Green Micro ATX motherboard with black PCIe slots and silver heatsinks

MSI

MSI B350M PRO-VH PLUS AMD motherboard

SKU CH-9QAR-TS2W0

Socket AM4 micro-ATX board with AMD B350 chipset, four SATA III ports, 7.1-channel Realtek ALC887 audio, Gigabit LAN and six USB 3.1 Gen1 ports, supporting DDR4 up to 3200 OC and 32 GB maximum memory

  • CPU Socket TypeSocket AM4
  • CPU TypeAMD first and second generation AMD Ryzen/Ryzen with Radeon
  • ChipsetAMD B350
  • Memory StandardSupport DDR4 1866/2133/2400/2667/2933 (OC)/3200 (OC) MHz mem
  • Maximum Memory Supported32GB
  • PCI Slots1 PCIe 3.0 x16 slot - RYZEN series processors support x16 mo
  • Supports Ryzen processors up to 32 GB DDR4 memory
  • DDR4 speeds from 1866 MHz to 3200 MHz overclocked
  • PCIe 3.0 x16 slot runs at x16 with Ryzen CPUs
  • Four SATA III ports for storage expansion
  • Realtek ALC887 delivers 7.1 channel audio
  • Realtek 8111H Gigabit LAN for wired networking

Socket AM4 B350 Micro-ATX board

This MSI B350M PRO-VH PLUS motherboard uses the AMD B350 chipset and a Socket AM4 layout in a Micro-ATX form factor. It is built for first- and second-generation Ryzen processors and compatible A-series or Athlon CPUs. The board targets budget system builders who need a compact foundation for a home or office PC.

Suits entry Ryzen builds.

Buyers assembling a basic rig with a single graphics card and up to 32GB of DDR4 memory will find the essential connectivity here. The design provides one full-length PCIe 3.0 x16 slot plus two x1 slots, so it fits compact cases but leaves no room for a second GPU or multiple add-in cards. Anyone planning multi-GPU setups or a larger array of expansion cards should consider a full-size ATX alternative.

One PCIe 3.0 x16 slot and two x1 slots

The expansion layout is the decisive spec: a single PCIe 3.0 x16 slot runs at x16 with Ryzen CPUs and at x8 with 7th-generation A-series or Athlon chips. Two PCIe 3.0 x1 slots handle additional controllers or networking cards. If the build requires more than one full-length slot, this board will not meet that requirement.

Highlights

  • Supports Ryzen processors up to 32 GB DDR4 memory
  • DDR4 speeds from 1866 MHz to 3200 MHz overclocked
  • PCIe 3.0 x16 slot runs at x16 with Ryzen CPUs
  • Four SATA III ports for storage expansion
  • Realtek ALC887 delivers 7.1 channel audio
  • Realtek 8111H Gigabit LAN for wired networking

Specifications

BrandMSI
SeriesMSI B350M PRO-VH PLUS
ModelMSI B350M PRO-VH PLUS
CPU Socket TypeSocket AM4
CPU TypeAMD first and second generation AMD Ryzen/Ryzen with Radeon Vega graphics card processors and AMD A series/Ryzen processors with AM4 pins
ChipsetAMD B350
Memory StandardSupport DDR4 1866/2133/2400/2667/2933 (OC)/3200 (OC) MHz memory
Maximum Memory Supported32GB
PCI Slots1 PCIe 3.0 x16 slot
- RYZEN series processors support x16 mode
7th generation A-series/Athlon processors support x8 mode
2 PCIe 3.0 x1 slots
SATA RAID4XSATA III interface
Audio ChipsetRealtek ALC887 decoding chip
- 7.1 channel high-quality sound effects
LAN Chipset1 x Realtek 8111H Gigabit network interface card
Onboard USB- 6 USB 3.1 Gen1 (SuperSpeed USB) ports (4 ports on the backplane, 2 ports provided via onboard USB ports)
- 6 USB 2.0 (High-speed USB) interfaces (2 interfaces located on the backplane, 4 interfaces provided through the onboard USB interface)

Questions about this item

How can I confirm the MSI B350M PRO-VH PLUS is working after installing a Ryzen processor and DDR4 memory?

The system should POST, display the BIOS screen, and detect the installed DDR4 modules at their rated speed up to 3200 (OC) MHz with a maximum capacity of 32GB across the two slots.

What accessories are included with the MSI B350M PRO-VH PLUS and what must I provide separately?

The box contains the motherboard, one CMOS battery, one SATA cable, and the chassis I/O back panel; you must supply a Socket AM4 processor, DDR4 memory, storage drives, a power supply, and a case.

Which memory speed should I choose for the MSI B350M PRO-VH PLUS given the supported DDR4 frequencies?

The board natively supports DDR4 1866, 2133, and 2400 MHz; speeds of 2667, 2933, and 3200 MHz are marked as OC and require manual configuration in the BIOS to run at those rates.
