Green micro-ATX motherboard with silver heatsinks, black slots and rear I/O panel

MSI

MSI 880GM-E35 AMD 880G DDR3 Micro ATX Motherboard

SKU CH-RT64-04GJN

Micro ATX board for AMD Phenom II and Athlon II CPUs with DDR3 up to 1600 MHz and 16 GB capacity

  • CPU TypeSupports 64-bit AMD Phenom II X6/X4/X3/X2, Athlon II X4/X3/X
  • ChipsetAMD 880G
  • Memory StandardSupports dual-channel DDR3 1600 (overclocking)/1333/1066/800
  • Maximum Memory Supported16GB
  • PCI Slots1 PCI Express x16 slot supports PCIE 2.0 x 16 speed executio
  • SATA RAID6XSATA II interface
  • Supports AMD Phenom II and Athlon II CPUs for versatile desktop builds
  • Dual-channel DDR3 up to 1600MHz overclocking with 16GB maximum capacity
  • AMD 880G chipset with integrated graphics for compact system flexibility
  • Realtek ALC892 8-channel audio and Realtek 8111E Gigabit LAN for rich media and networking
  • One PCIe 2.0 x16 slot, one PCIe x1 and one PCI slot for expansion options

AMD 880G chipset Micro ATX board

The MSI 880GM-E35 uses the AMD 880G chipset on a Micro ATX form factor. It supports 64-bit AMD Phenom II and Athlon II processors. Dual-channel DDR3 memory runs at up to 1600 MHz with overclocking. Maximum capacity is 16 GB across the memory slots.

Suits AM3 upgrades and basic builds

This board suits owners of compatible AM3 processors who need a replacement or a budget platform. Integrated graphics from the 880G chipset handle display output without a discrete card. Builders needing newer CPU sockets, faster memory standards or modern storage interfaces should look at something else.

16 GB DDR3 maximum memory capacity

The single specification that decides fit is the 16 GB DDR3 limit. If the planned system requires more memory or a different memory type, this motherboard will not work. Verify the CPU and memory kit against this ceiling before purchase.

Highlights

  • Supports AMD Phenom II and Athlon II CPUs for versatile desktop builds
  • Dual-channel DDR3 up to 1600MHz overclocking with 16GB maximum capacity
  • AMD 880G chipset with integrated graphics for compact system flexibility
  • Realtek ALC892 8-channel audio and Realtek 8111E Gigabit LAN for rich media and networking
  • One PCIe 2.0 x16 slot, one PCIe x1 and one PCI slot for expansion options

Specifications

BrandMSI
SeriesMSI 880GM-E35
ModelMSI 880GM-E35
CPU TypeSupports 64-bit AMD Phenom II X6/X4/X3/X2, Athlon II X4/X3/X2 and Sempron processors
ChipsetAMD 880G
Memory StandardSupports dual-channel DDR3 1600 (overclocking)/1333/1066/800MHz memory
Maximum Memory Supported16GB
PCI Slots1 PCI Express x16 slot supports PCIE 2.0 x 16 speed execution
1 PCI Express x1 slot
1 PCI slot, supports 3.3v/5v PCI main bus interface
SATA RAID6XSATA II interface
Audio ChipsetRealtek ALC892 Chip
- Supports 8-channel sound effects detected by intelligent sound interface
Compatible with Azalia 1.0 specifications
LAN ChipsetRealtek PCI-E GbLAN Controller REL8111E Chip
- Supports 10Mb/s, 100Mb/s and 1000Mb/s
Compliant with PCI-Express bus specification v1.0a.
Onboard USB6 USB 2.0 ports (backplane)

Questions about this item

Which DDR3 memory speeds does the MSI 880GM-E35 support for its dual-channel controller?

The board runs dual-channel DDR3 at 1600 MHz when overclocked, and at 1333, 1066 or 800 MHz without overclocking, up to a total of 16 GB.

Will a PCI Express 2.0 x16 graphics card operate at full speed in the single x16 slot?

Yes, the sole PCI Express x16 slot is wired for PCIe 2.0 x16 electrical speed, so a 2.0 card will run at its rated bandwidth.

How can I confirm the Realtek ALC892 audio and REL8111E LAN are active after assembly?

In Device Manager both the High Definition Audio Controller and the Gigabit Ethernet Controller should appear without error codes, and the rear panel should provide 8-channel audio output and a 1000 Mb/s link light.
