Small green circuit board with wide-angle camera lens and four mounting holes

LORDWORLD

LORDWORLD IMX219-160 8MP 160° Camera Module for Jetson Nano development board

SKU CH-1SAZ-1W00C

An 8 MP Sony IMX219 sensor with a 160° field of view and <14.3% distortion for Jetson Nano AI projects

  • 8MP Sony IMX219 sensor captures 3280×2464 detail for AI vision
  • 160° diagonal field of view covers wide scenes with
  • 15mm focal length and F2.35 aperture suit close-range recognition tasks
  • Four screw holes and 25×24mm footprint simplify mounting on Jetson Nano kits
  • 3V power output enables direct connection to the developer board

IMX219-160 Camera Module for Jetson Nano

The LORDWORLD IMX219-160 is an 8 megapixel camera module built around a Sony IMX219 sensor. It connects directly to the NVIDIA Jetson Nano Developer Kit for AI workloads such as face recognition, road mark detection and licence plate recognition. The module measures 25mm × 24mm and provides a 3.3V power output.

Check CSI interface and mounting space

Verify that your Jetson Nano Developer Kit has an available CSI camera connector compatible with the IMX219 sensor. Ensure the 25mm × 24mm board fits within your enclosure and that the four screw holes align with your mounting points. The 160° diagonal field of view requires an unobstructed line of sight for the 3.15mm focal length lens.

Compact board with four-hole mounting

The 25mm × 24mm PCB uses four screw holes for secure attachment, reducing vibration in mobile or robotic projects. A 1/4 inch CMOS sensor with an F2.35 aperture and 3.15mm focal length delivers a 160° diagonal angle of view while keeping distortion below 14.3%. The 3.3V output simplifies power distribution for the Jetson Nano platform.

Highlights

  • 8MP Sony IMX219 sensor captures 3280×2464 detail for AI vision
  • 160° diagonal field of view covers wide scenes with
  • 15mm focal length and F2.35 aperture suit close-range recognition tasks
  • Four screw holes and 25×24mm footprint simplify mounting on Jetson Nano kits
  • 3V power output enables direct connection to the developer board

Specifications

BrandLORDWORLD

Questions about this item

What comes in the box with the IMX219-160 camera module and do I need to buy a Jetson Nano separately?

The module includes the camera board with four mounting screw holes and a 3.3 V power output. A Jetson Nano Developer Kit is not included and must be purchased separately.

Should I choose this 160° wide-angle version or a narrower field-of-view module for my project?

Choose the 160° diagonal field of view when you need wide coverage such as road-mark or licence-plate detection; a narrower module would capture less scene per frame.

What does the 8 MP 3280 × 2464 resolution actually deliver when the camera is running on a Jetson Nano?

It provides 8 megapixel stills at 3280 × 2464 pixels through the CSI interface, enabling detailed input for face recognition and other AI tasks on the Nano.
