Green Micro-ATX circuit board with silver LGA1151 socket, four black DDR4 slots, reinforced PCIe x16 slot

MSI

MSI B360M PRO-VDH Intel motherboard

SKU CH-DH4T-HKQMW

Micro-ATX board for LGA1151 Intel CPUs with four DDR4 slots, Steel Armor PCIe x16, Turbo M.2, six SATA ports and Realtek Gigabit LAN

  • ChipsetIntel B360
  • Number of Memory Slots4 x DDR4 Boost DIMM slots (Dual Channel, up to 64GB)
  • Maximum Memory SupportedSupports DDR4 2133 up to 2666 MHz as MSI Compatibility List
  • PCI Slots1 PCIe 3.0x16 with Steel Armor and 2 x PCIe 3.0x1 slots
  • Wireless LANvia PCIe or USB (add-on WLAN card or dongle required)
  • Form FactorMicro-ATX (9.6" x 9.6" inches) with 8 Mounting Holes
  • Supports 9th and 8th Gen Intel Core processors via LGA1151 socket
  • Four DDR4 Boost DIMM slots deliver up to 64 GB dual-channel memory at 2666 MHz
  • Turbo M.2 slot accepts PCIe 3.0 x4 and SATA SSDs in 2242, 2260, 2280 and 22110 sizes
  • Realtek ALC887 codec provides 7.1-channel HD Audio for immersive sound
  • Six SATAIII 6 Gb/s ports plus rear USB 3.0 Type-C, three USB 3.0 and two USB 2.0 connections

Socket LGA1151 Micro-ATX Board

The MSI B360M PRO-VDH is a Micro-ATX motherboard built around the Intel B360 chipset and the LGA1151 socket. It accepts 8th and 9th generation Intel Core, Pentium Gold and Celeron processors. Four DDR4 Boost DIMM slots support dual-channel memory up to 64GB at speeds from 2133 to 2666 MHz. The board measures 9.6 by 9.6 inches with eight mounting holes.

Sustained Load Behaviour

Core Boost uses a premium layout and optimised digital power design to maintain stable delivery during extended workloads. Steel Armor reinforces the primary PCIe 3.0 x16 slot, preventing flex when a heavy graphics card is installed for long sessions. EZ Debug LED indicators help identify hardware issues quickly if thermal throttling or instability appears under continuous stress.

Pre-Installation Checks

Verify that your chassis accommodates a 9.6-inch Micro-ATX board and provides the eight mounting points. Confirm the CPU cooler clearance suits the socket area layout. Ensure the power supply includes the necessary 8-pin CPU and 24-pin ATX connectors. Check that any M.2 SSD you plan to use matches the 2242, 2260, 2280 or 22110 form factors supported by the single Turbo M.2 slot.

Highlights

  • Supports 9th and 8th Gen Intel Core processors via LGA1151 socket
  • Four DDR4 Boost DIMM slots deliver up to 64 GB dual-channel memory at 2666 MHz
  • Turbo M.2 slot accepts PCIe 3.0 x4 and SATA SSDs in 2242, 2260, 2280 and 22110 sizes
  • Realtek ALC887 codec provides 7.1-channel HD Audio for immersive sound
  • Six SATAIII 6 Gb/s ports plus rear USB 3.0 Type-C, three USB 3.0 and two USB 2.0 connections

Specifications

BrandMSI
ModelB360M PRO-VDH
ChipsetIntel B360
Number of Memory Slots4 x DDR4 Boost DIMM slots (Dual Channel, up to 64GB)
Maximum Memory SupportedSupports DDR4 2133 up to 2666 MHz as MSI Compatibility List
PCI Slots1 PCIe 3.0x16 with Steel Armor and 2 x PCIe 3.0x1 slots
Wireless LANvia PCIe or USB (add-on WLAN card or dongle required)
Form FactorMicro-ATX (9.6" x 9.6" inches) with 8 Mounting Holes

Questions about this item

How hot or loud does the B360M PRO-VDH run when the system stays on 24/7?

The board uses a passive chipset heatsink and Core Boost power layout, so it adds no fan noise; actual heat and noise depend on the CPU cooler and case airflow you pair with it.

Which parts must I already own for the B360M PRO-VDH to boot and run?

You need an LGA1151 8th or 9th Gen Intel processor, DDR4 memory modules up to 2666 MHz, a PSU with 24-pin and 8-pin CPU connectors, and a graphics card or CPU with integrated graphics for video output.

Will my older SATA drives and USB 2.0 peripherals work with this motherboard?

Yes, the board provides six SATA 6 Gb/s ports and four internal USB 2.0 headers alongside the newer USB 3.0 and M.2 connections, so existing drives and peripherals connect directly.
