacePCI-Express 4.0 x4
Max Sequential ReadUp to 2400 MBps
Max Sequential WriteUp to 2300 MBps
4KB Random ReadUp to 550,000 IOPS
4KB Random WriteUp to 520,000 IOPS
MTBF2,000,000 hours
Power Consumption (Active)25W

Questions about this item

What capacity should I choose for the Optane D4800X?

The drive is offered in a single 1.5TB capacity, so there is no alternative size to select for this model.

What does the 2400 MBps sequential read mean in a real system?

It represents the peak throughput the controller can deliver over a PCIe 4.0 x4 link; actual speed depends on workload, queue depth and platform cooling.

Which interface standard does the U.2 drive use and what does it limit?

The drive uses a PCIe 4.0 x4 NVMe connection, capping maximum bandwidth to the electrical limits of that generation and lane count.
