Green micro-ATX board with black sockets and silver heatsinks

MSI

MSI A68HM-E33 AMD motherboard Socket FM1 32GB DDR3 Micro ATX

SKU CH-MQ8T-1FBZ6

Micro-ATX board for Socket FM1 APUs with dual-channel DDR3 up to 32 GB, one PCIe 3.0 x16 slot, four SATA ports and Realtek gigabit LAN

  • CPU Socket TypeSocket FM1
  • CPU TypeAMD A-series/Athlon processors with FM2 + architecture
  • ChipsetAMD A68H
  • Memory StandardSupports dual-channel DDR3 1333/1600/1866/2133 (OC) MHz memo
  • Maximum Memory Supported32GB
  • PCI Slots1 x PCIe 3.0 x16 slot 1 x PCIe 2.0 x1 slot 1 x PCI slot
  • Supports dual-channel DDR3 up to 2133 MHz for responsive multitasking
  • AMD A68H chipset enables FM2+ architecture CPU compatibility
  • Realtek ALC887 audio chip delivers clear onboard sound
  • Realtek RTL8111G gigabit LAN provides wired network connectivity
  • Four SATA III ports plus one PCIe 3.0 x16 slot for storage and graphics expansion

Socket FM1 platform for AMD A-series builds

The MSI A68HM-E33 is a micro-ATX motherboard built around the AMD A68H chipset for Socket FM1 processors. It supports dual-channel DDR3 memory up to 32 GB at speeds of 1333, 1600, 1866 or 2133 MHz when overclocked. The board provides one PCIe 3.0 x16 slot, one PCIe 2.0 x1 slot and a legacy PCI slot for expansion cards.

Budget upgrade or repair for FM1 systems

This board suits owners of existing FM1 APUs who need a replacement or a low-cost foundation for a basic desktop. Integrated Realtek ALC887 audio and RTL8111G gigabit LAN cover everyday sound and networking without extra cards. Builders targeting newer sockets, higher memory capacity or modern storage interfaces should select a current-platform motherboard instead.

32 GB DDR3 ceiling defines the upgrade limit

The maximum supported memory is 32 GB across two dual-channel slots using DDR3 modules. If your workload demands more than 32 GB this platform cannot meet that requirement and another motherboard is necessary.

Highlights

  • Supports dual-channel DDR3 up to 2133 MHz for responsive multitasking
  • AMD A68H chipset enables FM2+ architecture CPU compatibility
  • Realtek ALC887 audio chip delivers clear onboard sound
  • Realtek RTL8111G gigabit LAN provides wired network connectivity
  • Four SATA III ports plus one PCIe 3.0 x16 slot for storage and graphics expansion

Specifications

BrandMSI
SeriesMSI A68HM-E33
ModelMSI A68HM-E33
CPU Socket TypeSocket FM1
CPU TypeAMD A-series/Athlon processors with FM2 + architecture
ChipsetAMD A68H
Memory StandardSupports dual-channel DDR3 1333/1600/1866/2133 (OC) MHz memory
Maximum Memory Supported32GB
PCI Slots1 x PCIe 3.0 x16 slot
1 x PCIe 2.0 x1 slot
1 x PCI slot
SATA RAID4XSATA III interface
Audio ChipsetRealtek ALC887 Audio Chip
LAN ChipsetRealtek RTL8111G Gigabit Network Controller
Onboard USB2 USB 3.0 ports located on the back panel
6 USB 2.0 ports (2 on the back panel, 4 supported through built-in USB ports)

Questions about this item

Does the 32 GB DDR3 limit mean I must replace the board to go beyond that?

The board caps at 32 GB of DDR3 across two channels, so any upgrade past that requires a different motherboard.

Which slot or interface hits its ceiling first during long heavy loads?

The single PCIe 3.0 x16 lane and four SATA ports set the practical throughput ceiling under sustained work.

How loud or hot does the Realtek ALC887 and RTL8111G run when the system stays on all day?

Both chips are low-power controllers; they add minimal heat and no audible noise during continuous operation.
