Black M.2 2280 SSD with silver heatsink and gold contacts

KINGSMAN GAMING

KINGSMAN GAMING KM600 ULTRA 1TB M.2 2280 internal SSD

SKU CH-JD8W-XEBRT

A 1 TB M.2 2280 NVMe drive with a heatsink delivering up to 3200 MB/s read and 2500 MB/s write

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity1TB
  • Memory Components3D NAND TLC
  • InterfacePCI-Express 3.0 x4

Options 1TB

  • Sequential read up to 3200 MBps speeds game loads
  • Sequential write up to 2500 MBps cuts file transfer time
  • 700 TBW rating extends usable lifespan
  • Built-in heatsink maintains performance under load
  • 1,000,000 hour MTBF indicates long-term reliability

1TB NVMe drive with heatsink

The Kingsman Gaming KM600 Ultra is a 1TB M.2 2280 internal SSD built on PCIe 3.0 x4 and NVMe 1.4. It uses 3D NAND TLC memory and ships with an integrated heatsink. Sequential reads reach 3200 MBps and writes reach 2500 MBps. The drive is rated for 700TB written and a 1,000,000 hour MTBF.

Installation and common issues

The M.2 2280 form factor fits a standard motherboard slot and is secured with a single screw. Because the heatsink adds height, verify that the motherboard standoff and any nearby components leave enough clearance. A loose screw or an angled insert are the most frequent causes of the drive not being detected.

Compatibility checklist

Confirm the system has an M.2 slot wired for PCIe 3.0 x4 and NVMe 1.4 support. Check the motherboard manual for any shared-lane restrictions that could reduce bandwidth. Ensure the BIOS is current enough to recognise NVMe 1.4 drives and that the operating system includes an NVMe driver.

Highlights

  • Sequential read up to 3200 MBps speeds game loads
  • Sequential write up to 2500 MBps cuts file transfer time
  • 700 TBW rating extends usable lifespan
  • Built-in heatsink maintains performance under load
  • 1,000,000 hour MTBF indicates long-term reliability

Specifications

BrandAITC KINGSMAN
SeriesKM600 ULTRA
ModelAIKM600UM1TB228
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity1TB
Memory Components3D NAND TLC
InterfacePCI-Express 3.0 x4
ProtocolNVMe 1.4
Max Sequential ReadUp to 3200 MBps
Max Sequential WriteUp to 2500 MBps
Terabytes Written (TBW)700TB
MTBF1,000,000 hours
HeatSinkwith HeatSink

Other versions of this model

2 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Will this drive fit in a standard M.2 2280 slot on a desktop or laptop motherboard?

Yes, the drive follows the M.2 2280 form factor and uses a PCIe 3.0 x4 interface with NVMe 1.4 protocol, matching the slot specification on most modern Intel and AMD platforms.

Does the included heatsink add enough height to block installation in a thin laptop?

The drive ships with a heatsink attached; you should verify the clearance in your specific laptop chassis before purchase, as the extra height may exceed the space allowed in some ultra-thin designs.

What level of write endurance does the 1 TB model provide for heavy workloads?

The drive is rated for 700 TBW and uses 3D NAND TLC with SLC caching to sustain performance during intensive write tasks.
