Small square black mini PC with front ports and vents

minisforum

minisforum NAB6 Lite barebone mini PC Core i5-12600H 32GB 512GB

SKU CH-BYQQ-NCDN8

A compact barebone mini PC with a 12-core Intel Core i5-12600H, 32 GB DDR4 and a 512 GB PCIe 4.0 SSD, driving four 4K displays via dual HDMI and dual USB-C plus twin 2.5 Gbps LAN ports

  • CPU SocketFCBGA1744
  • CPU TypeIntel Core i5-12600H
  • CPU Cores12-Core(4P+8E)
  • Integrated GraphicsIntel Iris Xe Graphics eligible
  • Wireless LAN802.11ax
  • BluetoothBluetooth 5.2

Options NAB6 Lite(32+500)

Struck-through versions exist but are not stocked here.

  • 12-core 16-thread Core i5-12600H reaches 4.5 GHz for responsive multitasking
  • Intel Iris Xe graphics drives four 4K 60 Hz displays via two HDMI and two USB-C ports
  • Dual 2.5 Gbps Ethernet ports enable router or firewall roles with high throughput
  • 32 GB DDR4 3200 installed and 512 GB PCIe 4.0 SSD fitted, both expandable
  • Compact 5.02 × 5 × 2.15 inch chassis weighs 1.25 lb for flexible placement

Ready-to-run mini PC for office and media

The minisforum NAB6 Lite arrives as a complete barebone system with an Intel Core i5-12600H processor, 12 cores and 16 threads boosting to 4.5 GHz, 32 GB of DDR4-3200 memory already installed and a 512 GB PCIe 4.0 M.2 SSD. It targets users who want a compact desktop for productivity, streaming or light creative work without assembling parts themselves.

Memory and storage headroom

The two SO-DIMM slots support up to 64 GB of DDR4, so the factory 32 GB leaves room for a straightforward upgrade. The M.2 2280 slot accepts PCIe 4.0 drives up to 2 TB, and a 2.5-inch SATA 3.0 bay is available for an additional hard drive or SSD. When all three bays are populated the platform reaches its storage ceiling.

Cooling, acoustics and power in daily use

The integrated Intel Iris Xe graphics drive up to four 4K displays at 60 Hz through two HDMI and two USB-C ports while staying within the chip’s 45 W base power envelope. Dual 2.5 GbE ports, Wi-Fi 6E and Bluetooth 5.2 handle networking without adding discrete controllers that increase heat. In typical office workloads the system runs quietly and draws modest power from its external adapter.

Highlights

  • 12-core 16-thread Core i5-12600H reaches 4.5 GHz for responsive multitasking
  • Intel Iris Xe graphics drives four 4K 60 Hz displays via two HDMI and two USB-C ports
  • Dual 2.5 Gbps Ethernet ports enable router or firewall roles with high throughput
  • 32 GB DDR4 3200 installed and 512 GB PCIe 4.0 SSD fitted, both expandable
  • Compact 5.02 × 5 × 2.15 inch chassis weighs 1.25 lb for flexible placement

Specifications

BrandMINISFORUM
ModelDeskMini
CPU SocketFCBGA1744
CPU TypeIntel Core i5-12600H
CPU Cores12-Core(4P+8E)
Integrated GraphicsIntel Iris Xe Graphics eligible
Wireless LAN802.11ax
BluetoothBluetooth 5.2
WiFi GenerationWi-Fi 6E
HDMI2
RJ452
Memory slot2x DDR4 SO-DIMM Slot
Memory Type SupportedDDR4 3200
Max Memory Supported64GB
Memory installed32GB
Dimensions5.02x 5x 2.15 inch
Weight1.25 LB

Other versions of this model

4 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Will the NAB6 Lite's two 2.5 Gbps LAN ports work with my existing gigabit switch and Cat5e cabling?

Yes, the dual 2.5 Gbps RJ45 ports are backward compatible and will negotiate down to 1 Gbps on your current switch and Cat5e cables.

How can I verify the Core i5-12600H is running at its 4.5 GHz maximum turbo frequency under load?

Open Task Manager's Performance tab or a tool like HWMonitor while running a heavy workload; the CPU clock should reach 4.5 GHz on the performance cores.

Does the box include the 32 GB DDR4-3200 memory and 512 GB PCIe 4.0 SSD, or must I buy them separately?

The unit ships with 32 GB (2×16 GB) DDR4-3200 SO-DIMMs and a 512 GB M.2 2280 PCIe 4.0 SSD already installed.
