Green Micro ATX board with silver LGA 1151 socket, black DDR4 slots and metal I/O shield

MSI

MSI B250M PRO-VH Intel B250 motherboard

SKU CH-KNYK-TVNKP

Micro-ATX board with LGA 1151 socket, Intel B250 chipset, dual-channel DDR4 up to 32GB, one PCIe 3.0 x16 and two x1 slots, six SATA III ports, 7.1 audio, Gigabit LAN.

  • CPU Socket TypeLGA 1151
  • CPU TypeSupports 6th/7th generation Intel Core i3/i5/i7 processors,
  • ChipsetIntel B250
  • Memory StandardSupports dual-channel DDR4 2400/2133MHz memory
  • Maximum Memory Supported32GB
  • PCI Slots1 PCIe 3.0 x16 slot 2 PCIe 3.0 x1 slots
  • Supports 6th and 7th generation Intel Core processors with LGA 1151 socket
  • Dual-channel DDR4 memory up to 32GB at 2400 or 2133MHz
  • One PCIe 3.0 x16 and two PCIe 3.0 x1 expansion slots
  • Six SATA III ports and one M.2 interface for storage
  • Realtek ALC887 7.1 channel audio and RTL8111H Gigabit LAN

Micro-ATX board for LGA 1151 CPUs

This MSI B250M PRO-VH motherboard uses the Intel B250 chipset in a micro-ATX layout. It accepts 6th and 7th generation Intel Core i3, i5 and i7 processors plus Pentium and Celeron models that fit the LGA 1151 socket. Dual-channel DDR4 memory runs at 2400 or 2133 MHz up to 32 GB total capacity. One PCIe 3.0 x16 slot and two PCIe 3.0 x1 slots handle graphics and add-in cards.

Suits budget 6th/7th gen Intel builds

Builders assembling a cost-conscious system around a 6th or 7th generation Intel Core, Pentium or Celeron CPU will find the board a direct fit. The single x16 slot and two x1 slots cover basic expansion while six SATA III ports and one M.2 interface provide storage options. Realtek ALC887 audio and RTL8111H Gigabit LAN handle sound and networking. Six USB 3.1 Gen1 and six USB 2.0 ports cover peripherals. Users needing newer CPU generations, more PCIe lanes or overclocking features should look at a different platform.

LGA 1151 socket dictates CPU choice

The LGA 1151 socket is the single specification that determines whether this motherboard matches the processor. Only 6th and 7th generation Intel Core i3, i5, i7, Pentium and Celeron CPUs with that pin layout are supported. No other socket or generation will install in this board.

Highlights

  • Supports 6th and 7th generation Intel Core processors with LGA 1151 socket
  • Dual-channel DDR4 memory up to 32GB at 2400 or 2133MHz
  • One PCIe 3.0 x16 and two PCIe 3.0 x1 expansion slots
  • Six SATA III ports and one M.2 interface for storage
  • Realtek ALC887 7.1 channel audio and RTL8111H Gigabit LAN

Specifications

BrandMSI
SeriesMSI B250M PRO-VH
ModelMSI B250M PRO-VH
CPU Socket TypeLGA 1151
CPU TypeSupports 6th/7th generation Intel Core i3/i5/i7 processors, as well as Intel Pentium and Celeron processors with pin LGA1151
ChipsetIntel B250
Memory StandardSupports dual-channel DDR4 2400/2133MHz memory
Maximum Memory Supported32GB
PCI Slots1 PCIe 3.0 x16 slot
2 PCIe 3.0 x1 slots
SATA RAID1XM.2 interface, 6xSATA III interface
Audio ChipsetRealtek ALC887 decoding chip
- 7.1 channel high-quality sound effects
LAN Chipset1 Realtek RTL8111H Gigabit network interface card
Onboard USB- 6 USB 3.1 Gen1 (SuperSpeed USB) ports (4 ports on the backplane, 2 via onboard USB ports)
- 6 USB 2.0 (High-speed USB) ports (2 ports on the backplane, 4 via onboard USB ports)

Questions about this item

How much power does the board draw under continuous load?

The B250 chipset and Realtek RTL8111H LAN controller are low-power components, so the motherboard itself adds minimal draw beyond the installed CPU and memory.

Which DDR4 memory speeds and maximum capacity are supported?

Dual-channel DDR4 at 2400 or 2133 MHz up to 32 GB total across the two slots.

Can I keep my existing SATA drives and PCIe 3.0 add-in cards?

Yes — six SATA III ports and two PCIe 3.0 x1 slots are available alongside the primary PCIe 3.0 x16 slot.
