Green Micro ATX motherboard with AM3 socket and silver heatsinks

MSI

MSI 785GM-E65 AMD 785G Socket AM3 16GB DDR3 Micro ATX Motherboard

SKU CH-FWES-G0AB1

Socket AM3 board with AMD 785G chipset, dual-channel DDR3 up to 16 GB, one PCI Express x16 2.0 slot, five SATA ports, Realtek GbLAN and 8-channel audio

  • CPU Socket TypeSocket AM3
  • CPU TypeSupport 64bit AMD Phenom II processor
  • ChipsetAMD 785G
  • Memory StandardSupports dual-channel DDR3 1333/1066/800MHz memory
  • Maximum Memory Supported16GB
  • PCI Slots1 PCI Express x16 slot, supports PCIE 2.0 x 16 speed executi
  • Supports up to 16GB dual-channel DDR3 memory for responsive multitasking
  • AMD 785G chipset with integrated graphics handles HD video without a discrete card
  • Realtek 8111DL Gigabit LAN delivers 10/100/1000 wired network speeds
  • Six USB 2.0 ports on the back panel connect keyboards, mice and storage
  • Micro ATX form factor fits compact cases while keeping one PCIe x16 slot

Socket AM3 AMD 785G Micro ATX Board

This motherboard fits Socket AM3 processors such as Phenom II and uses the AMD 785G chipset in a Micro ATX layout. It supports dual-channel DDR3 memory at 1333, 1066 and 800 MHz up to 16 GB total capacity. Integrated graphics are provided by the chipset for systems without a discrete card.

Ideal For Upgrading Older AM3 Systems

Builders replacing a failed board or moving up from a basic AM3 platform will appreciate the onboard Gigabit LAN, six rear USB 2.0 ports and eight-channel audio with Blu-ray sound output. Users needing modern interfaces such as USB 3.0, SATA 6 Gbps or M.2 slots should choose a newer platform instead.

16 GB DDR3 Maximum Memory Limit

The board accepts up to 16 GB of DDR3 across its memory slots, which is the ceiling for this chipset. If your workload requires more memory you must select a different motherboard.

Highlights

  • Supports up to 16GB dual-channel DDR3 memory for responsive multitasking
  • AMD 785G chipset with integrated graphics handles HD video without a discrete card
  • Realtek 8111DL Gigabit LAN delivers 10/100/1000 wired network speeds
  • Six USB 2.0 ports on the back panel connect keyboards, mice and storage
  • Micro ATX form factor fits compact cases while keeping one PCIe x16 slot

Specifications

BrandMSI
SeriesMSI 785GM-E65
ModelMSI 785GM-E65
CPU Socket TypeSocket AM3
CPU TypeSupport 64bit AMD Phenom II processor
ChipsetAMD 785G
Memory StandardSupports dual-channel DDR3 1333/1066/800MHz memory
Maximum Memory Supported16GB
PCI Slots1 PCI Express x16 slot, supports PCIE 2.0 x 16 speed execution
1 PCI Express x1 slot
2 PCI slots, support 3.3v/5v PCI main bus interface
SATA RAID5XSATA II interface
Audio ChipsetRealtek Advanced Sound Chip
- Supports Blu-ray sound output
- 8-channel sound effects that support smart sound interface detection
Compatible with Azalia 1.0 specifications
LAN ChipsetRealtek PCI-E GbLAN Controller 8111DL Chip
Integrate Fast Ethernet MAC and PHY in a single chip
Supports 10Mb/s, 100Mb/s and 1000Mb/s
- Complies with PCI-Express bus specification v1.0a
Onboard USB6 USB 2.0 ports (backplane)

Questions about this item

What case clearance does the Micro ATX board need?

The Micro ATX form factor fits standard mounting holes and the supplied I/O shield; allow room for the 16 GB DDR3 limit and the PCI Express x16 slot length.

Which BIOS step is often missed during first boot?

After seating the CPU and DDR3 modules, enter BIOS to set the memory speed to 1333, 1066 or 800 MHz and enable dual-channel mode before saving.

What onboard part will need replacement over time?

The CMOS battery maintains clock and firmware settings; swap it when the system loses time or reverts BIOS options after power-off.
