Green Micro ATX board with silver CPU socket, black memory slots and blue PCIe slots, rear I/O shield visible

MSI

MSI B365M PRO-VDH Intel motherboard LGA 1151 DDR4 64GB Micro ATX

SKU CH-EMVG-29VAP

Micro ATX board with Intel B365 chipset for LGA 1151 CPUs, dual-channel DDR4 to 64 GB, one PCIe 3.0 x16 and two PCIe 3.0 x1 slots, six SATA III ports, Realtek 7.1 audio and Gigabit LAN.

  • CPU Socket TypeLGA 1151
  • CPU TypeSupports 9th/8th Intel, Core/Pentium, Gold/Celeron processor
  • ChipsetIntel B365
  • Memory StandardSupports dual-channel DDR4 2666/2400/2133MHz memory
  • Maximum Memory Supported64GB
  • PCI Slots1 x PCIe 3.0 x16 2 x PCIe 3.0 x1
  • Supports 9th and 8th Gen Intel Core processors via LGA 1151 socket
  • Dual-channel DDR4 memory up to 64 GB at 2666 MHz
  • 1 channel Realtek ALC892 audio for immersive sound
  • Gigabit LAN with Realtek RTL8111H controller for wired networking
  • Eight USB 3.1 Gen 1 ports plus six USB 2.0 connections for peripherals

Socket LGA 1151 Micro-ATX board

The MSI B365M PRO-VDH is a Micro-ATX motherboard built around the Intel B365 chipset for LGA 1151 processors. It supports 9th and 8th generation Intel Core, Pentium Gold and Celeron CPUs. Four DDR4 slots accept dual-channel memory up to 2666 MHz with a total capacity of 64 GB. The board provides one PCIe 3.0 x16 slot and two PCIe 3.0 x1 slots for expansion cards.

Check CPU cooler clearance and power headers

Verify that your LGA 1151 processor matches the supported 9th or 8th generation lineup before ordering. Confirm your case can fit a Micro-ATX board and that the CPU cooler clears the socket area. Ensure the power supply has the required 24-pin ATX and 8-pin CPU connectors. Check that your DDR4 modules are rated for 2133, 2400 or 2666 MHz speeds.

Bundled I/O shield, SATA cable and CMOS battery

The package includes a chassis I/O back panel, one SATA cable and a CMOS battery so the board can be installed without extra purchases. Rear I/O supplies three USB 3.1 Gen1 Type-A ports and one Type-C port, plus two USB 2.0 Type-A ports. Internal headers add four more USB 3.1 Gen1 and four USB 2.0 connections. Realtek ALC892 delivers 7.1 channel audio and RTL8111H provides Gigabit LAN.

Highlights

  • Supports 9th and 8th Gen Intel Core processors via LGA 1151 socket
  • Dual-channel DDR4 memory up to 64 GB at 2666 MHz
  • 1 channel Realtek ALC892 audio for immersive sound
  • Gigabit LAN with Realtek RTL8111H controller for wired networking
  • Eight USB 3.1 Gen 1 ports plus six USB 2.0 connections for peripherals

Specifications

BrandMSI
SeriesMSI B365M PRO-VDH
ModelMSI B365M PRO-VDH
CPU Socket TypeLGA 1151
CPU TypeSupports 9th/8th Intel, Core/Pentium, Gold/Celeron processors (LGA 1151 interface)
ChipsetIntel B365
Memory StandardSupports dual-channel DDR4 2666/2400/2133MHz memory
Maximum Memory Supported64GB
PCI Slots1 x PCIe 3.0 x16
2 x PCIe 3.0 x1
SATA RAID1XM.2 interface, 6xSATA III interface
Audio ChipsetRealtek ALC892
7.1 channel high-quality audio
LAN ChipsetRealtek RTL8111H Gigabit network interface card
Onboard USB8 x USB 3.1 Gen1 (back 3 Type-A + 1 Type-C, 4 for use via internal USB connector)
6 x USB 2.0 (2 Type-A ports on the back, 4 for use via internal USB connectors)

Questions about this item

What accessories come in the box with this B365M PRO-VDH board?

The package includes the motherboard, a CMOS battery, one SATA cable and the chassis I/O back panel.

Which DDR4 speed should I choose for the 64GB limit on this board?

The board runs dual-channel DDR4 at 2666, 2400 or 2133 MHz; pick 2666 MHz modules for the highest supported frequency.

What does the single PCIe 3.0 x16 slot mean for my graphics card?

It provides one full-bandwidth connection for a graphics card, while two additional PCIe 3.0 x1 slots handle smaller add-in cards.
