Green ATX motherboard with black sockets and silver heatsinks

MSI

MSI A68H PC MATE AMD Motherboard Socket FM1 DDR3 32GB ATX

SKU CH-7PDB-VVKN2

ATX motherboard with FM1 socket, dual-channel DDR3 up to 2133MHz, 32GB max RAM, two PCIe x16 slots and four SATA ports

  • CPU Socket TypeSocket FM1
  • CPU TypeSupport AMD socket FM2 +/FM2 A series/Athlon processor
  • ChipsetAMD A68H
  • Memory StandardSupport dual-channel DDR3 1333/1600/1866/2133MHz memory
  • Maximum Memory Supported32GB
  • PCI Slots2 PCIe x16 slots - PCI_E2 supports PCIe 3.0 x16 speeds * - P
  • Supports up to 32GB dual-channel DDR3 memory for multitasking headroom
  • Two PCIe x16 slots plus three legacy PCI slots for expansion flexibility
  • Four SATA III ports enable fast storage arrays
  • Realtek ALC887 codec delivers clear onboard audio
  • Realtek RTL8111E provides Gigabit LAN connectivity

AMD A68H Socket FM1 Board

This ATX motherboard uses the AMD A68H chipset and accepts Socket FM1 processors. It is aimed at builders assembling a budget desktop or replacing a board in an existing FM1 system. Dual-channel DDR3 support and a full set of legacy slots make it practical for general-purpose use.

Check CPU socket and memory

Verify that your processor fits Socket FM1 and that you have DDR3 modules rated for 1333, 1600, 1866 or 2133 MHz. The board provides four memory slots with a 32 GB maximum capacity. Ensure your case can accommodate an ATX form factor and that your power supply has the required ATX connectors.

Bundled cables and I/O shield

The package includes one SATA cable for connecting a drive, a CMOS battery for the real-time clock, and a chassis I/O back panel for the rear ports. No additional adapters, Wi-Fi antenna or software discs are supplied.

Highlights

  • Supports up to 32GB dual-channel DDR3 memory for multitasking headroom
  • Two PCIe x16 slots plus three legacy PCI slots for expansion flexibility
  • Four SATA III ports enable fast storage arrays
  • Realtek ALC887 codec delivers clear onboard audio
  • Realtek RTL8111E provides Gigabit LAN connectivity

Specifications

BrandMSI
SeriesMSI A68H PC MATE
ModelMSI A68H PC MATE
CPU Socket TypeSocket FM1
CPU TypeSupport AMD socket FM2 +/FM2 A series/Athlon processor
ChipsetAMD A68H
Memory StandardSupport dual-channel DDR3 1333/1600/1866/2133MHz memory
Maximum Memory Supported32GB
PCI Slots2 PCIe x16 slots
- PCI_E2 supports PCIe 3.0 x16 speeds *
- PCI_E4 supports PCIe 2.0 x4 speeds
2 PCIe 2.0 x1 slots
3 PCI slots
SATA RAID4XSATA III interface
Audio ChipsetRealtek ALC887 Decoder Chip
LAN ChipsetRealtek RTL8111E Gigabit network interface card
Onboard USB2 USB 3.0 ports located on the back panel
10 USB 2.0 ports (4 on the backplane, 6 supported through built-in USB ports)

Questions about this item

What comes in the box with the MSI A68H PC MATE motherboard?

The package includes the motherboard, a CMOS battery, one SATA cable and the chassis I/O back panel.

Which DDR3 memory speeds does the MSI A68H PC MATE support?

The board supports dual-channel DDR3 at 1333, 1600, 1866 and 2133 MHz, up to a maximum of 32 GB.

What does the 32 GB maximum memory mean for a working system?

You can install up to 32 GB of DDR3 across the dual-channel slots for the full capacity the chipset allows.
