Compact mATX board, dark PCB with silver heatsinks, dual DDR5 slots, single PCIe x16, two M.2, rear I/O cluster

JGINYUE

JGINYUE B650M GAMING PLUS AMD motherboard

SKU CH-DV13-ZS3HH

Micro-ATX AM5 board with 11-phase power, dual-channel DDR5 up to 64GB at 6000MHz, two M.2 4.0 slots, four SATA 3.0 ports, 2.5G LAN and Realtek ALC897 audio

  • CPU Socket TypeAM5
  • CPU TypeRyzen 9000 Series
  • ChipsetAMD B650M
  • Number of Memory Slots2x288pin (DDR5)
  • Memory StandardDDR5 6000
  • Maximum Memory Supported64GB
  • Supports Ryzen 7000, 8000 and 9000 series CPUs on AM5 socket
  • Dual-channel DDR5 memory up to 64 GB at 6000 MHz
  • Two M.2 slots with NVME 4.0 protocol for fast storage
  • 5 Gb Ethernet and Realtek ALC897 audio built in
  • 11-phase power delivery with four 4-pin fan headers

Platform and audience

The JGINYUE B650M GAMING PLUS is an AM5 motherboard built for AMD Ryzen 7000, 8000 and 9000 series desktop processors. It fits micro-ATX cases and targets system builders who want a compact board with modern connectivity.

Upgrade path

Moving to this board brings DDR5 memory support up to 64 GB at 4800 to 6000+ MHz via AMD EXPO profiles. It also adds two M.2 slots with NVME protocol 4.0 and a 2.5 G Ethernet controller for faster storage and network throughput.

Sustained operation

An 11 phase power delivery design feeds the CPU socket while four 4-pin fan headers allow active cooling control. Diagnostic LEDs and a one-click BIOS clear button simplify troubleshooting during extended high-load sessions.

Highlights

  • Supports Ryzen 7000, 8000 and 9000 series CPUs on AM5 socket
  • Dual-channel DDR5 memory up to 64 GB at 6000 MHz
  • Two M.2 slots with NVME 4.0 protocol for fast storage
  • 5 Gb Ethernet and Realtek ALC897 audio built in
  • 11-phase power delivery with four 4-pin fan headers

Specifications

BrandJGINYUE
SeriesAMD
ModelB650M GAMING PLUS
Part NumberB650M
CPU Socket TypeAM5
CPU TypeRyzen 9000 Series
ChipsetAMD B650M
Number of Memory Slots2x288pin (DDR5)
Memory StandardDDR5 6000
Maximum Memory Supported64GB
Channel SupportedDual Channel
Memory Performance ProfileAMD EXPO
PCI Express 4.0 x161 x PCI Express 4.0 x16
PCI Express x11 x PCI Express x1
Serial ATA (SATA)4 x SATA 6Gb/s
M.22 x M.2
Audio ChipsetRealtek ALC897
LAN ChipsetRTL8125BG 2.5G Ethernet chip
HDMI1 x HDMI
DisplayPort1 x DisplayPort
USB 3.04 x USB 3.0
USB 1.1/2.04 x USB 2.0
Onboard USBRear 4xUSB 3.2, 4xUSB 2.0
Other ConnectorsFront mounted 1xUSB3.2 pin, 2xUSB2.0 pin
Form FactorMicro ATX
Power Pin24 Pin
Windows 11Supported

Questions about this item

What are the board dimensions and form factor for case clearance?

The board measures 24cm by 19cm and uses the M-ATX form factor, so check your case supports that size before ordering.

How do I connect the front-panel Type-E 5G header and which CPU generation affects rear USB availability?

Plug the case front-panel cable into the single front Type-E 5G header; on 8000 series CPUs one rear USB port may be disabled due to channel limits.

Which components will need attention or replacement over the life of the board?

The CMOS battery will eventually need replacing to keep BIOS settings, and the four 4-pin fan headers should be checked if cooling performance drops.
