Silver rectangular server CPU with gold contact pads and green substrate

Intel

Intel Xeon Silver 4310T 2.3 GHz 10-Core LGA 4189 105W CD8068904659001 server processor

SKU CH-ZQDZ-5X2N1 MPN CD8068904659001

Ten-core server processor with 20 threads, 15 MB L3 cache and 105 W TDP for LGA 4189 platforms

  • NameXeon Silver 4310T
  • CPU Socket TypeLGA 4189
  • Core NameIce Lake
  • # of Cores10-Core
  • # of Threads20
  • Operating Frequency2.3 GHz
  • 10 cores and 20 threads handle parallel workloads efficiently
  • 3 GHz base with 3.40 GHz turbo balances speed and power
  • 15 MB L3 cache reduces latency for frequent data
  • 8-channel DDR4 2666 support feeds all cores with bandwidth
  • 64 PCIe 4.0 lanes enable high-throughput I/O expansion

Server CPU for LGA 4189 platforms

The Intel Xeon Silver 4310T is a 10-core, 20-thread processor built on 10 nm Ice Lake architecture for dual-socket server boards using the LGA 4189 socket. It runs at a 2.3 GHz base frequency with a 3.40 GHz maximum turbo and provides 15MB of L3 cache. The 105W thermal design power fits standard server cooling envelopes.

Suits density-optimised dual-socket servers

This processor suits deployments that need eight-channel DDR4 2666 memory bandwidth and 64 lanes of PCI Express 4.0 connectivity in a 105W power budget. Buyers who need higher core counts, larger L3 caches or greater turbo headroom should look at other SKUs in the same socket family. It is not intended for single-socket workstations or platforms that require a different socket type.

Spec check: LGA 4189 socket and 105W TDP

The single specification that decides fit is the LGA 4189 socket combined with the 105W thermal design power; the motherboard must support both exactly. Verify the board's qualified vendor list and cooling capacity before purchase. Memory must be DDR4 2666 across eight channels to match the integrated controller.

Highlights

  • 10 cores and 20 threads handle parallel workloads efficiently
  • 3 GHz base with 3.40 GHz turbo balances speed and power
  • 15 MB L3 cache reduces latency for frequent data
  • 8-channel DDR4 2666 support feeds all cores with bandwidth
  • 64 PCIe 4.0 lanes enable high-throughput I/O expansion

Specifications

BrandIntel
SeriesIntel Xeon Silver
NameXeon Silver 4310T
ModelCD8068904659001
CPU Socket TypeLGA 4189
Core NameIce Lake
# of Cores10-Core
# of Threads20
Operating Frequency2.3 GHz
Max Turbo Frequency3.40 GHz
L3 Cache15MB
64-Bit SupportYes
Hyper-Threading SupportYes
Manufacturing Tech10 nm
Integrated Memory Controller SpeedDDR4 2666
Memory Channel8 Channel
Virtualization Technology SupportYes
PCI Express Revision4.0
Max # of PCI Express Lanes64
Thermal Design Power105W
Shipping weight0.09 kg
Package size116 × 101 × 44 mm

Questions about this item

What LGA 4189 motherboard do I need to install this Xeon Silver 4310T?

A server motherboard with an LGA 4189 socket and a chipset supporting 10 nm Ice Lake Xeon processors is required for the CD8068904659001.

Can I pair this 10-core CPU with older DDR4 2666 modules I already own?

Yes, the integrated memory controller runs DDR4 at 2666 across eight channels, so existing DDR4 2666 DIMMs will operate at their rated speed.

How can I confirm the 105 W TDP is being respected under load?

Monitor package power in the BIOS hardware monitor or via IPMI sensors; sustained readings at or below 105 W indicate the processor is operating within its thermal design power.
