Square green ceramic processor with gold contact pads and silver metal heat spreader, Intel Xeon Gold 5220 marking visible

Intel

Intel Xeon Gold 5220 server processor 18-core 2.2 GHz BX806955220

SKU CH-783Y-1ZY9S MPN BX806955220

An 18-core Xeon server processor with 36 threads, 2.2 GHz base frequency, 3.9 GHz turbo, 24.75 MB L3 cache and 125 W TDP for LGA 3647 platforms

  • NameXeon Gold 5220
  • CPU Socket TypeLGA 3647
  • # of Cores18-Core
  • # of Threads36
  • Operating Frequency2.2 GHz
  • Max Turbo Frequency3.9 GHz
  • 18 cores and 36 threads handle parallel workloads efficiently
  • 2 GHz base with 3.9 GHz turbo adapts to variable demand
  • 75 MB L3 cache keeps frequent data close
  • 6 memory channels at 2667 MHz feed data-hungry cores
  • 48 PCIe 3.0 lanes connect high-speed storage and networking

Intel Xeon Gold 5220 18-Core Server Processor

The Intel Xeon Gold 5220 is an 18-core server processor with a 2.2 GHz base frequency and 3.9 GHz max turbo frequency. It supports 36 threads through Hyper-Threading technology and includes 24.75 MB of L3 cache. Built on 14 nm process technology, it has a 125 W thermal design power and is designed for multi-socket server deployments.

LGA 3647 Socket with 48 PCIe 3.0 Lanes

This CPU fits the LGA 3647 socket and provides 48 lanes of PCI Express 3.0 connectivity for high-speed I/O expansion. The integrated memory controller runs six channels at 2667 MHz, freeing board space by eliminating the need for external memory buffers. A compatible server chassis and cooling solution rated for the 125 W TDP are required for installation.

Intel Virtualization Technology Enabled

Intel Virtualization Technology is supported in hardware, allowing multiple isolated workloads to run on the same physical cores without additional software licensing. The 64-bit instruction set and 14 nm manufacturing enable dense compute clusters for cloud and enterprise applications. Workloads requiring accelerator cards or specialised instruction sets not listed here are not addressed by this processor.

Highlights

  • 18 cores and 36 threads handle parallel workloads efficiently
  • 2 GHz base with 3.9 GHz turbo adapts to variable demand
  • 75 MB L3 cache keeps frequent data close
  • 6 memory channels at 2667 MHz feed data-hungry cores
  • 48 PCIe 3.0 lanes connect high-speed storage and networking

Specifications

BrandIntel
SeriesIntel Xeon Gold
NameXeon Gold 5220
ModelBX806955220
CPU Socket TypeLGA 3647
# of Cores18-Core
# of Threads36
Operating Frequency2.2 GHz
Max Turbo Frequency3.9 GHz
L3 Cache24.75MB
Manufacturing Tech14 nm
64-Bit SupportYes
Hyper-Threading SupportYes
Integrated Memory Controller Speed2667 MHz
Memory Channel6 Channel
Virtualization Technology SupportYes
PCI Express Revision3.0
Max # of PCI Express Lanes48
Thermal Design Power125W
Shipping weight0.45 kg
Package size137 × 114 × 43 mm

Questions about this item

What limits sustained performance under heavy load?

The 125 W thermal design power and 87 °C thermal specification define the sustained power and temperature ceiling.

How much heat and noise should I expect when the processor runs all day?

A 125 W TDP means the cooler must dissipate that heat continuously; fan noise depends on the cooling solution chosen.

Which socket and memory controller does the CPU need to operate?

It requires an LGA 3647 socket and uses a six-channel integrated memory controller rated for 2667 MHz.
