Green Mini-ITX board with silver PCIe slot and black I/O shield

MSI

MSI B150I GAMING PRO Intel B150 motherboard 32GB DDR4

SKU CH-P2MM-08G9K

Mini-ITX board with LGA 1151 socket, dual-channel DDR4 2133MHz up to 32GB, one PCIe 3.0 x16 slot, M.2 and four SATA ports, Realtek ALC887 7.1 audio and RTL8111H Gigabit LAN

  • CPU Socket TypeLGA 1151
  • CPU Type6th Gen Intel Core & trade i3/i5/i7, Intel Pentium/Celeron p
  • ChipsetIntel B150
  • Memory StandardSupports dual-channel DDR4 2133MHz memory
  • Maximum Memory Supported32GB
  • PCI Slots1 PCIe 3.0 x16 slot
  • LGA 1151 socket fits 6th Gen Intel Core i3 i5 i7 and Pentium Celeron CPUs
  • Dual-channel DDR4 2133MHz support up to 32GB maximum memory capacity
  • Intel B150 chipset provides one PCIe 3.0 x16 slot for graphics expansion
  • Realtek ALC887 codec delivers 7.1 channel high-definition audio output
  • Realtek RTL8111H controller supplies gigabit LAN plus four USB 3.1 Gen1 and six USB 2.0 ports

Compact LGA 1151 platform

This Mini-ITX board pairs the Intel B150 chipset with an LGA 1151 socket for 6th Gen Core i3, i5 and i7 processors plus Pentium and Celeron models. It targets builders who need a small-footprint foundation for a home or office system. The dual-channel memory controller accepts up to 32 GB of DDR4 2133 MHz RAM.

Interface limits in practice

Storage connects through one M.2 interface and four SATA III ports, while expansion relies on a single PCIe 3.0 x16 slot. Networking uses a Realtek RTL8111H Gigabit LAN controller. The rear I/O supplies two USB 3.1 Gen1 ports and four USB 2.0 ports, with two more of each available via onboard headers.

Installation notes

The compact layout keeps the CPU socket clear for most low-profile coolers, though tall memory modules can interfere with larger heatsinks. Front-panel headers sit along the bottom edge and follow the standard pin-out, so miswiring is the most common issue. Audio uses a Realtek ALC887 codec for 7.1 channel output, and a CMOS battery plus one SATA cable are included in the box.

Highlights

  • LGA 1151 socket fits 6th Gen Intel Core i3 i5 i7 and Pentium Celeron CPUs
  • Dual-channel DDR4 2133MHz support up to 32GB maximum memory capacity
  • Intel B150 chipset provides one PCIe 3.0 x16 slot for graphics expansion
  • Realtek ALC887 codec delivers 7.1 channel high-definition audio output
  • Realtek RTL8111H controller supplies gigabit LAN plus four USB 3.1 Gen1 and six USB 2.0 ports

Specifications

BrandMSI
SeriesMSI B150I GAMING PRO
ModelMSI B150I GAMING PRO
CPU Socket TypeLGA 1151
CPU Type6th Gen Intel Core & trade i3/i5/i7, Intel Pentium/Celeron processors with LGA1151 support
ChipsetIntel B150
Memory StandardSupports dual-channel DDR4 2133MHz memory
Maximum Memory Supported32GB
PCI Slots1 PCIe 3.0 x16 slot
SATA RAID1XM.2 interface, 4xSATA III interface
Audio ChipsetRealtek ALC887 Decoder Chip
- 7.1 channel high-quality sound effects
LAN Chipset1 Realtek RTL8111H Gigabit LAN Controller
Onboard USB- 4 USB 3.1 Gen1 (SuperSpeed USB) ports (2 on the back panel, 2 via onboard USB connectors)
- 6 USB 2.0 (High-speed USB) ports (4 on the backplane, 2 via onboard USB connectors)

Questions about this item

Should I choose 16 GB or 32 GB of DDR4 for this board?

The board supports dual-channel DDR4 at 2133 MHz up to 32 GB, so 32 GB uses the full capacity while 16 GB leaves room for later upgrades.

What does the 2133 MHz DDR4 rating mean once the board is running?

Memory will operate at 2133 MHz in dual-channel mode; installed modules rated higher will downclock to this speed.

How fast is the M.2 interface on this board in practice?

The single M.2 slot connects through the B150 chipset using SATA bandwidth, limiting drives to SATA III speeds.
