Green rectangular Micro ATX board with silver AM4 socket and four black DDR4 slots

MSI

MSI A520M PRO AMD motherboard Socket AM4 DDR4 64GB Micro ATX

SKU CH-VCBJ-YDTFH

A Socket AM4 micro-ATX board supporting Ryzen 3000, 4000G and 5000 series CPUs with dual-channel DDR4 up to 4600 MHz and 64 GB capacity

  • CPU Socket TypeSocket AM4
  • CPU TypeSupports 3rd generation AMD Ryzen desktop processors and AMD
  • ChipsetAMD A520
  • Memory StandardSupport Dual-Channel DDR4 1866/2133/2400/2667/2800/2933/3000
  • Maximum Memory Supported64GB
  • PCI Slots1 PCIe 3.0 x1 slot 1 PCIe x16 slot Support x16 speed through
  • Supports Ryzen 3000, 4000G and 5000 series processors via Socket AM4
  • Dual-channel DDR4 memory up to 64GB with speeds from 1866 to 4600+ MHz
  • PCIe 3.0 x16 slot runs at x16 with Ryzen 5000, 5000G, 4000G and 3000 CPUs
  • Four SATA III ports and one M.2 interface for storage expansion
  • Realtek ALC892/897 audio and RTL8111H gigabit LAN for connectivity

Socket AM4 DDR4 platform

The MSI A520M PRO is a Micro ATX motherboard built around the AMD A520 chipset. It accepts third-generation Ryzen desktop processors and Ryzen 4000 G-series desktop processors in the AM4 socket. Dual-channel DDR4 memory runs at speeds from 1866 up to 4600 MHz with a 64GB maximum capacity. A single PCIe 3.0 x16 slot and one PCIe 3.0 x1 slot provide expansion room.

Suited for value Ryzen builds

This board suits builders pairing a Ryzen 5000, 5000G, 4000G or 3000 series CPU with a single graphics card and SATA storage. The x16 link operates at full speed with those processors, while a Ryzen 3000G processor drops the slot to x8 speed. Users needing multiple M.2 drives, additional PCIe lanes or integrated Wi-Fi should look at a different chipset.

Steady operation under load

The Realtek RTL8111H gigabit LAN controller and Realtek ALC892/ALC897 audio codecs handle continuous network traffic and audio streaming without extra hardware. Four SATA III ports and one M.2 interface keep storage bandwidth available during extended file transfers. Six USB 2.0 ports and two USB 3.2 Gen 1 5Gbps ports maintain peripheral connectivity throughout long sessions.

Highlights

  • Supports Ryzen 3000, 4000G and 5000 series processors via Socket AM4
  • Dual-channel DDR4 memory up to 64GB with speeds from 1866 to 4600+ MHz
  • PCIe 3.0 x16 slot runs at x16 with Ryzen 5000, 5000G, 4000G and 3000 CPUs
  • Four SATA III ports and one M.2 interface for storage expansion
  • Realtek ALC892/897 audio and RTL8111H gigabit LAN for connectivity

Specifications

BrandMSI
SeriesMSI A520M PRO
ModelMSI A520M PRO
CPU Socket TypeSocket AM4
CPU TypeSupports 3rd generation AMD Ryzen desktop processors and AMD Ryzen 4000 G series desktop processors
ChipsetAMD A520
Memory StandardSupport Dual-Channel DDR4 1866/2133/2400/2667/2800/2933/3000/3066/3200/3466/3733/3866/4000/4133/4266/4400/4600 + MHz memory
Maximum Memory Supported64GB
PCI Slots1 PCIe 3.0 x1 slot
1 PCIe x16 slot
Support x16 speed through Ryzen 5000, 5000G, 4000G, and 3000 processors
Support x8 speed through Ryzen 3000G processor
AMD Athlon supports x4 speeds through Radeon graphics processors
SATA RAID1XM.2 interface, 4xSATA III interface
Audio ChipsetRealtek ALC892/ALC897 Codecs
LAN Chipset1 Realtek RTL8111H gigabit network interface card
Onboard USBAMD A520 chipset
2 USB 3.2 Gen 1 5Gbps ports available via on-board USB 3.2 Gen1 5Gbps connector
6 USB 2.0 ports (2 Type-A ports on the backplane, 4 ports available via onboard USB 2.0 connector)
AMD processor
4 USB 3.2 Gen 1 5Gbps Type-A ports on the backplane

Questions about this item

What CPU and memory do I need to run this MSI A520M PRO motherboard?

Install a 3rd-generation Ryzen desktop processor or a Ryzen 4000 G-series processor in the Socket AM4 socket, and add up to 64 GB of DDR4 modules running at speeds from 1866 MHz up to 4600 MHz in dual-channel mode.

Will my existing Radeon graphics card and SATA drives work with the PCIe and storage interfaces on this board?

The board provides one PCIe 3.0 x16 slot that runs at x16 speed with Ryzen 5000, 5000G, 4000G and 3000 processors, plus one M.2 interface and four SATA III ports for your current drives.

How can I confirm the Realtek audio and gigabit LAN are active after I build the system?

In Windows Device Manager, verify that the Realtek ALC892 or ALC897 audio codec and the Realtek RTL8111H gigabit network adapter both appear without error icons.
