Silver rectangular processor with gold contacts and green substrate visible

Intel

Intel Xeon Gold 6530 PK8072205512500 32-core desktop processor

SKU CH-XCXZ-2DEQ6 MPN PK8072205512500

32-core Xeon desktop processor with 160 MB L3 cache, 2.1 GHz base clock, 4 GHz max turbo and DDR5-4800 support in an LGA 4677 socket

  • Processors TypeDesktop
  • NameXeon Gold 6530
  • CPU Socket TypeLGA 4677
  • Core NameEmerald Rapids
  • # of Cores32-Core
  • # of Threads64-Threads
  • 32 cores handle heavy multi-threaded workloads efficiently
  • 64 threads enable simultaneous execution of many tasks
  • 160 MB L3 cache reduces latency for large data sets
  • 4 GHz max turbo frequency boosts single-thread speed
  • DDR5 4800 support across 8 channels delivers high memory bandwidth

Processor for multi-threaded workloads

The Intel Xeon Gold 6530 is a 32-core desktop processor built for heavy parallel work. It targets servers and workstations that run virtualisation, rendering or large-scale data jobs. Sixty-four threads give each core a logical pair for sustained throughput. The LGA 4677 socket fits compatible server-class platforms.

Capacity and headroom

Sixteen gigabytes of L3 cache and eight memory channels feed the cores at 4800 MHz. DDR5 4800 support scales to 4 TB with ECC for data integrity. Base frequency sits at 2.1 GHz and turbo reaches 4 GHz when thermal budget allows. The 270 W TDP marks the limit where sustained clocks throttle under full load.

Socket LGA 4677 compatibility

The LGA 4677 socket is the single specification that decides fit. Only motherboards wired for this socket and the matching chipset will power the processor. Verify platform qualification before purchase because no other socket accepts this package.

Highlights

  • 32 cores handle heavy multi-threaded workloads efficiently
  • 64 threads enable simultaneous execution of many tasks
  • 160 MB L3 cache reduces latency for large data sets
  • 4 GHz max turbo frequency boosts single-thread speed
  • DDR5 4800 support across 8 channels delivers high memory bandwidth

Specifications

BrandIntel
Processors TypeDesktop
SeriesXeon
NameXeon Gold 6530
ModelPK8072205512500
CPU Socket TypeLGA 4677
Core NameEmerald Rapids
# of Cores32-Core
# of Threads64-Threads
Operating Frequency2.1 GHz
Max Turbo Frequency4 GHz
L3 Cache160MB
Manufacturing Tech10nm
Instruction Set64-Bit
Integrated Memory Controller Speed4800 MHz
Memory TypesDDR5 4800
Memory Channel8
Max Memory Size4TB
ECC MemorySupported
Virtualization Technology SupportYes
PCI Express Revision5.0
Max Number of PCI Express Lanes80
Thermal Design Power270W
Cooling DeviceCooling device not included - Processor Only
Advanced TechnologiesIntel On Demand Activation Model: No
Intel Data Streaming Accelerator (DSA): 1 default devices
Intel Advanced Matrix Extensions (AMX): Yes
Intel Speed Select Technology - Core Power: Yes
Intel Speed Select Technology - Turbo Frequency: Yes
Intel Deep Learning Boost (Intel DL Boost) on CPU: Yes
Intel Speed Select Technology - Base Frequency: Yes
High Priority Cores: 12
High Priority Core Frequency: 2.3 GHz
Low Priority Cores: 20
Low Priority Core Frequency: 1.9 GHz
Intel Resource Director Technology (Intel RDT): Yes
Intel Speed Shift Technology: Yes
Intel Turbo Boost Technology: 2.0
I
Security & ReliabilityIntel Trust Domain Extensions (Intel TDX): Yes
Intel Crypto Acceleration: Yes
Intel QuickAssist Software Acceleration: Yes
Intel Platform Firmware Resilience Support: Yes
Intel Control-Flow Enforcement Technology: Yes
Intel Total Memory Encryption - Multi Key: Yes
Intel Total Memory Encryption: Yes
Intel AES New Instructions: Yes
Intel Software Guard Extensions (Intel SGX): Yes with Intel SPS
Default Maximum Enclave Page Cache (EPC) Size for Intel SGX: 128 GB
Intel OS Guard: Yes
Intel Trusted Execution Technology: Yes
Execute Disable Bit: Yes
Intel Boot Guard: Yes
Intel Run Sure Tech
Shipping weight0.45 kg
Package size191 × 152 × 84 mm

Questions about this item

Will this Xeon Gold 6530 fit into my existing LGA 4677 motherboard without a BIOS update?

The processor uses the LGA 4677 socket. Motherboard manufacturers release specific BIOS revisions for Emerald Rapids CPUs; check the vendor support page for the exact version required before installation.

How can I verify the 32 cores and 64 threads are active after installing the PK8072205512500?

Open Task Manager or run lscpu on Linux. Both will show 32 cores and 64 threads running at the 2.1 GHz base frequency, confirming the processor is recognised correctly.

Does the box contain a heatsink or only the CPU itself?

The tray package includes the Xeon Gold 6530 processor only. A compatible LGA 4677 cooler rated for 270 W TDP and DDR5 4800 memory modules must be purchased separately.
