Green Micro ATX motherboard with black LGA 1151 socket, silver heatsinks and blue DDR4 slots

MSI

MSI B250M-F Intel B250 LGA 1151 DDR4 32GB Micro ATX Intel motherboard

SKU CH-TACF-9C0KC

Micro-ATX board with LGA 1151 socket, dual-channel DDR4 up to 32 GB, six SATA III ports, one M.2 slot, Realtek ALC887 7.1 audio and Gigabit LAN

  • CPU Socket TypeLGA 1151
  • CPU TypeSupports 6th/7th generation Intel Core i3/i5/i7 processors,
  • ChipsetIntel B250
  • Memory StandardSupports dual-channel DDR4 2400/2133MHz memory
  • Maximum Memory Supported32GB
  • PCI Slots1 PCIe 3.0 x16 slot 2 PCIe 3.0 x1 slots
  • Supports 6th/7th gen Intel Core, Pentium and Celeron CPUs on LGA 1151 socket
  • Dual-channel DDR4 up to 2400 MHz with 32 GB maximum capacity
  • One PCIe 3.0 x16 slot plus two PCIe 3.0 x1 slots for expansion
  • Realtek ALC887 codec delivers 7.1 channel audio
  • Realtek RTL8111H provides Gigabit LAN connectivity

Intel B250 Micro ATX Motherboard

The MSI B250M-F is a Micro ATX board built on the Intel B250 chipset for LGA 1151 processors. It supports 6th and 7th generation Intel Core i3, i5, i7, Pentium and Celeron CPUs. Dual-channel DDR4 memory runs at 2400 or 2133 MHz up to 32 GB total capacity. The board measures 23.6 by 20.0 cm.

Maximum 32 GB DDR4 Capacity

The board accepts two DDR4 modules with a combined limit of 32 GB at 2400 or 2133 MHz. Exceeding this amount will prevent the system from posting. Verify your kit matches the supported speeds and total capacity before ordering.

Straightforward Installation

The package includes the motherboard, one SATA cable and a rear I/O shield. No original box or extra cables are supplied. Align the board with standard Micro ATX standoffs, connect the 24-pin and CPU power headers, then seat memory and expansion cards. Missing screws or an incorrect I/O shield are the most common fitment issues.

Highlights

  • Supports 6th/7th gen Intel Core, Pentium and Celeron CPUs on LGA 1151 socket
  • Dual-channel DDR4 up to 2400 MHz with 32 GB maximum capacity
  • One PCIe 3.0 x16 slot plus two PCIe 3.0 x1 slots for expansion
  • Realtek ALC887 codec delivers 7.1 channel audio
  • Realtek RTL8111H provides Gigabit LAN connectivity

Specifications

BrandMSI
SeriesMSI B250M-F
ModelMSI B250M-F
CPU Socket TypeLGA 1151
CPU TypeSupports 6th/7th generation Intel Core i3/i5/i7 processors, as well as Intel Pentium and Celeron processors with pin LGA1151
ChipsetIntel B250
Memory StandardSupports dual-channel DDR4 2400/2133MHz memory
Maximum Memory Supported32GB
PCI Slots1 PCIe 3.0 x16 slot
2 PCIe 3.0 x1 slots
SATA RAID1XM.2 interface, 6xSATA III interface
Audio ChipsetRealtek ALC887 decoding chip
- 7.1 channel high-quality sound effects
LAN Chipset1 x Realtek RTL8111H Gigabit network interface card
Onboard USB- 6 USB 3.1 Gen1 (SuperSpeed USB) ports (4 ports on the backplane, 2 via onboard USB ports)
- 6 USB 2.0 (High-speed USB) ports (2 ports on the backplane, 4 via onboard USB ports)

Questions about this item

How much DDR4 memory can the B250M-F actually use in a working system?

The board supports up to 32 GB of dual-channel DDR4 at 2400 or 2133 MHz.

What does the single M.2 interface connect to and what speed does it deliver?

The M.2 slot runs over the B250 chipset and provides one SATA III link for a SATA-based M.2 drive.

Will this Micro ATX board fit in a standard 23.6 cm by 20.0 cm case cut-out?

Yes, the PCB measures 23.6 cm by 20.0 cm, matching the Micro ATX form factor.
