Green Micro ATX board with black sockets and silver heatsinks

MSI

MSI B360M PRO-VD LGA 1151 DDR4 32GB Micro ATX Motherboard

SKU CH-8CAA-3CX03

Micro ATX board for 8th-gen Intel CPUs, dual-channel DDR4 up to 32 GB, one PCIe 3.0 x16 slot, six SATA III ports and Gigabit LAN

  • CPU Socket TypeLGA 1151
  • CPU TypeSupports 8th generation Intel Core processors with LGA1151,
  • ChipsetIntel B360
  • Memory StandardSupports dual-channel DDR4 2666/2400/2133MHz memory
  • Maximum Memory Supported32GB
  • PCI Slots1 PCIe 3.0 x16 slot 2 PCIe 3.0 x1 slots
  • Supports 8th gen Intel Core, Pentium Gold and Celeron CPUs via LGA 1151 socket
  • Dual-channel DDR4 memory up to 2666 MHz with 32 GB maximum capacity
  • One PCIe 3.0 x16 slot and two PCIe 3.0 x1 slots for expansion cards
  • Realtek ALC887 audio chip delivers 7.1 channel high-quality sound
  • RTL8111H Gigabit LAN plus six USB 3.1 Gen1 and six USB 2.0 ports

Intel B360 Micro ATX board

This MSI B360M PRO-VD motherboard uses the Intel B360 chipset in a Micro ATX form factor. It accepts LGA 1151 socket processors including 8th generation Intel Core, Pentium Gold and Celeron CPUs. The board supports dual-channel DDR4 memory at 2666, 2400 or 2133 MHz up to 32 GB total capacity.

Socket, memory and expansion check

Verify your processor is an LGA 1151 model supported by the Intel B360 chipset before ordering. Confirm your memory modules are DDR4 rated for 2666, 2400 or 2133 MHz and that total capacity does not exceed 32 GB. The board provides one PCIe 3.0 x16 slot and two PCIe 3.0 x1 slots for add-in cards.

Build, connectors and daily use

The board measures 23.6 by 20.0 cm and uses standard Micro ATX mounting points for chassis installation. Rear I/O includes four USB 3.1 Gen1 Type-A ports, two USB 2.0 ports and a single RTL8111H Gigabit LAN connector. Audio uses the Realtek ALC887 codec for 7.1 channel output. Internal headers supply two additional USB 3.1 Gen1 ports, four USB 2.0 ports and six SATA III connectors plus one M.2 interface.

Highlights

  • Supports 8th gen Intel Core, Pentium Gold and Celeron CPUs via LGA 1151 socket
  • Dual-channel DDR4 memory up to 2666 MHz with 32 GB maximum capacity
  • One PCIe 3.0 x16 slot and two PCIe 3.0 x1 slots for expansion cards
  • Realtek ALC887 audio chip delivers 7.1 channel high-quality sound
  • RTL8111H Gigabit LAN plus six USB 3.1 Gen1 and six USB 2.0 ports

Specifications

BrandMSI
SeriesMSI B360M PRO-VD
ModelMSI B360M PRO-VD
CPU Socket TypeLGA 1151
CPU TypeSupports 8th generation Intel Core processors with LGA1151, Pentium Gold and Celeron processors
ChipsetIntel B360
Memory StandardSupports dual-channel DDR4 2666/2400/2133MHz memory
Maximum Memory Supported32GB
PCI Slots1 PCIe 3.0 x16 slot
2 PCIe 3.0 x1 slots
SATA RAID1XM.2 interface, 6xSATA III interface
Audio ChipsetRealtek ALC887 decoding chip
7.1 channel high-quality sound effects
LAN Chipset1 x RTL8111H Gigabit network interface card
Onboard USBIntel B360 Chipset
6 USB 3.1 Gen1 (SuperSpeed USB) ports (4 Type-A ports on the backplane, 2 ports provided via onboard USB ports)
6 USB 2.0 (High-speed USB) interfaces (2 interfaces on the backplane, 4 interfaces through the onboard USB interface

Questions about this item

Does the board ship with the I/O shield and a SATA cable, or do I need to buy them separately?

The package includes the motherboard, the chassis I/O back panel and one SATA cable.

Should I choose the 32 GB or 64 GB memory limit for a dual-channel DDR4 build?

This board supports up to 32 GB of dual-channel DDR4 at 2666, 2400 or 2133 MHz.

What does the single PCIe 3.0 x16 slot mean for a graphics card install?

It provides one full-length PCIe 3.0 x16 connection for a discrete GPU, with two additional x1 slots for other add-in cards.
