Small green ITX motherboard with silver heatsinks and black slots

MAXSUN

MAXSUN Challenger H610 ITX Intel motherboard

SKU CH-YT4Z-4T80B

Mini-ITX board for Intel LGA 1700 CPUs with DDR4, PCIe 4.0 x16, 2.5 GbE LAN and dual HDMI

  • CPU Socket TypeLGA 1700
  • CPU TypeIntel Core 12th Gen (LGA 1700)
  • ChipsetIntel H610
  • Number of Memory Slots2x288pin (DDR4)
  • Memory StandardSupport XMP 3200Mhz
  • Maximum Memory Supported64GB
  • Supports Intel 12th Gen Core processors via LGA 1700 socket
  • 8+1+1 phase power delivery with 50A DR.MOS for stable CPU operation
  • ITX air-duct optimisation and alloy armour improve thermal performance
  • 5 Gbps LAN plus CNVi Wi-Fi interface for flexible connectivity
  • Dual-channel DDR4 up to 64 GB with XMP 3200 MHz support

Challenger H610 ITX platform

The MAXSUN Challenger H610 ITX motherboard uses the Intel H610 chipset on an LGA 1700 socket for 12th Generation Core processors. Two DDR4 slots support up to 64GB of dual-channel memory with XMP 3200MHz profiles. A single PCIe 4.0 x16 slot, four SATA 6Gb/s ports and one M.2 connector handle expansion and storage.

Compact builds and integrated graphics users

This board suits small-form-factor systems that rely on the CPU's integrated graphics, thanks to two HDMI ports and one DisplayPort output. The 2.5Gbps Realtek LAN and CNVi wireless interface cover wired and wireless networking. Builders needing multiple graphics cards, overclocking headroom or more than two memory slots should consider a larger chipset.

Straightforward ITX installation

The 24-pin and 8-pin power connectors follow standard ATX layout, and the I/O shield is included in the box. The alloy heat-dissipation armour covers the 8+1+1 phase VRM with 50A DR.MOS components, so airflow around the VRM area is the main installation watch-point.

Highlights

  • Supports Intel 12th Gen Core processors via LGA 1700 socket
  • 8+1+1 phase power delivery with 50A DR.MOS for stable CPU operation
  • ITX air-duct optimisation and alloy armour improve thermal performance
  • 5 Gbps LAN plus CNVi Wi-Fi interface for flexible connectivity
  • Dual-channel DDR4 up to 64 GB with XMP 3200 MHz support

Specifications

BrandMAXSUN
SeriesChallenger
ModelH610 ITX
CPU Socket TypeLGA 1700
CPU TypeIntel Core 12th Gen (LGA 1700)
ChipsetIntel H610
Number of Memory Slots2x288pin (DDR4)
Memory StandardSupport XMP 3200Mhz
Maximum Memory Supported64GB
Channel SupportedDual Channel
PCI Express 4.0 x161 x PCI Express 4.0 x16
Serial ATA (SATA)4 x SATA 6Gb/s
M.21 x M.2
Audio ChipsetALC897
LAN ChipsetRealtek RTL8125B
Max LAN Speed2.5Gbps
Wireless LANCNVi Wireless Network card Interface
Back I/O Ports2 USB3.2 Gen1 ports, 3 USB2.0 ports; 1 group of USB3.2 Gen1 ports on the front panel, 1 group of USB2.0 ports on the front panel
HDMI2 x HDMI
DisplayPort1 x DisplayPort
Onboard USB2 USB3.2 Gen1 ports, 3 USB2.0 ports
Form FactorMini ITX
Dimensions (W x L)170 × 170 mm
Power Pin24 pins + 8 pins

Questions about this item

What DDR4 memory speed does the MAXSUN Challenger H610 ITX board officially support with XMP?

The board supports DDR4 up to 3200 MHz when XMP is enabled in the BIOS.

Will my existing SATA 6 Gb/s drives work with the four SATA ports on this motherboard?

Yes, the four SATA 6 Gb/s ports are backward compatible with older SATA revisions.

How can I confirm the 2.5 GbE LAN is running at full speed after installing the board?

Check the network adapter status in Windows or use a speed test against a 2.5 GbE-capable switch.
