Green micro-ATX board with silver AM4 socket and four black DDR4 slots

MSI

MSI A320M PRO-V AMD motherboard

SKU CH-Q96G-3M91H

Socket AM4 micro-ATX board supports AMD Ryzen and Athlon CPUs with dual-channel DDR4 up to 32 GB, one PCIe 3.0 x16 slot, two x1 slots, four SATA III ports, Realtek ALC887 7.1 audio and gigabit LAN

  • CPU Socket TypeSocket AM4
  • CPU TypeAMD RYZEN series processors with AM4 pin support, as well as
  • ChipsetAMD A320
  • Memory StandardSupports dual-channel DDR4 1866/2133/2400/2667/2933 (OC)/320
  • Maximum Memory Supported32GB
  • PCI Slots1 PCIe 3.0 x16 slot - RYZEN series processors support x16 mo
  • Supports dual-channel DDR4 up to 3200 MHz for responsive memory performance
  • AM4 socket accepts RYZEN and 7th generation A-series processors for flexible CPU choice
  • 32 GB maximum memory capacity enables smooth multitasking and heavy workloads
  • Realtek ALC887 delivers 7.1 channel audio for immersive sound
  • Realtek 8111H Gigabit LAN provides reliable wired network connectivity

Socket AM4 foundation

The MSI A320M PRO-V is a micro ATX motherboard built around the AMD A320 chipset and the Socket AM4 platform. It accepts RYZEN series processors and 7th generation A series or Athlon CPUs, making it a direct fit for budget desktop builds. The board ships with a CMOS battery, one SATA cable and an I/O back panel.

DDR4 memory ceiling

Dual-channel DDR4 runs at 1866, 2133, 2400, 2667, 2933 (OC) and 3200 (OC) MHz, but the chipset caps usable capacity at 32 GB across two slots. Four SATA III ports provide storage connectivity, while the Realtek ALC887 codec delivers 7.1 channel audio and a Realtek 8111H controller handles Gigabit LAN.

PCIe lane allocation

The single PCIe 3.0 x16 slot operates at x16 with RYZEN CPUs and drops to x8 with 7th generation A series or Athlon chips. Two additional PCIe 3.0 x1 slots remain available for add-in cards. Rear I/O includes four USB 3.1 Gen1 ports and two USB 2.0 ports, with headers for two more USB 3.1 Gen1 and four USB 2.0 connections.

Highlights

  • Supports dual-channel DDR4 up to 3200 MHz for responsive memory performance
  • AM4 socket accepts RYZEN and 7th generation A-series processors for flexible CPU choice
  • 32 GB maximum memory capacity enables smooth multitasking and heavy workloads
  • Realtek ALC887 delivers 7.1 channel audio for immersive sound
  • Realtek 8111H Gigabit LAN provides reliable wired network connectivity

Specifications

BrandMSI
SeriesMSI A320M PRO-V
ModelMSI A320M PRO-V
CPU Socket TypeSocket AM4
CPU TypeAMD RYZEN series processors with AM4 pin support, as well as 7th generation A series/Athlon processors
ChipsetAMD A320
Memory StandardSupports dual-channel DDR4 1866/2133/2400/2667/2933 (OC)/3200 (OC) MHz memory
Maximum Memory Supported32GB
PCI Slots1 PCIe 3.0 x16 slot
- RYZEN series processors support x16 mode
7th generation A-series/Athlon processors support x8 mode
2 PCIe 3.0 x1 slots
SATA RAID4XSATA III interface
Audio ChipsetRealtek ALC887 decoding chip
- 7.1 channel high-quality sound effects
LAN Chipset1 Realtek 8111H Gigabit network interface card
Onboard USBAMD A320 chipset
- 6 USB 3.1 Gen1 (SuperSpeed USB) ports (4 ports on the backplane, 2 ports provided via onboard USB ports)
- 6 USB 2.0 (High-speed USB) interfaces (2 interfaces located on the backplane, 4 interfaces provided through the onboard USB interface)

Questions about this item

Should I pick the 32GB DDR4 limit or plan for less?

The board supports up to 32GB of dual-channel DDR4, so two 16GB modules fill the limit while lower capacities leave room for future upgrades.

What does the 3200 (OC) MHz memory rating deliver in a real build?

With a RYZEN CPU the board can run DDR4 at 3200 MHz when overclocked, giving higher bandwidth than the base 2133/2400 speeds for gaming and multitasking.

How does the PCIe 3.0 x16 slot behave with different CPUs?

RYZEN series processors run the slot at x16 mode while 7th generation A-series and Athlon CPUs drop it to x8 mode, capping graphics-card bandwidth accordingly.
