A silver rectangular server CPU with gold contact pads and a green substrate, Intel Xeon Platinum 8468H model

Intel

Intel PK8071305075701 Xeon Platinum 8468H 48-core 2.1 GHz server processor

SKU CH-WAVM-67M8J MPN PK8071305075701

48-core server processor with 96 threads, 105 MB L3 cache, DDR5-4800 support up to 4 TB, 80 PCIe 5.0 lanes, and 330 W TDP

  • NameXeon Platinum 8468H
  • CPU Socket TypeLGA 4677
  • Core NameSapphire Rapids
  • # of Cores48-Core
  • # of Threads96
  • Operating Frequency2.1 GHz
  • 48 cores and 96 threads handle heavy parallel workloads
  • 8 GHz max turbo frequency accelerates single-thread performance
  • 105 MB L3 cache keeps large data sets close to the cores
  • Eight-channel DDR5 controller scales memory bandwidth to 4 TB
  • PCI Express 5.0 with 80 lanes connects high-speed accelerators and storage

48-core Xeon Platinum 8468H for dense servers

The Intel Xeon Platinum 8468H is a 48-core, 96-thread server processor with a 2.1 GHz base clock and 3.8 GHz maximum turbo frequency. It targets high-density compute clusters, virtualization hosts and memory-intensive databases that can exploit 105 MB of L3 cache and eight DDR5 channels.

Check LGA 4677 socket and 330 W cooling

Verify that your motherboard uses the LGA 4677 socket and that its power-delivery subsystem is rated for a 330 W thermal design power. The processor supports DDR5 at up to 4800 MT/s with one DIMM per channel or 4400 MT/s with two DIMMs per channel across eight memory channels, so plan DIMM population accordingly.

10 nm Sapphire Rapids die, no cooler included

The chip is built on Intel's 10 nm Sapphire Rapids process and exposes 80 PCI Express 5.0 lanes for high-bandwidth I/O. A cooling solution is not supplied; you must source a heatsink or liquid block qualified for the 330 W envelope and the LGA 4677 mounting pattern.

Highlights

  • 48 cores and 96 threads handle heavy parallel workloads
  • 8 GHz max turbo frequency accelerates single-thread performance
  • 105 MB L3 cache keeps large data sets close to the cores
  • Eight-channel DDR5 controller scales memory bandwidth to 4 TB
  • PCI Express 5.0 with 80 lanes connects high-speed accelerators and storage

Specifications

BrandIntel
SeriesIntel Xeon Platinum
NameXeon Platinum 8468H
ModelPK8071305075701
CPU Socket TypeLGA 4677
Core NameSapphire Rapids
# of Cores48-Core
# of Threads96
Operating Frequency2.1 GHz
Max Turbo Frequency3.8 GHz
L3 Cache105MB
64-Bit SupportYes
Hyper-Threading SupportYes
Manufacturing Tech10 nm
Integrated Memory Controller SpeedUp to DDR5 4800 MT/s 1DPC
Up to DDR5 4400 MT/s 2DPC
Maximum Memory Capacity4TB
Memory Channel8 Channel
Virtualization Technology SupportYes
ScalabilityS8S
PCI Express Revision5.0
Max # of PCI Express Lanes80
Thermal Design Power330W
Cooling DeviceCooling device not included - Processor Only
Shipping weight0.23 kg
Package size127 × 102 × 25 mm

Questions about this item

What comes in the box with the Xeon Platinum 8468H, and is a cooler included?

The processor is supplied without a cooling device; only the CPU itself is included.

Which memory speed should I choose for the Xeon Platinum 8468H — 4800 MT/s or 4400 MT/s DDR5?

The integrated controller runs DDR5 at up to 4800 MT/s with one DIMM per channel and up to 4400 MT/s with two DIMMs per channel across eight channels.

What does the 330 W thermal design power mean for my server build?

The 330 W rating indicates the cooling solution must dissipate that heat level under sustained full-load operation.
