Rectangular 2.5 inch SSD with black metal casing and label sticker

Kingston Technology Corp.

Kingston Technology Corp. SUV400S3B7A/480G internal SSD

SKU CH-R5BR-Y3GR3 MPN SUV400S3B7A/480G

A 2.5-inch 480 GB SATA solid-state drive with sequential read speeds up to 550 MBps and write speeds up to 500 MBps

  • Device TypeSSD Combo Bundle
  • Used ForConsumer
  • Form Factor2.5"
  • Capacity480GB
  • Memory ComponentsTLC
  • InterfaceSATA III

Options 480GB Bundle

  • Fast boot and load times from up to 550 MBps sequential read
  • Responsive multitasking backed by up to 90,000 IOPS random read
  • Long service life supported by 1,000,000 hours MTBF rating
  • Low power draw with 0.672W idle and 0.693W average active consumption
  • Easy upgrade path via 2.5" SATA form factor and bundle kit option

Drive identity

This 2.5 inch SATA internal SSD delivers 480GB of TLC storage for consumer desktops and laptops. The Marvell 88SS1074 controller provides sequential speeds up to 550 MBps read and 500 MBps write with random performance of 90000 IOPS read and 35000 IOPS write. Rated MTBF reaches 1000000 hours.

Deciding spec

The SATA III interface and 2.5 inch form factor determine whether this drive fits your system; it requires a standard SATA data and power connection and a 7.00mm drive bay. Sequential throughput peaks at 550 MBps read and 500 MBps write, well above a 7200 RPM hard drive. Power draw stays below 2.515W maximum write.

Install notes

The bundle kit includes hardware for straightforward mounting in a 69.85mm by 100.00mm bay. Connect the SATA data and power cables, secure the drive with the supplied screws, and initialise in the operating system. Common issues are loose cables or forgetting to enable AHCI mode in BIOS for full performance.

Highlights

  • Fast boot and load times from up to 550 MBps sequential read
  • Responsive multitasking backed by up to 90,000 IOPS random read
  • Long service life supported by 1,000,000 hours MTBF rating
  • Low power draw with 0.672W idle and 0.693W average active consumption
  • Easy upgrade path via 2.5" SATA form factor and bundle kit option

Specifications

BrandKingston
SeriesSSDNow UV400
ModelSUV400S3B7A/480G
Device TypeSSD Combo Bundle
Used ForConsumer
Form Factor2.5"
Capacity480GB
Memory ComponentsTLC
InterfaceSATA III
ControllerMarvell 88SS1074
Max Sequential ReadUp to 550 MBps
Max Sequential WriteUp to 500 MBps
4KB Random ReadUp to 90,000 IOPS
4KB Random WriteUp to 35,000 IOPS
MTBF1,000,000 hours
Features10 times faster than a 7200 RPM hard drive
More reilable and durable than a hard drive
Available as a bundle kit for easy installation
Multiple capacities to met your needs
Power Consumption (Idle)0.672W
Power Consumption (Active)0.693W Avg
0.590W (MAX) Read
2.515W (MAX) Write
Operating Temperature0°C ~ +70°C
Storage Temperature-40°C ~ +85°C
Max Vibration ResistanceOperating: 2.17G Peak (7-800Hz)
Non-operating: 20G Peak (10-2000Hz)
Height7.00mm
Width69.85mm
Depth100.00mm
Weight57.00g
Shipping weight0.35 kg
Package size168 × 163 × 53 mm

Other versions of this model

1 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What does the 550 MBps sequential read figure mean for everyday use?

It means the drive can read large files such as videos or backups at up to 550 MBps, which is roughly ten times the throughput of a typical 7200 RPM hard drive.

What does the SATA III interface limit in practice?

The SATA III link caps real-world throughput at about 550 MBps read and 500 MBps write, so the drive cannot exceed those speeds even if the controller could go faster.

Will this 2.5 inch drive fit my laptop or desktop bay?

Yes, it measures 100.00 mm long, 69.85 mm wide and 7.00 mm high, matching the standard 2.5 inch form factor used in most laptops and desktop drive cages.
