Compact silver square mini PC barebone with front ports

Intel

Intel RNUC12WSKi70000 barebone mini PC i7-1260P DDR4 64GB Wi-Fi 6E Bluetooth 5.2

SKU CH-E8C2-RSDBZ MPN RNUC12WSKi70000

Barebone mini PC with a 12th Gen Core i7-1260P, dual DDR4-3200 SO-DIMM slots for up to 64GB, one M.2 slot for NVMe or SATA SSD.

  • CPU Type12th Gen Intel® Core™ i7-1260P 4P+8E/16T / P-Cores: up to 4.
  • Memory installedNo Memory
  • Memory slotDual DDR4-3200 SODIMMs, 1.2V, up to 64GB
  • Memory Type SupportedDDR4 3200
  • Max Memory Supported64GB
  • Dual Channel Memory SupportedYes
  • 12th Gen Core i7-1260P with 4P+8E cores up to 4.7 GHz
  • Iris Xe graphics drives four 4K displays via dual HDMI 2.0b and Thunderbolt 4
  • Dual-channel DDR4-3200 SO-DIMM slots support up to 64 GB
  • M.2 22x80 socket takes PCIe Gen 4 NVMe or SATA SSD
  • Intel Wi-Fi 6E AX211 and Bluetooth 5.2 with 2.5 Gb LAN

Intel NUC 12 Pro i7-1260P barebone

The Intel NUC 12 Pro Wall Street Canyon kit delivers a 12th Gen Core i7-1260P processor with four performance cores and eight efficient cores in a slim chassis. It targets professionals and enthusiasts building a compact workstation or multi-display signage player. Buyers who need discrete graphics or more than two M.2 slots should look elsewhere. No memory or storage is included.

Installation and common pitfalls

The barebone accepts dual DDR4-3200 SO-DIMMs up to 64 GB total and a single M.2 22x80 drive supporting PCIe Gen 4 NVMe or SATA. Install memory first, then the drive, before closing the case. A frequent issue is inserting a 2230 or 2242 module that does not reach the screw standoff. The power cord is not included, so source a compatible C5 lead separately.

Capacity, headroom and limits

Dual-channel DDR4-3200 scales to 64 GB, giving ample headroom for virtual machines and heavy multitasking. The M.2 socket handles NVMe drives from 128 GB to 8 TB or SATA SSDs to 2 TB. Iris Xe graphics drives four 4K displays via two HDMI 2.0b and two Thunderbolt 4 ports, or a single 8K panel. The 35 W TDP constrains sustained all-core loads in the slim thermal envelope.

Highlights

  • 12th Gen Core i7-1260P with 4P+8E cores up to 4.7 GHz
  • Iris Xe graphics drives four 4K displays via dual HDMI 2.0b and Thunderbolt 4
  • Dual-channel DDR4-3200 SO-DIMM slots support up to 64 GB
  • M.2 22x80 socket takes PCIe Gen 4 NVMe or SATA SSD
  • Intel Wi-Fi 6E AX211 and Bluetooth 5.2 with 2.5 Gb LAN

Specifications

BrandIntel
SeriesIntel NUC 12 Pro Wall Street Canyon i7 slim
ModelRNUC12WSKi70000
Part NumberRNUC12WSKi70000
CPU Type12th Gen Intel® Core™ i7-1260P 4P+8E/16T / P-Cores: up to 4.7GHz - E-Cores: up to 3.4GHz / 18MB Intel® Smart Cache / 35W TDP
Memory installedNo Memory
Memory slotDual DDR4-3200 SODIMMs, 1.2V, up to 64GB
Memory Type SupportedDDR4 3200
Max Memory Supported64GB
Dual Channel Memory SupportedYes
M.2 Slot1x M.2 22x80 socket supporting PCIe x4 Gen 4 NVMe from 128GB to 8TB or SATA SSD from 128GB to 2TB
Integrated GraphicsIntel® Iris® Xe Graphics / 4x 4K displays supported via 2x HDMI 2.0b + 2x Thunderbolt 4 Ports / 1x 8K display supported
Channel7.1 multichannel digital audio via HDMI & Thunderbolt
LAN1x Intel® 2.5Gb LAN (i225-V)
Wireless LANIntel Wi-Fi 6E AX211, 802.11ax
BluetoothBluetooth 5.2
Front USB2x Front USB 3.2 Gen2 type-A
Front Audio Ports3.5mm front stereo headset jack
HDMI2x HDMI 2.0b
Thunderbolt 32x Thunderbolt 4 (Alt-DP)
Rear USB1x Rear USB 3.2 Gen2 type-A
1x Rear USB 2.0 type-A
Input12-20VDC variable DC input
Power Supply120W 19V PSU supplied
Dimensions117x112x37mm
FeaturesKensington lock support
VESA mount kit support
Expansion 2XUSB 2.0 headers
Customization
Primary storage up to 8TB Gen4 NVMe or 2TB SATA SSD
Secondary storage up to 512GB Gen3 PCIe or 512GB SATA
Memory up to 64GB
Replaceable lid for I/O expansion
Shipping weight1.47 kg
Package size192 × 173 × 102 mm

Questions about this item

How do I confirm the i7-1260P is running correctly after installing DDR4-3200 SO-DIMMs and an M.2 drive?

Enter the BIOS to verify the CPU shows 12 cores and 16 threads, memory runs at 3200 MT/s in dual-channel mode, and the M.2 device appears on the PCIe Gen 4 x4 interface.

Which components are included and which must be purchased separately for the RNUC12WSKi70000?

The kit includes the barebone chassis, motherboard with soldered i7-1260P, dual DDR4-3200 SO-DIMM slots, one M.2 2280 slot, 2.5Gb LAN, Wi-Fi 6E AX211, Bluetooth 5.2, two HDMI 2.0b, two Thunderbolt 4 ports, and front USB 3.2 Gen 2 Type-A. You must buy DDR4-3200 SO-DIMMs up to 64 GB and an M.2 NVMe or SATA SSD.

Which DDR4 capacity should I choose for the dual-channel sockets?

Install a matched pair of DDR4-3200 1.2 V SO-DIMMs; the board supports up to 64 GB total, so two 32 GB modules give the maximum dual-channel capacity.
