Green rectangular micro-ATX board with silver CPU socket, two black RAM slots, single PCIe x16 slot, two SATA ports

MSI

MSI A320M PRO-M2 V2 SATA 6Gb/s USB 3.1 HDMI NVME AMD motherboard

SKU CH-JA2F-CCVRH

Micro-ATX AM4 board with two DDR4 slots, one PCIe x16 slot, two SATA ports and USB 3.1

  • CPU TypeRyzen 3000G Series
  • Supports Ryzen 3000G series processors for desktop performance
  • AMD A320 chipset provides stable platform foundation
  • Two DDR4 memory slots up to 32 GB capacity
  • One PCIe 3.0 x16 slot for graphics expansion
  • SATA 6 Gb/s and USB 3.1 ports for fast storage and peripherals

Micro ATX AMD A320 board

This Micro ATX motherboard uses the AMD A320 chipset and an AM4 socket. It is intended for desktop systems running first- to third-generation Ryzen processors. The board provides two DDR4 memory slots with a maximum capacity of 32 GB. Integrated graphics from a compatible APU drive the VGA output on the rear panel.

Verify CPU generation and BIOS version

Confirm that the processor is a first-, second- or third-generation Ryzen part; the board does not support fourth- or fifth-generation CPUs. The installed BIOS is dated 2019-02-01 with version E7B84v31, and a later 2022-11-10 release exists. Ensure the cooler mounting matches the AM4 layout and that the power supply provides the required ATX connectors.

Sustained load on A320 chipset

Under continuous workloads the A320 chipset and VRM area operate within their rated thermal limits for typical office tasks. The two memory slots run in dual-channel mode, maintaining bandwidth during extended sessions. Rear I/O includes USB 2.0 and a single RJ45 LAN port for stable connectivity.

Highlights

  • Supports Ryzen 3000G series processors for desktop performance
  • AMD A320 chipset provides stable platform foundation
  • Two DDR4 memory slots up to 32 GB capacity
  • One PCIe 3.0 x16 slot for graphics expansion
  • SATA 6 Gb/s and USB 3.1 ports for fast storage and peripherals

Specifications

CPU TypeRyzen 3000G Series

Questions about this item

What comes in the box and what must I buy separately?

The package contains one motherboard and one metal I/O shield. No CMOS battery, cables, manual or mounting screws are included; you will need to source those yourself.

Which Ryzen generation should I choose for this A320M PRO-M2 V2?

The board supports first, second and third generation Ryzen CPUs on the AM4 socket. Fourth and fifth generation processors are not supported because the BIOS lacks the required microcode.

What does the 32 GB maximum RAM figure mean once the board is installed?

With two DDR4 slots in dual-channel mode you can install up to 32 GB total, giving the system plenty of headroom for office multitasking and light content creation.
