Green Micro ATX motherboard with black PCIe slots and silver CPU socket

MSI

MSI A68HM-P33 v2 AMD motherboard FM2+ DDR3 32GB Micro ATX

SKU CH-41X4-JPVTA

Micro-ATX board for FM2+ APUs with dual-channel DDR3 up to 32 GB, one PCIe 3.0 x16 slot, four SATA ports, 8.1-channel Realtek audio and Gigabit LAN

  • CPU Socket TypeFM2+
  • CPU TypeSupport FM2 + socket AMD A series/Athlon series processors
  • ChipsetAMD A68H
  • Memory Standard2 DDR3 memory slots supporting up to 32GB Memory, supports D
  • Maximum Memory Supported32GB
  • PCI Slots1 PCIe 3.0 x16 slot * 1 PCIe 2.0 x1 slot 1 PCI slot
  • Supports AMD A-Series and Athlon CPUs via FM2+ socket
  • Up to 32GB DDR3 memory across two slots with dual-channel architecture
  • Memory speeds up to 2133 (OC) / 1866 / 1600 / 1333 MHz with AMD Memory Profile support
  • 1-channel audio from Realtek ALC887 codec with Azalia 1.0 compatibility
  • PCIe 3.0 x16, PCIe 2.0 x1 and legacy PCI expansion slots plus four SATA III ports

FM2+ AMD A68H board for budget builds

This Micro ATX motherboard fits FM2+ socket AMD A-Series and Athlon processors on the AMD A68H chipset. It provides two DDR3 slots that accept up to 32GB of memory in dual-channel mode. The board includes one PCIe 3.0 x16 slot, one PCIe 2.0 x1 slot and one legacy PCI slot for expansion cards.

Steady operation with DDR3 2133 OC headroom

Memory runs at 1333, 1600, 1866 or 2133 MHz when overclocked, giving headroom for sustained workloads. Four SATA III ports support RAID 0, 1, 5 and 10 arrays for redundant or striped storage. Realtek RTL8111G LAN and Realtek ALC887 8.1-channel audio handle network and sound duties without extra cards.

Replaces older FM2 boards with native USB 3.0

The A68H chipset adds native USB 3.0 on the rear panel, removing the need for third-party controllers found on earlier FM2 designs. Two rear USB 3.0 ports and six USB 2.0 ports (two rear, four internal) cover modern peripherals. The upgrade is worthwhile when moving from a board that lacks SATA III or USB 3.0 support.

Highlights

  • Supports AMD A-Series and Athlon CPUs via FM2+ socket
  • Up to 32GB DDR3 memory across two slots with dual-channel architecture
  • Memory speeds up to 2133 (OC) / 1866 / 1600 / 1333 MHz with AMD Memory Profile support
  • 1-channel audio from Realtek ALC887 codec with Azalia 1.0 compatibility
  • PCIe 3.0 x16, PCIe 2.0 x1 and legacy PCI expansion slots plus four SATA III ports

Specifications

BrandMSI
SeriesMSI A68HM-P33 v2
ModelMSI A68HM-P33 v2
CPU Socket TypeFM2+
CPU TypeSupport FM2 + socket AMD A series/Athlon series processors
ChipsetAMD A68H
Memory Standard2 DDR3 memory slots supporting up to 32GB
Memory, supports DDR3 2133 (OC)/1866/1600/1333 MHz
Dual-channel memory architecture
Support non-ECC, non-buffered memory
Support for AMD Memory Profile (AMP)
Support for Extreme Memory Profile (XMP)
Maximum Memory Supported32GB
PCI Slots1 PCIe 3.0 x16 slot *
1 PCIe 2.0 x1 slot
1 PCI slot
SATA RAID4XSATA III interface
Audio ChipsetRealtek ALC887 Decoder Chip
Support intelligent audio interface needle-measured 8.1 channel sound effects
Compatible with Azalia 1.0 specification
LAN ChipsetRealtek RTL8111G network interface card
Onboard USB2 USB 3.0 ports located on the back panel
6 USB 2.0 ports (2 on the back panel, 4 supported through built-in USB ports)

Questions about this item

How much power does the MSI A68HM-P33 v2 draw when the system runs all day?

The board uses the AMD A68H chipset with two DDR3 slots and a single PCIe 3.0 x16 slot, so idle power is low and scales with the chosen FM2+ processor and memory kit.

Which memory kit must I already own for this motherboard to work?

You need non-ECC, non-buffered DDR3 DIMMs running at 1333, 1600, 1866 or 2133 (OC) MHz; the two slots support up to 32 GB in dual-channel mode.

Will my older PCI expansion card fit alongside the PCIe 3.0 x16 slot on this board?

Yes, the layout includes one legacy PCI slot, one PCIe 2.0 x1 slot and one PCIe 3.0 x16 slot, so a PCI card can be installed at the same time.
