Green micro-ATX board with black heatsinks and silver socket AM4

MSI

MSI B350M BAZOOKA AMD motherboard

SKU CH-AK2M-WPQZM

Socket AM4 board with AMD B350 chipset, dual-channel DDR4 to 3200 OC, 64 GB max, one PCIe 3.0 x16 slot, four SATA III ports, Realtek ALC892 7.1 audio and Gigabit LAN

  • CPU Socket TypeSocket AM4
  • CPU TypeAMD first and second generation AMD Ryzen/Ryzen with Radeon
  • ChipsetAMD B350
  • Memory StandardSupport dual-channel DDR4 1866/2133/2400/2667 (OC)/2933 (OC)
  • Maximum Memory Supported64GB
  • PCI Slots1 PCIe 3.0 x16 slot - RYZEN series processors support x16 mo
  • Supports Ryzen processors up to 3200 MHz DDR4
  • Four SATA III ports for multiple storage drives
  • Single PCIe 3.0 x16 slot for graphics cards
  • Realtek ALC892 delivers 7.1 channel audio
  • Gigabit LAN via Realtek 8111H controller

Socket AM4 foundation

The MSI B350M BAZOOKA is a Micro ATX board built on the AMD B350 chipset for Socket AM4 processors. It supports first- and second-generation Ryzen CPUs as well as A-series and Athlon chips with AM4 pins. Dual-channel DDR4 memory runs at speeds from 1866 up to 3200 (OC) MHz with a maximum capacity of 64GB.

Thermals and power in daily use

The board draws power through standard ATX and CPU connectors and runs without active chipset cooling. The Realtek ALC892 audio codec and Realtek 8111H Gigabit LAN operate at low wattage, keeping system noise dependent only on the CPU cooler and case fans you choose. No onboard fan headers beyond the CPU and chassis connectors are detailed in the specifications.

Upgrade path from older platforms

This motherboard replaces AM3+ or FM2+ boards when moving to a Ryzen or updated A-series processor. The single PCIe 3.0 x16 slot runs at x16 with Ryzen and x8 with 7th-generation A-series or Athlon CPUs. Two PCIe 2.0 x1 slots, four SATA III ports and one M.2 interface provide storage and add-in flexibility. Eight USB 2.0 and two USB 3.1 Gen1 ports handle peripherals without extra controllers.

Highlights

  • Supports Ryzen processors up to 3200 MHz DDR4
  • Four SATA III ports for multiple storage drives
  • Single PCIe 3.0 x16 slot for graphics cards
  • Realtek ALC892 delivers 7.1 channel audio
  • Gigabit LAN via Realtek 8111H controller

Specifications

BrandMSI
SeriesMSI B350M BAZOOKA
ModelMSI B350M BAZOOKA
CPU Socket TypeSocket AM4
CPU TypeAMD first and second generation AMD Ryzen/Ryzen with Radeon Vega graphics card processors and AMD A series/Ryzen processors with AM4 pins
ChipsetAMD B350
Memory StandardSupport dual-channel DDR4 1866/2133/2400/2667 (OC)/2933 (OC)/3200 (OC) + MHz memory
Maximum Memory Supported64GB
PCI Slots1 PCIe 3.0 x16 slot
- RYZEN series processors support x16 mode
7th generation A-series/Athlon processors support x8 mode
2 PCIe 2.0 x1 slots
SATA RAID1XM.2 interface, 4xSATA III interface
Audio ChipsetRealtek ALC892 decoding chip
- 7.1 channel high-quality sound effects
LAN Chipset1 Realtek 8111H Gigabit network interface card
Onboard USBAMD B350 chipset
- 2 USB 3.1 Gen1 (SuperSpeed USB) ports are provided via the onboard USB 3.1 Gen1 port
- 8 USB 2.0 (High-speed USB) interfaces (4 Type-A connections, ports located on the backplane, 4 interfaces provided through the onboard USB 2.0 interface)
AMD processor
- 4 USB 3.1 Gen1 (SuperSpeed USB) Type-A ports on the back panel

Questions about this item

Will a first-generation Ryzen CPU run the PCIe slot at full x16 speed on this board?

Yes, Ryzen series processors support x16 mode on the single PCIe 3.0 x16 slot.

What is the highest DDR4 speed the board can run without overclocking?

The board runs DDR4 at 2133 MHz by default; 2400, 2667, 2933 and 3200 are overclocked speeds.

Does the package include everything needed to install the board in a case?

The box contains the motherboard, a CMOS battery, one SATA cable and the rear I/O panel.
