Green Micro ATX motherboard with silver heatsinks and black expansion slots

MSI

MSI 760GM-P33 AMD motherboard Socket AM3 DDR3 8GB Micro ATX

SKU CH-4CW4-VQTWA

Micro-ATX AM3 board with AMD 760G chipset supporting dual-channel DDR3 up to 1600 MHz and 8 GB maximum memory

  • CPU Socket TypeSocket AM3
  • CPU TypeSupports 64-bit AMD Phenom II/Athlon II/Sempron processors
  • ChipsetAMD 760G
  • Memory StandardSupports dual-channel DDR3 1600 (overclocking)/1333/1066/800
  • Maximum Memory Supported8GB
  • PCI Slots1 PCI Express x16 slot, supports PCIE 2.0 x 16 speed executi
  • Supports dual-channel DDR3 up to 1600 MHz for responsive multitasking
  • Socket AM3 fits Phenom II, Athlon II and Sempron CPUs
  • PCIe 2.0 x16 plus two x1 slots give graphics and add-in flexibility
  • Six SATA II ports provide ample drive connectivity
  • Gigabit LAN with 10/100/1000 Mb/s speeds ensures wired network performance

Socket AM3 platform for legacy AMD builds

This Micro ATX motherboard uses the AMD 760G chipset and a Socket AM3 interface to support 64-bit Phenom II, Athlon II and Sempron processors. It targets users maintaining or repairing older systems that require DDR3 memory and classic expansion layouts. The board delivers basic desktop functionality without modern overheads.

Dual-channel DDR3 and mixed PCI Express slots

Four memory slots accept dual-channel DDR3 at 1600 (overclocking), 1333, 1066 or 800 MHz up to a total of 8 GB. Expansion includes one PCI Express x16 slot running at 2.0 x16 speed, two PCI Express x1 slots and one 3.3 V/5 V PCI slot. Six SATA II ports provide storage connectivity while the VIA VT1708S codec enables 8-channel audio and the Atheros AR8131M controller handles 10/100/1000 Mb/s LAN.

Verify CPU cooler clearance

The Micro ATX form factor fits standard chassis but cooler height near the socket area should be confirmed against your case specifications. Only DDR3 DIMMs are compatible; other generations will not seat. Ensure your power supply provides the legacy 24-pin and 4-pin CPU connectors required by this platform.

Highlights

  • Supports dual-channel DDR3 up to 1600 MHz for responsive multitasking
  • Socket AM3 fits Phenom II, Athlon II and Sempron CPUs
  • PCIe 2.0 x16 plus two x1 slots give graphics and add-in flexibility
  • Six SATA II ports provide ample drive connectivity
  • Gigabit LAN with 10/100/1000 Mb/s speeds ensures wired network performance

Specifications

BrandMSI
SeriesMSI 760GM-P33
ModelMSI 760GM-P33
CPU Socket TypeSocket AM3
CPU TypeSupports 64-bit AMD Phenom II/Athlon II/Sempron processors
ChipsetAMD 760G
Memory StandardSupports dual-channel DDR3 1600 (overclocking)/1333/1066/800MHz memory
Maximum Memory Supported8GB
PCI Slots1 PCI Express x16 slot, supports PCIE 2.0 x 16 speed execution
2 PCI Express x1 slots
1 PCI slot, supports 3.3v/5v PCI main bus interface
SATA RAID6XSATA II interface
Audio ChipsetVIA VT1708S Audio Chip
- Supports 8-channel sound effects detected by intelligent sound interface
Compatible with Azalia 1.0 specifications
LAN ChipsetAtheros PCI-E GbLAN Controller AR8131M Chip
- Integrate Fast Ethernet MAC and PHY into a single chip
- Supports 10Mb/s, 100Mb/s and 1000Mb/s
Compliant with PCI-Express bus specification v1.0a.
Onboard USB4 USB 2.0 ports (backplane)

Questions about this item

What speed does the single PCI Express x16 slot actually run at on this MSI 760GM-P33?

The board provides one PCI Express x16 slot that operates at PCIe 2.0 x16 speed, so a graphics card is limited to 2.0 bandwidth even if the card itself supports a newer generation.

What case and power connectors does the Micro ATX MSI 760GM-P33 require?

It uses the standard Micro ATX mounting pattern with a 24-pin ATX power connector and a 4-pin CPU power header; the rear I/O shield is supplied in the box.

How do I install the DDR3 memory on the MSI 760GM-P33 and which slot order should I use?

Insert modules into the two DDR3 slots so they click into the latches; for dual-channel operation populate both slots with matched sticks, otherwise the board runs in single-channel mode.
