Green Micro ATX motherboard with black sockets and silver heatsinks

MSI

MSI B150M PRO-VD Intel B150 LGA 1151 DDR4 32GB Micro ATX Intel motherboard

SKU CH-1CHM-DEX6E

Supports 6th generation Intel Core i3, i5, i7, Pentium and Celeron processors on LGA 1151 socket with dual-channel DDR4 2133MHz memory up to 32GB

  • CPU Socket TypeLGA 1151
  • CPU TypeSupports 6th generation LGA1151 architecture Intel Core i3/i
  • ChipsetIntel B150
  • Memory StandardSupports dual-channel DDR4 2133MHz memory
  • Maximum Memory Supported32GB
  • PCI Slots1 PCIe 3.0 x 16 slot 2 PCIe 3.0 x 1 slots
  • Supports 6th-gen Intel Core i3/i5/i7 on LGA 1151 socket
  • Dual-channel DDR4 2133MHz memory up to 32GB capacity
  • Micro ATX form factor measuring 23.6 by 20.0 cm
  • Six SATA III ports plus one PCIe 3.0 x16 and two PCIe 3.0 x1 slots
  • Realtek ALC887 7.1 channel audio with RTL8111H Gigabit LAN

Intel B150 Micro ATX Motherboard

The MSI B150M PRO-VD is an Intel B150 chipset motherboard built for the LGA 1151 socket. It accepts 6th generation Core i3, i5, i7, Pentium and Celeron processors in a compact Micro ATX form factor. The board supports dual-channel DDR4 memory at 2133MHz up to a maximum of 32GB capacity.

Home and Office Builders

This board suits users assembling a general-purpose desktop for everyday productivity, media playback or light multitasking. The single PCIe 3.0 x16 slot accommodates one graphics card, while six SATA III ports provide storage flexibility. Enthusiasts needing multiple GPUs, overclocking features or more than two memory slots should consider a different chipset.

Sustained Operation

Under continuous load the B150 chipset runs within its rated thermal envelope without active cooling on the heatsink. The Realtek ALC887 audio codec and RTL8111H Gigabit LAN controller maintain stable performance during extended sessions. Power delivery is designed for the supported 6th generation processor TDP range, so voltage regulation remains consistent during prolonged workloads.

Highlights

  • Supports 6th-gen Intel Core i3/i5/i7 on LGA 1151 socket
  • Dual-channel DDR4 2133MHz memory up to 32GB capacity
  • Micro ATX form factor measuring 23.6 by 20.0 cm
  • Six SATA III ports plus one PCIe 3.0 x16 and two PCIe 3.0 x1 slots
  • Realtek ALC887 7.1 channel audio with RTL8111H Gigabit LAN

Specifications

BrandMSI
SeriesMSI B150M PRO-VD
ModelMSI B150M PRO-VD
CPU Socket TypeLGA 1151
CPU TypeSupports 6th generation LGA1151 architecture Intel Core i3/i5/i7, Intel Pentium, Celeron processors
ChipsetIntel B150
Memory StandardSupports dual-channel DDR4 2133MHz memory
Maximum Memory Supported32GB
PCI Slots1 PCIe 3.0 x 16 slot
2 PCIe 3.0 x 1 slots
SATA RAID6XSATA III interface
Audio ChipsetRealtek ALC887 Decoder Chip
7.1 channel high-quality sound effects
LAN Chipset1 Realtek RTL8111H Gigabit LAN Controller
Onboard USB6 USB 3.1 Gen1 (SuperSpeed USB) ports (4 on the backplane, 2 via onboard USB ports)
- 6 USB 2.0 (High-speed USB) ports (2 on the backplane, 4 via onboard USB ports)

Questions about this item

Which DDR4 memory speed and maximum capacity does the MSI B150M PRO-VD support?

The board runs dual-channel DDR4 at 2133 MHz and accepts up to 32 GB total across its two slots.

Will my existing SATA drives and PCIe add-in cards work with the B150 chipset on this board?

Yes — six SATA III ports and one PCIe 3.0 x16 plus two PCIe 3.0 x1 slots are provided for current drives and expansion cards.

How can I confirm the Realtek ALC887 audio and RTL8111H LAN are active after the build?

Device Manager should list Realtek High Definition Audio and Realtek PCIe GBE Family Controller without error codes.
