Green micro-ATX board with silver LGA 1151 socket, two black DDR4 slots, single PCIe x16 slot, six SATA ports, black rear I/O shield

MSI

MSI B365M PLUS Intel motherboard LGA 1151 DDR4 32GB Micro ATX

SKU CH-2Z8T-YK1EK

Micro-ATX Intel B365 board, LGA 1151 socket, two DDR4 slots up to 32 GB, one PCIe 3.0 x16 and two x1 slots, six SATA III and one M.2, Realtek ALC887 7.1 audio, RTL8111H Gigabit LAN

  • CPU Socket TypeLGA 1151
  • CPU TypeSupports LGA1151 8th Gen, 9th Gen Intel Core ™, Pentium Gold
  • ChipsetIntel B365
  • Memory Standard2 DDR4 slots, supporting a total of up to 32GB. Supports DDR
  • Maximum Memory Supported32GB
  • PCI Slots1 PCIe 3.0 x16 slot 2 PCIe 3.0 x1 slots
  • Supports 8th and 9th Gen Intel Core processors via LGA 1151 socket
  • Dual-channel DDR4 memory up to 32 GB at 2666 MHz
  • One PCIe 3.0 x16 slot plus two PCIe 3.0 x1 slots for expansion
  • Realtek ALC887 codec delivers 7.1-channel high-definition audio
  • Realtek RTL8111H provides Gigabit Ethernet connectivity

Socket LGA 1151 micro-ATX board

The MSI B365M PLUS is an Intel B365 motherboard built for LGA 1151 processors. It accepts 8th and 9th generation Core, Pentium Gold and Celeron CPUs in a compact micro-ATX form factor. The board provides essential connectivity for mainstream desktop builds.

Home and office builds, not high-end overclocking

This board suits users assembling a general-purpose PC for productivity, media playback or light gaming. Builders who need multiple graphics cards, heavy overclocking headroom or more than two memory slots should consider a larger chipset platform.

32 GB DDR4 ceiling with dual-channel support

Two DDR4 slots support up to 32 GB total at speeds of 2666, 2400 or 2133 MHz in dual-channel mode. Non-ECC unbuffered modules and XMP profiles are supported. The 32 GB limit means memory-intensive workloads will hit a hard ceiling.

Highlights

  • Supports 8th and 9th Gen Intel Core processors via LGA 1151 socket
  • Dual-channel DDR4 memory up to 32 GB at 2666 MHz
  • One PCIe 3.0 x16 slot plus two PCIe 3.0 x1 slots for expansion
  • Realtek ALC887 codec delivers 7.1-channel high-definition audio
  • Realtek RTL8111H provides Gigabit Ethernet connectivity

Specifications

BrandMSI
SeriesMSI B365M PLUS
ModelMSI B365M PLUS
CPU Socket TypeLGA 1151
CPU TypeSupports LGA1151 8th Gen, 9th Gen Intel Core ™, Pentium Gold and Celeron processors
ChipsetIntel B365
Memory Standard2 DDR4 slots, supporting a total of up to 32GB.
Supports DDR4 2666/2400/2133 MHz
Support dual channel mode
Support non-ECC, unbuffered memory
Supports Intel Extreme Memory Profile (XMP)
Maximum Memory Supported32GB
PCI Slots1 PCIe 3.0 x16 slot
2 PCIe 3.0 x1 slots
SATA RAID1XM.2 interface, 6xSATA III interface
Audio ChipsetRealtek ALC887 decoding chip
7.1 channel high-quality sound effects
LAN Chipset1 Realtek RTL8111H Gigabit network interface card
Onboard USBIntel chipsets
6 USB 3.1 Gen1 (SuperSpeed USB) ports (4 Type-A ports on the backplane, 2 ports provided via onboard USB ports)
6 USB 2.0 (High-speed USB) interfaces (2 interfaces on the backplane, 4 interfaces provided through the onboard USB interface)

Questions about this item

Which CPU socket must my processor match to work with this board?

The board uses the LGA 1151 socket, so your processor must be an 8th or 9th Gen Intel Core, Pentium Gold or Celeron in that package.

Will my existing DDR4 2400 MHz modules run at their rated speed on this board?

Yes, the board supports DDR4 2133, 2400 and 2666 MHz, so 2400 MHz modules will operate at their native frequency in dual-channel mode.

How can I confirm the 7.1 channel audio is active after I build the system?

Open the Realtek audio control panel in Windows and verify the speaker configuration shows 7.1 channels with all channels passing the test tones.
