Green micro-ATX board with black sockets and silver heatsinks

MSI

MSI 860GM-P43(FX) AMD 760G AM3+ DDR3 16GB Micro ATX Motherboard

SKU CH-FRKT-DNMZ9

Micro ATX board for AM3+ CPUs with AMD 760G chipset, dual-channel DDR3 up to 16GB, PCIe 2.0 x16 slot, six SATA ports, Realtek Gigabit LAN and 8-channel audio

  • CPU Socket TypeSocket AM3+
  • CPU TypeAMD FX/Phenom ™ II/Athlon ™ II/Sempron ™ processors with AM3
  • ChipsetAMD 760G
  • Memory StandardSupports dual-channel DDR3 1333/1066/800MHz memory
  • Maximum Memory Supported16GB
  • PCI Slots1 PCI Express x16 slot supports PCIE 2.0 x 16 speed executio
  • Supports AMD FX, Phenom II, Athlon II and Sempron processors via Socket AM3+
  • AMD 760G chipset provides integrated graphics and platform stability
  • Dual-channel DDR3 memory up to 16 GB at 1333, 1066 or 800 MHz
  • PCI Express 2.0 x16 slot plus x1 and legacy PCI slots for expansion
  • Realtek ALC887 8-channel audio and Realtek 8111E Gigabit LAN for sound and networking

AM3+ Micro-ATX board for legacy AMD builds

The MSI 860GM-P43(FX) uses the AMD 760G chipset on a Socket AM3+ platform. It fits Micro-ATX cases and supports AMD FX, Phenom II, Athlon II and Sempron processors. Dual-channel DDR3 memory runs at 1333, 1066 or 800 MHz up to 16 GB total capacity.

Suits repair or budget upgrades.

This board matches existing AM3+ CPUs and DDR3 modules for low-cost repairs or secondary systems. Builders needing current sockets, newer memory standards or modern I/O should select a different motherboard.

Dual-channel DDR3 1333/1066/800 MHz to 16 GB

Memory support is the key specification: only dual-channel DDR3 at 1333, 1066 or 800 MHz up to 16 GB is compatible. Verify your CPU and RAM match these limits before purchase.

Highlights

  • Supports AMD FX, Phenom II, Athlon II and Sempron processors via Socket AM3+
  • AMD 760G chipset provides integrated graphics and platform stability
  • Dual-channel DDR3 memory up to 16 GB at 1333, 1066 or 800 MHz
  • PCI Express 2.0 x16 slot plus x1 and legacy PCI slots for expansion
  • Realtek ALC887 8-channel audio and Realtek 8111E Gigabit LAN for sound and networking

Specifications

BrandMSI
SeriesMSI 860GM-P43(FX)
ModelMSI 860GM-P43(FX)
CPU Socket TypeSocket AM3+
CPU TypeAMD FX/Phenom ™ II/Athlon ™ II/Sempron ™ processors with AM3 + slots
ChipsetAMD 760G
Memory StandardSupports dual-channel DDR3 1333/1066/800MHz memory
Maximum Memory Supported16GB
PCI Slots1 PCI Express x16 slot supports PCIE 2.0 x 16 speed execution
1 PCI Express x1 slot
1 PCI slot, supports 3.3v/5v PCI main bus interface
SATA RAID6XSATA II interface
Audio ChipsetRealtek ALC887 Chip
- Supports 8-channel sound effects detected by intelligent sound interface
Compatible with Azalia 1.0 specifications
LAN ChipsetRealtek PCI-E GbLAN Controller REL8111E Chip
- Supports 10Mb/s, 100Mb/s and 1000Mb/s
Compliant with PCI-Express bus specification v1.0a.
Onboard USB6 USB 2.0 ports (backplane)

Questions about this item

What DDR3 memory speed must I already have for the board to run at its top 1333 MHz dual-channel rate?

Install two matching DDR3 modules rated at 1333 MHz; the board will then operate in dual-channel mode at that speed, with lower 1066 and 800 MHz modules also supported.

Will my PCI Express 2.0 x16 graphics card work in the single x16 slot without bandwidth loss?

Yes — the slot runs at PCI Express 2.0 x16 speed, so a 2.0 card uses its full width and a 3.0 card simply negotiates down to 2.0 without extra setup.

How can I confirm the Realtek ALC887 audio and REL8111E LAN are active after first boot?

Open Device Manager; both the High Definition Audio Controller and the Gigabit Ethernet Controller should appear without yellow warnings, and the rear panel should show six USB 2.0 ports live.
