Green rectangular ATX motherboard with silver heatsinks, black expansion slots and rear I/O panel

MSI

MSI 770T-C35 AMD motherboard Socket AM2/AM2+ DDR2 16GB ATX

SKU CH-300Q-2FQ56

Supports AMD Phenom, Athlon and Sempron CPUs with dual-channel DDR2 up to 16 GB, one PCI Express x16 2.0 slot, six SATA ports and Realtek gigabit LAN

  • CPU Socket TypeSocket AM2/AM2+
  • CPU TypeSupports AMD Phenom, Athlon and Sempron processors
  • ChipsetAMD 770
  • Memory StandardSupport dual-channel DDR2 1066/800/667/533MHz memory
  • Maximum Memory Supported16GB
  • PCI Slots1 PCI Express x16 slot, supports PCIE 2.0 2 PCI Express x1 s
  • Supports AMD Phenom, Athlon and Sempron CPUs via Socket AM2/AM2+
  • Dual-channel DDR2 up to 1066 MHz for 16 GB maximum memory
  • PCI Express x16 slot with 2.0 support for graphics expansion
  • Realtek ALC889 delivers 8-channel audio with Azalia 1.0 compatibility
  • Realtek 8111DL provides 10/100/1000 Ethernet plus six USB 2.0 ports

Socket AM2/AM2+ platform board

The MSI 770T-C35 is an ATX motherboard built around the AMD 770 chipset for Socket AM2 and AM2+ processors. It accepts AMD Phenom, Athlon and Sempron CPUs and provides dual-channel DDR2 memory support up to 16GB. Six SATA ports, one PCI Express x16 slot, two PCI Express x1 slots and three legacy PCI slots give expansion room for older builds.

Dual-channel DDR2 up to 1066MHz

The board runs dual-channel DDR2 at 1066, 800, 667 or 533MHz with a maximum capacity of 16GB. This memory specification is the single figure that determines whether the board matches an existing CPU and RAM kit. Six SATA 3.3v/5v interfaces and a PCI Express 2.0 x16 slot complete the storage and graphics connectivity.

Passive chipset cooling and modest power draw

The AMD 770 chipset is cooled passively so the board adds no active fan noise. Onboard audio uses the Realtek ALC889 codec with 8-channel output and Azalia 1.0 compliance. Networking is handled by a Realtek 8111DL Gigabit LAN controller. Six USB 2.0 ports on the rear panel provide peripheral connectivity without extra headers.

Highlights

  • Supports AMD Phenom, Athlon and Sempron CPUs via Socket AM2/AM2+
  • Dual-channel DDR2 up to 1066 MHz for 16 GB maximum memory
  • PCI Express x16 slot with 2.0 support for graphics expansion
  • Realtek ALC889 delivers 8-channel audio with Azalia 1.0 compatibility
  • Realtek 8111DL provides 10/100/1000 Ethernet plus six USB 2.0 ports

Specifications

BrandMSI
SeriesMSI 770T-C35
ModelMSI 770T-C35
CPU Socket TypeSocket AM2/AM2+
CPU TypeSupports AMD Phenom, Athlon and Sempron processors
ChipsetAMD 770
Memory StandardSupport dual-channel DDR2 1066/800/667/533MHz memory
Maximum Memory Supported16GB
PCI Slots1 PCI Express x16 slot, supports PCIE 2.0
2 PCI Express x1 slots
3 PCI slots, supporting 3.3v/5v PCI main bus interface
SATA RAID6XSATA II interface
Audio ChipsetRealtek ALC889 Chip
- Supports 8-channel sound effects detected by intelligent sound interface
Compatible with Azalia 1.0 specifications
LAN Chipset1 PCI Express network port supports 10/100/1000 Fast Ethernet provided by Realtek 8111DL
Onboard USB6 USB 2.0 ports (backplane)

Questions about this item

What does the 16GB maximum memory mean for a DDR2 build?

You can populate up to 16GB of dual-channel DDR2 at 1066/800/667/533MHz, giving headroom for memory-heavy legacy applications.

How does the PCIe 2.0 x16 slot limit a modern graphics card?

The slot runs at PCIe 2.0 speeds, so newer cards will operate at that bandwidth ceiling rather than their native 3.0 or 4.0 rates.

What mounting pattern does the ATX board need in the chassis?

Standard ATX screw holes and the included I/O back panel align with any ATX-compatible case.
