Intel Xeon W7-3565X server CPU, silver heat spreader, LGA 4677 land grid array

Intel

Intel Xeon W7-3565X 32-core 2.5 GHz server processor BX807133565X

SKU CH-X8R0-K0DC4 MPN BX807133565X

32-core server CPU with 2.5 GHz base, 4.8 GHz max turbo, 82.5 MB L3 cache, DDR5-4800 8-channel memory, 112 PCIe 5.0 lanes, 335 W TDP, LGA 4677 socket

  • NameXeon W7-3565X
  • CPU Socket TypeLGA 4677
  • Core NameSapphire Rapids
  • # of Cores32-Core
  • # of Threads64
  • Operating Frequency2.5 GHz
  • 32 cores and 64 threads accelerate multi-threaded workloads
  • 8 GHz max turbo frequency speeds single-thread bursts
  • 5 MB L3 cache reduces latency for large datasets
  • 8-channel DDR5 4800 controller supports up to 4 TB memory
  • 112 PCIe 5.0 lanes enable high-bandwidth I/O expansion

Workstation processor for single-socket servers

The Intel Xeon W7-3565X is a 32-core, 64-thread server CPU built for workstations that run heavy compute workloads on a single socket. It targets engineers, researchers and content creators who need high core counts without multi-socket complexity. The processor drops into the LGA 4677 platform and supports up to 4 TB of DDR5 memory across eight channels.

Single-socket constraint with 112 PCIe 5.0 lanes

Scalability is limited to 1S only, so this chip cannot be paired with a second processor in a dual-socket board. If your workload demands multi-socket scaling or more than 112 lanes of PCIe 5.0 connectivity, this part will not meet the requirement. Buyers planning dual-socket servers or larger lane budgets must choose a different processor line.

335 W base power and 402 W max turbo power

The processor carries a thermal design power of 335 W and can draw up to 402 W under Intel Turbo Boost Max Technology 3.0. A cooling solution rated for at least the maximum turbo power is required because no cooler is included in the box. Sustained all-core loads will run near the base power level while bursty single-thread tasks can push consumption toward the higher figure.

Highlights

  • 32 cores and 64 threads accelerate multi-threaded workloads
  • 8 GHz max turbo frequency speeds single-thread bursts
  • 5 MB L3 cache reduces latency for large datasets
  • 8-channel DDR5 4800 controller supports up to 4 TB memory
  • 112 PCIe 5.0 lanes enable high-bandwidth I/O expansion

Specifications

BrandIntel
SeriesXeon
NameXeon W7-3565X
ModelBX807133565X
CPU Socket TypeLGA 4677
Core NameSapphire Rapids
# of Cores32-Core
# of Threads64
Operating Frequency2.5 GHz
Max Turbo FrequencyIntel Turbo Boost Max Technology 3.0 Frequency: 4.8 GHz
Intel Turbo Boost Technology Maximum Single Core Turbo Frequency: 4.6 GHz
L3 Cache82.5MB
64-Bit SupportYes
Hyper-Threading SupportYes
Manufacturing Tech10 nm
Integrated Memory Controller SpeedDDR5 4800
Maximum Memory Capacity4TB
Memory Channel8 Channel
Virtualization Technology SupportYes
Scalability1S Only
PCI Express Revision5.0
Max # of PCI Express Lanes112
Thermal Design Power335W
Max Turbo Power402W
Cooling DeviceCooling device not included - Processor Only
Shipping weight0.23 kg
Package size140 × 114 × 51 mm

Questions about this item

How does the 32-core design with 64 threads perform in a real workstation?

Thirty-two cores and sixty-four threads let you run heavy multi-threaded workloads such as rendering, simulation or large-scale compilation with high parallel throughput.

What does the PCI Express 5.0 interface with 112 lanes actually cap in practice?

The CPU exposes up to 112 lanes of PCIe 5.0, so total platform bandwidth is limited by that lane count and the 5.0 signalling rate per lane.

What does the LGA 4677 socket need for mounting and cooling?

The processor fits an LGA 4677 socket and requires a compatible cooler rated for its 335 W base power or 402 W max turbo power, as no cooling device is included.
