Green Micro ATX motherboard with black PCIe slots and silver LGA 1151 socket

MSI

MSI B150M BAZOOKA Intel B150 motherboard

SKU CH-EDNQ-F1T91

Micro-ATX board for 6th generation Intel Core processors with LGA 1151 socket, dual-channel DDR4 2133MHz memory up to 64GB, 7.1-channel Realtek ALC887 audio and Realtek RTL8111H gigabit LAN

  • CPU Socket TypeLGA 1151
  • CPU Type6th generation Intel Core i3/i5/i7, Pentium/Celeron processo
  • ChipsetIntel B150
  • Memory StandardSupports dual-channel DDR4 2133MHz memory
  • Maximum Memory Supported64GB
  • PCI Slots1 PCIe 3.0 x16 slot 2 PCIe 3.0 x1 slots
  • Supports 6th generation Intel Core i3/i5/i7 processors via LGA 1151 socket
  • Dual-channel DDR4 2133MHz memory up to 64GB maximum capacity
  • One PCIe 3.0 x16 slot plus two PCIe 3.0 x1 slots for expansion
  • Realtek ALC887 codec delivers 7.1 channel high-quality audio output
  • Six USB 3.1 Gen1 and six USB 2.0 ports provide extensive connectivity

MSI B150M BAZOOKA LGA 1151 Motherboard

This Micro ATX board uses the Intel B150 chipset and fits 6th generation Core i3, i5, i7, Pentium or Celeron processors in an LGA 1151 socket. It supports dual-channel DDR4 memory at 2133MHz up to a total of 64GB. The layout provides one PCIe 3.0 x16 slot and two PCIe 3.0 x1 slots for expansion cards.

Entry builds and basic upgrades

Buyers assembling a budget office PC or refreshing an older LGA 1151 system will find the board’s six SATA III ports, one SATA Express connector and 7.1-channel Realtek ALC887 audio adequate. A Realtek RTL8111H gigabit LAN port handles wired networking. Enthusiasts needing more than one full-length PCIe 3.0 x16 slot or newer CPU generations should consider a different platform.

Maximum memory capacity is 64GB

Four DDR4 slots accept up to 64GB in total, so the decision hinges on whether that ceiling meets the planned workload. If the target system requires more memory than 64GB, this motherboard cannot satisfy it.

Highlights

  • Supports 6th generation Intel Core i3/i5/i7 processors via LGA 1151 socket
  • Dual-channel DDR4 2133MHz memory up to 64GB maximum capacity
  • One PCIe 3.0 x16 slot plus two PCIe 3.0 x1 slots for expansion
  • Realtek ALC887 codec delivers 7.1 channel high-quality audio output
  • Six USB 3.1 Gen1 and six USB 2.0 ports provide extensive connectivity

Specifications

BrandMSI
SeriesMSI B150M BAZOOKA
ModelMSI B150M BAZOOKA
CPU Socket TypeLGA 1151
CPU Type6th generation Intel Core i3/i5/i7, Pentium/Celeron processors with LGA1151 architecture
ChipsetIntel B150
Memory StandardSupports dual-channel DDR4 2133MHz memory
Maximum Memory Supported64GB
PCI Slots1 PCIe 3.0 x16 slot
2 PCIe 3.0 x1 slots
SATA RAID1xSATA Express interface, 6xSATA III interface
Audio ChipsetRealtek ALC887 Decoder Chip
7.1 channel high-quality sound effects
LAN Chipset1 Realtek RTL8111H gigabit network interface card
Onboard USBIntel B150 chipset
- 6 USB 3.1 Gen1 (SuperSpeed USB) ports (4 on the backplane, 2 via onboard USB ports)
- 6 USB 2.0 (High-speed USB) ports (2 on the backplane, 4 via onboard USB ports)

Questions about this item

How hot or loud does the MSI B150M BAZOOKA get when running all day?

The board uses the Intel B150 chipset with standard passive cooling; no onboard fan is fitted, so noise depends entirely on the CPU cooler and case airflow you install.

What other parts must I already own for the MSI B150M BAZOOKA to work?

You need an LGA 1151 processor from the 6th generation Core i3, i5, i7, Pentium or Celeron lines, plus DDR4 2133MHz modules up to 64GB total.

Will my existing SATA drives and PCIe cards work with the MSI B150M BAZOOKA?

Yes — the board provides six SATA III ports and one SATA Express interface, plus one PCIe 3.0 x16 slot and two PCIe 3.0 x1 slots for older expansion cards.
