Silver 2.5 inch U.2 enterprise SSD with 15mm height

Intel

Intel Optane DC P5800X 400GB 2.5" U.2 PCIe 4.0 x4 NVMe enterprise SSD SSDPF21Q400GB01

SKU CH-RFRF-ZZRBA MPN SSDPF21Q400GB01

400 GB U.2 enterprise SSD with 3D XPoint media, PCIe 4.0 x4 NVMe, 7200 MB/s read, 4800 MB/s write, 100 DWPD endurance and AES 256-bit encryption

  • Form Factor2.5" U.2
  • Memory Components3D XPoint
  • InterfacePCI-Express 4.0 x4, NVMe
  • Max Sequential ReadUp to 7200 MBps
  • Max Sequential WriteUp to 4800 MBps
  • MTBF2,000,000 hours
  • Optane 3D XPoint media accelerates write-heavy workloads
  • PCIe 4.0 x4 NVMe interface delivers 7200 MBps sequential read
  • 100 DWPD endurance rating supports 73000 TBW lifetime writes
  • AES 256-bit hardware encryption with enhanced power-loss protection
  • 5" U.2 15mm form factor fits dense server bays

Enterprise write-tiering drive

The Intel Optane DC P5800X 400GB 2.5" U.2 drive targets data-centre caching and hot-data tiering. Its 3D XPoint media delivers consistent low latency for write-intensive workloads. The 15mm z-height fits standard U.2 bays in rack servers. It is not for bulk-capacity storage tiers where cost per gigabyte dominates.

PCIe 4.0 x4 throughput ceiling

The PCIe 4.0 x4 link caps sequential reads at 7200 MBps and writes at 4800 MBps. Active power draw reaches 14W, so chassis airflow must handle the thermal load. The interface does not scale beyond four lanes, limiting peak bandwidth in multi-drive arrays. Builders needing higher single-stream throughput cannot meet it with this interface generation.

100 DWPD endurance rating

A 100 drive-writes-per-day rating over five years yields 73,000 TBW total endurance. This single figure determines whether the drive survives sustained write caching or logging workloads. Lower-endurance alternatives will wear out prematurely under the same duty cycle. AES 256-bit encryption and end-to-end data protection are included.

Highlights

  • Optane 3D XPoint media accelerates write-heavy workloads
  • PCIe 4.0 x4 NVMe interface delivers 7200 MBps sequential read
  • 100 DWPD endurance rating supports 73000 TBW lifetime writes
  • AES 256-bit hardware encryption with enhanced power-loss protection
  • 5" U.2 15mm form factor fits dense server bays

Specifications

BrandIntel
SeriesOptane SSD DC P5800X
ModelSSDPF21Q400GB01
Form Factor2.5" U.2
Memory Components3D XPoint
InterfacePCI-Express 4.0 x4, NVMe
Max Sequential ReadUp to 7200 MBps
Max Sequential WriteUp to 4800 MBps
MTBF2,000,000 hours
FeaturesEndurance Rating (Lifetime Writes): 100 DWPD
Enhanced Power Loss Data Protection: Yes
Hardware Encryption: AES 256 bit
High Endurance Technology (HET): Yes
Temperature Monitoring and Logging: Yes
End-to-End Data Protection: Yes
Power Consumption (Idle)3.8W
Power Consumption (Active)14W
Operating Temperature0°C ~ +70°C
Max Shock Resistance1,000 G, 0.5 ms, half sine
Max Vibration ResistanceOperating: 2.17 Grms, (5-700 Hz), random
Non-Operating: 3.13 Grms (5-800 Hz), random
Height15.00mm
Weight140.00g
Shipping weight0.18 kg
Package size137 × 108 × 15 mm

Questions about this item

Should I pick the 400 GB U.2 model or a different capacity for my write-heavy workload?

The 400 GB U.2 model delivers 100 DWPD and 73,000 TBW, making it suitable for write-intensive applications that need consistent endurance.

What does the 7,200 MB/s sequential read figure mean once the drive is installed in a server?

That peak read speed is reached over the PCIe 4.0 x4 link when the controller can sustain large-block transfers; real-world throughput depends on queue depth, CPU overhead and thermal limits.

How does the PCIe 4.0 x4 NVMe interface cap performance in practice?

The x4 lane width limits maximum theoretical bandwidth to roughly 8 GB/s, so the drive’s 7,200 MB/s read and 4,800 MB/s write ratings operate within that ceiling.
