Green micro-ATX board with silver heatsinks, black slots and rear I/O shield

MSI

MSI B365M PRO-VH LGA 1151 DDR4 32GB Micro ATX Intel motherboard

SKU CH-SKHM-5KGJ7

Micro ATX motherboard with Intel B365 chipset, LGA 1151 socket, dual-channel DDR4 up to 32 GB, one PCIe 3.0 x16 slot, six SATA III ports, Realtek 7.1 audio and Gigabit LAN

  • CPU Socket TypeLGA 1151
  • CPU TypeSupports 8th generation, 9th generation Intel Core, Pentium
  • ChipsetIntel B365
  • Memory StandardSupports dual-channel DDR4 2666/2400/2133MHz memory
  • Maximum Memory Supported32GB
  • PCI Slots1 PCIe 3.0 x16 slot 2 PCIe 3.0 x1 slots
  • Supports 8th and 9th Gen Intel Core CPUs via LGA 1151 socket
  • Dual-channel DDR4 up to 2666 MHz for responsive multitasking
  • 32 GB maximum memory capacity handles demanding workloads
  • 1-channel Realtek ALC887 audio delivers immersive sound
  • Gigabit LAN with Realtek RTL8111H ensures wired network speed

Socket LGA 1151 Micro ATX board

This motherboard uses the Intel B365 chipset and fits the Micro ATX form factor. It accepts 8th and 9th generation Intel Core, Pentium Gold and Celeron processors. Dual-channel DDR4 memory runs at 2666, 2400 or 2133 MHz up to a 32GB limit. The layout suits compact builds that need mainstream desktop performance.

Expansion slots and rear connectivity

One PCIe 3.0 x16 slot and two PCIe 3.0 x1 slots handle graphics and add-in cards. Storage connects through one M.2 interface and six SATA III ports. The rear panel provides four USB 3.1 Gen1 Type-A ports and two USB 2.0 ports. Onboard headers add two more USB 3.1 Gen1 and four USB 2.0 connections. Realtek ALC887 audio delivers 7.1 channel output and a Realtek RTL8111H controller supplies gigabit LAN.

Upgrade path from older Intel platforms

Builders moving from 6th or 7th generation Core systems gain native USB 3.1 Gen1 support and the newer B365 chipset features. The 32GB memory ceiling and six SATA III ports cover typical storage and multitasking needs. If a workload demands more than 32GB of RAM or multiple x16 slots, a larger ATX board with a Z-series chipset would be required.

Highlights

  • Supports 8th and 9th Gen Intel Core CPUs via LGA 1151 socket
  • Dual-channel DDR4 up to 2666 MHz for responsive multitasking
  • 32 GB maximum memory capacity handles demanding workloads
  • 1-channel Realtek ALC887 audio delivers immersive sound
  • Gigabit LAN with Realtek RTL8111H ensures wired network speed

Specifications

BrandMSI
SeriesMSI B365M PRO-VH
ModelMSI B365M PRO-VH
CPU Socket TypeLGA 1151
CPU TypeSupports 8th generation, 9th generation Intel Core, Pentium Gold and Celeron processors with LGA1151
ChipsetIntel B365
Memory StandardSupports dual-channel DDR4 2666/2400/2133MHz memory
Maximum Memory Supported32GB
PCI Slots1 PCIe 3.0 x16 slot
2 PCIe 3.0 x1 slots
SATA RAID1XM.2 interface, 6xSATA III interface
Audio ChipsetRealtek ALC887 decoding chip
7.1 channel high-quality sound effects
LAN Chipset1 Realtek RTL8111H Gigabit network interface card
Onboard USBIntel chipsets
6 USB 3.1 Gen1 (SuperSpeed USB) ports (4 Type-A ports on the backplane, 2 ports provided via onboard USB ports)
6 USB 2.0 (High-speed USB) interfaces (2 interfaces on the backplane, 4 interfaces provided through the onboard USB interface)

Questions about this item

What speed does the M.2 interface cap at with the B365 chipset?

The single M.2 slot runs at SATA III speeds, so a SATA M.2 drive is limited to 6 Gbps throughput.

What clearance does the Micro ATX board need in the case?

The board measures 23.6 cm by 20.0 cm and fits any chassis that accepts Micro ATX.

How is the M.2 drive secured during installation?

Insert the drive at an angle into the slot, press it flat and fasten the single screw; the common mistake is omitting the screw so the drive pops up.
