Green Micro ATX motherboard with black sockets and silver heatsinks

MSI

MSI 760GM-P21(FX) AM3+ 760G DDR3 16GB Micro ATX motherboard

SKU CH-T70V-6QDDK

Supports AM3+ CPUs with dual-channel DDR3 up to 16 GB and provides a PCIe 2.0 x16 slot plus four SATA ports

  • CPU Socket TypeSocket AM3+
  • CPU Type64bit AMD FX, Phenom II X6/X4/X3/X2, Athlon II X4/X3/X2 and
  • ChipsetAMD 760G
  • Memory StandardSupports dual-channel DDR3 1333/1066/800MHz memory
  • Maximum Memory Supported16GB
  • PCI Slots1 PCI Express x16 slot supports PCIE 2.0 x 16 speed executio
  • Supports 64-bit AMD FX, Phenom II and Athlon II CPUs with Socket AM3+
  • Dual-channel DDR3 1333/1066/800 MHz memory up to 16 GB capacity
  • PCI Express 2.0 x16 slot plus x1 and PCI slots for expansion
  • Realtek ALC887 7-channel audio with intelligent interface detection
  • Realtek RTL8105E Gigabit LAN supporting 10/100 Mb/s speeds

MSI 760GM-P21(FX) AM3+ Motherboard

The MSI 760GM-P21(FX) is a Micro ATX board built around the AMD 760G chipset for Socket AM3+ processors. It accepts 64-bit AMD FX, Phenom II, Athlon II and Sempron CPUs. The board provides dual-channel DDR3 memory support up to 16 GB across the 1333, 1066 and 800 MHz standards. It suits budget builds or legacy upgrades where AM3+ compatibility is required.

PCI Express 2.0 and SATA II limits

A single PCI Express x16 slot runs at the 2.0 generation, capping graphics bandwidth to that standard. One PCI Express x1 slot and one 3.3 V or 5 V PCI slot complete the expansion options. Storage connects through four SATA II ports that top out at 3 Gb/s per drive. The Realtek RTL8105E LAN controller is limited to 10 Mb/s and 100 Mb/s Ethernet speeds.

16 GB DDR3 ceiling

The maximum supported memory is 16 GB of dual-channel DDR3. Any build that needs more capacity must use a different platform. This figure is the deciding spec for whether the board fits the intended workload.

Highlights

  • Supports 64-bit AMD FX, Phenom II and Athlon II CPUs with Socket AM3+
  • Dual-channel DDR3 1333/1066/800 MHz memory up to 16 GB capacity
  • PCI Express 2.0 x16 slot plus x1 and PCI slots for expansion
  • Realtek ALC887 7-channel audio with intelligent interface detection
  • Realtek RTL8105E Gigabit LAN supporting 10/100 Mb/s speeds

Specifications

BrandMSI
SeriesMSI 760GM-P21(FX)
ModelMSI 760GM-P21(FX)
CPU Socket TypeSocket AM3+
CPU Type64bit AMD FX, Phenom II X6/X4/X3/X2, Athlon II X4/X3/X2 and Sempron CPU.
ChipsetAMD 760G
Memory StandardSupports dual-channel DDR3 1333/1066/800MHz memory
Maximum Memory Supported16GB
PCI Slots1 PCI Express x16 slot supports PCIE 2.0 x 16 speed execution
1 PCI Express x1 slot
1 PCI slot, supports 3.3v/5v PCI main bus interface
SATA RAID4XSATA II interface
Audio ChipsetRealtek ALC887 Chip
- 7-channel sound effects that support intelligent sound interface detection
Compatible with Azalia 1.0 specifications
LAN ChipsetRealtek PCI-E GbLAN Controller RTL8105E Chip
- Support 10Mb/s, 100Mb/s
Compliant with PCI-Express bus specification v1.0a.
Onboard USB6 USB 2.0 ports (backplane)

Questions about this item

Should I pick a board that takes 16GB DDR3 or one limited to 8GB?

This board tops out at 16GB across two slots, so you can install two 8GB DDR3 modules and reach the full capacity.

What does the 1333MHz DDR3 rating mean once the board is running?

The memory controller will run DDR3 at up to 1333MHz in dual-channel mode; faster modules simply drop to that speed.

Does the PCI Express x16 slot run at 2.0 or 1.0 speeds?

The x16 slot operates at PCIe 2.0 x16, while the x1 slot and the PCI slot remain at their standard rates.
