Green circuit board with black chips and silver connector, thin rectangular M.2 2280 SSD without heatsink

KingSpec

KingSpec XG7000-1TB internal SSD

SKU CH-5J7X-P5JG5 MPN XG7000-1TB

M.2 2280 PCIe 4.0 x4 NVMe 1.4 SSD with 1TB 3D NAND, 1GB DRAM cache, 7400 MB/s read, 6600 MB/s write, 720000 read IOPS, 800000 write IOPS, 600 TBW, graphene heat spreader

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity1TB
  • Memory Components3D NAND
  • InterfacePCI-Express 4.0 x4

Options XG 7000-1TB

  • XG 7000-8TB
  • XG 7000-4TB
  • XG 7000-2TB
  • XG 7000-1TB
  • XG 7000-512GB
  • XG7000-2TB-Soccer 2280
  • XG 7000-2TB 2242
  • XG 7000-1TB 2242
  • XG 7000-512 2242

Struck-through versions exist but are not stocked here.

  • Reads up to 7400 MB/s via PCIe 4.0 x4
  • Writes up to 6600 MB/s for fast game loads
  • 720000 random read IOPS with 1GB DRAM cache
  • 600 TBW and 1000000-hour MTBF for endurance
  • Slim 2.1 mm M.2 2280 fits PS5 and laptops

PCIe 4.0 NVMe drive for PS5 and PC

The KingSpec XG7000-1TB is an M.2 2280 internal SSD built on PCIe 4.0 x4 with NVMe 1.4. It targets gamers and creators who need fast load times on PS5, desktop or laptop. A 1 GB DRAM cache supports sustained throughput.

Graphene spreader, 0.66 W idle draw

A graphene-based thermal spreader keeps the controller cool without a bulky heatsink. Idle power sits at 0.66 W, helping laptop battery life. The thin 2.1 mm profile fits tight slots while maintaining stable temperatures during long sessions.

Fits M.2 2280 slots, frees 2.5-inch bays

The 80.0 x 22.0 mm card drops into any M.2 2280 socket, including PS5 expansion bays. Removing a 2.5-inch drive cage clears space for extra airflow or additional storage. Backward compatible with PCIe 3.0 systems.

Highlights

  • Reads up to 7400 MB/s via PCIe 4.0 x4
  • Writes up to 6600 MB/s for fast game loads
  • 720000 random read IOPS with 1GB DRAM cache
  • 600 TBW and 1000000-hour MTBF for endurance
  • Slim 2.1 mm M.2 2280 fits PS5 and laptops

Specifications

BrandKingSpec
SeriesXG7000 Series
ModelXG7000 2280
Part NumberXG7000-1TB 2280
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity1TB
Memory Components3D NAND
InterfacePCI-Express 4.0 x4
ProtocolNVMe 1.4
Cache1GB DRAM
Max Sequential ReadUp to 7400 MBps
Max Sequential WriteUp to 6600 MBps
4KB Random ReadUp to 720,000 IOPS
4KB Random WriteUp to 800,000 IOPS
Terabytes Written (TBW)600TB
MTBF1,000,000 hours
HeatSinkwithout HeatSink
Power Consumption (Idle)0.66W
Power Consumption (Active)8.18W
Operating Temperature0°C ~ +70°C
Storage Temperature-20°C ~ +75°C
Operating Humidity5-95%
Height80.0mm
Width22.0mm
Depth2.10mm
Weight30g
Shipping weight0.05 kg
Package size102 × 57 × 13 mm

Questions about this item

How do I install the KingSpec XG7000-1TB in a PS5 and what step do people often miss?

Insert the M.2 2280 drive into the console's PCIe 4.0 x4 slot at a slight angle then secure it with the single screw; the step many miss is removing the PS5's cover and the expansion-slot screw before sliding the drive in.

What maintenance or replacement will the XG7000-1TB need later?

No scheduled maintenance is required; the 3D NAND drive is rated for 600 TBW and 1,000,000 hours MTBF, so replacement only becomes necessary once the 600 terabytes-written endurance limit is reached.

What limit appears first during sustained heavy writes on this SSD?

The graphene heatsink and thermal-throttling firmware will reduce write speeds from the 6600 MB/s peak once the controller temperature reaches its safety threshold, making thermal throttling the first sustained-use limit.
