Micro ATX board, black PCB with silver heatsinks and red accents

MSI

MSI B350M GAMING PRO AMD motherboard

SKU CH-87CJ-C0A5Y

Micro-ATX AM4 board with B350 chipset, dual-channel DDR4 up to 3200 MHz OC, 32 GB max, one PCIe 3.0 x16 slot, 7.1 Realtek ALC887 audio and Gigabit LAN

  • CPU Socket TypeSocket AM4
  • CPU TypeAMD first and second generation AMD Ryzen/Ryzen with Radeon
  • ChipsetAMD B350
  • Memory StandardSupports dual-channel DDR4 1866/2133/2400/2667 (OC)/2933 (OC
  • Maximum Memory Supported32GB
  • PCI Slots1 PCIe 3.0 x16 slot - RYZEN series processors support x16 mo
  • Socket AM4 supports first and second generation Ryzen processors
  • Micro ATX form factor measures 23.6 by 20.0 cm for compact builds
  • Dual-channel DDR4 memory scales up to 3200 MHz overclocked for responsive performance
  • Four SATA III ports plus one M.2 interface give flexible storage options
  • Realtek ALC887 codec delivers 7.1 channel high-quality sound effects

Socket AM4 Micro-ATX Platform

The MSI B350M GAMING PRO is a Micro-ATX motherboard built for AMD Socket AM4 processors. It supports first and second generation Ryzen CPUs as well as 7th Gen A-Series and Athlon chips. The board delivers a compact foundation for mainstream desktop builds.

Dual-Channel DDR4 and Core Connectivity

Four memory slots run dual-channel DDR4 at speeds up to 3200 MHz when overclocked, with a 32 GB capacity ceiling. Expansion covers one PCIe 3.0 x16 slot and two PCIe 2.0 x1 slots. Storage connects through four SATA III ports and one M.2 interface. Realtek ALC887 audio provides 7.1-channel output while a Realtek 8111H controller handles Gigabit LAN.

Upgrade Path From Older AM3+ Systems

This board replaces legacy platforms that cannot run Ryzen architectures. The jump is worthwhile when moving to Zen or Zen+ cores for higher instructions-per-clock and modern instruction sets. It also adds native USB 3.1 Gen1 ports and M.2 support absent on prior chipsets.

Highlights

  • Socket AM4 supports first and second generation Ryzen processors
  • Micro ATX form factor measures 23.6 by 20.0 cm for compact builds
  • Dual-channel DDR4 memory scales up to 3200 MHz overclocked for responsive performance
  • Four SATA III ports plus one M.2 interface give flexible storage options
  • Realtek ALC887 codec delivers 7.1 channel high-quality sound effects

Specifications

BrandMSI
SeriesMSI B350M GAMING PRO
ModelMSI B350M GAMING PRO
CPU Socket TypeSocket AM4
CPU TypeAMD first and second generation AMD Ryzen/Ryzen with Radeon Vega graphics card processors and AMD A series/Ryzen processors with AM4 pins
ChipsetAMD B350
Memory StandardSupports dual-channel DDR4 1866/2133/2400/2667 (OC)/2933 (OC)/3200 (OC) MHz memory
Maximum Memory Supported32GB
PCI Slots1 PCIe 3.0 x16 slot
- RYZEN series processors support x16 mode
- 7th Gen A-series/Athlon processors support x8 mode
2 PCIe 2.0 x1 slots
SATA RAID1XM.2 interface, 4xSATA III interface
Audio ChipsetRealtek ALC887 decoding chip
- 7.1 channel high-quality sound effects
LAN Chipset1 x Realtek 8111H Gigabit network interface card
Onboard USBAMDB350 chip group
- 2 USB 3.1 Gen1 (SuperSpeed USB) ports are provided via the onboard USB 3.1 Gen1 port
- 6 USB 2.0 (High-speed USB) ports (2 on the backplane, 4 via onboard USB ports)
AMD CPU chip group
- 4 USB 3.1 Gen1 (SuperSpeed USB) Type-A interfaces on the backplane

Questions about this item

Which AMD processors fit this Socket AM4 board?

First- and second-generation Ryzen CPUs and APUs with AM4 pins are supported, plus 7th-generation A-series and Athlon chips. Ryzen parts run the top PCIe slot at x16; A-series and Athlon run it at x8.

What is the highest DDR4 speed the board can run?

The board natively supports DDR4 up to 2400 MHz and can reach 2667, 2933 or 3200 MHz when overclocked. Four slots take a maximum of 32 GB in dual-channel mode.

What storage connectors are available?

Four SATA III ports and one M.2 interface are provided. The M.2 slot runs over SATA, so only SATA-based M.2 drives will work.
