Green Micro ATX motherboard with black heatsinks and red accents

MSI

MSI B360M FIRE LGA 1151 Intel motherboard

SKU CH-CMWK-KK4R8

Micro-ATX board for 8th-gen Intel Core CPUs with dual-channel DDR4 up to 2666 MHz, 32 GB maximum memory, one PCIe 3.0 x16 slot, six SATA III ports, an M.2 interface.

  • CPU Socket TypeLGA 1151
  • CPU TypeSupports 8th Gen Intel Core processors, and Intel Pentium Go
  • ChipsetIntel B360
  • Memory StandardSupports dual-channel DDR4 2666/2400/2133MHz memory
  • Maximum Memory Supported32GB
  • PCI Slots1 x PCIe 3.0 x16 slot 2 x PCIe 3.0 x1 slots
  • Supports 8th Gen Intel Core and Pentium Gold CPUs on LGA 1151 socket
  • Dual-channel DDR4 memory up to 32 GB at 2666 MHz
  • One PCIe 3.0 x16 plus two PCIe 3.0 x1 expansion slots
  • Six SATA III ports and one M.2 interface for storage
  • Realtek ALC887 7.1-channel audio with RTL8111H Gigabit LAN

Compact Intel B360 platform for 8th-gen builds

The MSI B360M FIRE is a Micro-ATX motherboard built around the Intel B360 chipset and LGA 1151 socket. It supports 8th Generation Intel Core, Pentium Gold and Celeron processors. Dual-channel DDR4 memory runs at 2666, 2400 or 2133 MHz up to a 32 GB capacity.

Steady operation through the B360 chipset

The board delivers one PCIe 3.0 x16 slot and two PCIe 3.0 x1 slots for expansion cards. Storage connects through six SATA III ports and a single M.2 interface. The Realtek RTL8111H provides a Gigabit LAN connection for consistent network throughput.

Micro-ATX layout with essential rear I/O

The 23.6 x 20.0 cm form factor fits smaller chassis while exposing four USB 3.1 Gen1 Type-A ports and two USB 2.0 ports on the back panel. Internal headers add two more USB 3.1 Gen1 and four USB 2.0 connections. Audio uses the Realtek ALC887 codec for 7.1-channel output.

Highlights

  • Supports 8th Gen Intel Core and Pentium Gold CPUs on LGA 1151 socket
  • Dual-channel DDR4 memory up to 32 GB at 2666 MHz
  • One PCIe 3.0 x16 plus two PCIe 3.0 x1 expansion slots
  • Six SATA III ports and one M.2 interface for storage
  • Realtek ALC887 7.1-channel audio with RTL8111H Gigabit LAN

Specifications

BrandMSI
SeriesMSI B360M FIRE
ModelMSI B360M FIRE
CPU Socket TypeLGA 1151
CPU TypeSupports 8th Gen Intel Core processors, and Intel Pentium Gold and Celeron processors for Socket LGA1151
ChipsetIntel B360
Memory StandardSupports dual-channel DDR4 2666/2400/2133MHz memory
Maximum Memory Supported32GB
PCI Slots1 x PCIe 3.0 x16 slot
2 x PCIe 3.0 x1 slots
SATA RAID1XM.2 interface, 6xSATA III interface
Audio ChipsetRealtek ALC887 Codec
7.1-Channel High Definition Audio
LAN Chipset1 x RTL8111H Gigabit network interface card
Onboard USBIntel B360 Chipset
6x USB 3.1 Gen1 (SuperSpeed USB) ports (4 Type-A ports on the back panel, 2 ports available through the internal USB connector)
6x USB 2.0 (High-speed USB) ports (2 ports on the back panel, 4 ports available through the internal USB connectors)

Questions about this item

How hot or noisy does the MSI B360M FIRE get when running an 8th Gen Intel Core processor all day?

The board uses the Intel B360 chipset and a 4+2 phase power design that runs cool under typical 8th Gen Intel Core workloads; fan headers let you tune case airflow for quiet operation.

What memory and cooler must I already own to use this LGA 1151 micro-ATX board?

You need DDR4 modules at 2666, 2400 or 2133 MHz (up to 32 GB total) and any LGA 1151 compatible CPU cooler that fits the 23.6 x 20.0 cm layout.

Will my older SATA SSDs and PCIe 3.0 add-in cards work alongside the B360 chipset?

Yes — six SATA III ports and one M.2 slot handle legacy drives, while one PCIe 3.0 x16 and two PCIe 3.0 x1 slots accept older expansion cards.
