Small green circuit board with gold edge connector and black memory chips, mSATA form factor

Kingston Technology Corp.

Kingston Technology Corp. SMS200S3/60G 60GB mSATA internal SSD

SKU CH-WAEN-0AK47 MPN SMS200S3/60G

A 60 GB mSATA solid-state drive with 550 MB/s read and 520 MB/s write speeds for notebooks or desktops with an mSATA slot

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Capacity60GB
  • InterfaceMini-SATA (mSATA)
  • ControllerSandForce
  • Sustained Sequential Read550MBps
  • 60 GB capacity stores OS and key apps
  • mSATA form factor fits ultra-thin notebooks and small desktops
  • 550 MB/s sequential read and 520 MB/s sequential write speed boot and load times
  • 86,000 random read and 78,000 random write IOPS keep multitasking responsive
  • 1 million-hour MTBF and 20 G shock resistance protect data on the move

Capacity and form factor

The Kingston SMS200S3/60G is a 60GB mSATA internal solid-state drive built for notebooks, Ultrabooks and desktops that have an mSATA connector. Its caseless PCB design measures one-eighth the size of a 2.5 inch hard drive and uses a SandForce 2241 controller with a SATA 3.0 interface.

Thermals noise and power

The drive draws 0.4W at idle, 1.2W during typical read operations and 1.8W during typical write operations. With no moving parts it operates silently and is rated for an operating temperature range of 0°C to 70°C, a storage range of -40°C to 85°C and a vibration resistance of 20G.

Sequential speed ceiling

Sustained sequential read reaches 550MBps and sustained sequential write reaches 520MBps over the SATA 3.0 link. These figures set the practical performance ceiling for boot, application launch and file transfer workloads on this 60GB mSATA SSD.

Highlights

  • 60 GB capacity stores OS and key apps
  • mSATA form factor fits ultra-thin notebooks and small desktops
  • 550 MB/s sequential read and 520 MB/s sequential write speed boot and load times
  • 86,000 random read and 78,000 random write IOPS keep multitasking responsive
  • 1 million-hour MTBF and 20 G shock resistance protect data on the move

Specifications

BrandKingston
ModelSMS200S3/60G
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Capacity60GB
InterfaceMini-SATA (mSATA)
ControllerSandForce
Sustained Sequential Read550MBps
Sustained Sequential Write520MBps
4KB Random ReadUp to 86,000 IOPS
4KB Random WriteUp to 78,000 IOPS
MTBF1,000,000 hours
FeaturesLSI SandForce 2241 controller with SATA Rev. 3.0 (6Gb/s) interface -twice as fast as previous generation, yet more cost efficient
mSATA interface - fully compliant with industry standard, easy to fit, guaranteed to work
NAND Flash memory based - shock resistant with low power consumption
Supports Intel's SRT - combines capacity advantage of HDD with performance improvements of SSD in dual-storage configuration
Supports S.M.A.R.T. - monitors the status of your drive
Supports TRIM - maintains maximum performance on compatible operating systems
Power Consumption (Idle)0.4W
Power Consumption (Active)1.2W (TYP) Read
1.8W (TYP) Write
Operating Temperature0°C ~ +70°C
Storage Temperature-40°C ~ +85°C
Max Vibration Resistance20G
Height1.000
Width30mm
Depth50.88mm
Weight6.86g
Shipping weight0.02 kg
Package size81 × 44 × 8 mm

Questions about this item

How do I install the SMS200S3/60G mSATA SSD and what is the common mistake?

Insert the card into the mSATA slot at an angle, then press it down and secure it with the mounting screw; the step people miss is fastening that screw, which leaves the drive loose and can cause connection loss.

What maintenance or replacement will the SMS200S3/60G need over time?

No mechanical maintenance is required; keep the operating temperature between 0°C and 70°C, ensure the OS issues TRIM commands to sustain write performance, and replace the drive only if SMART data reports worn NAND or reallocated sectors.

What limit appears first on the SMS200S3/60G during sustained heavy writes?

The 520 MBps sustained sequential write ceiling is reached before thermal throttling, because active write power is 1.8 W and the drive is rated to 70°C operating temperature.
