Green micro-ATX motherboard with black slots and silver heatsinks

MSI

MSI B450M-A PRO MAX AMD motherboard

SKU CH-GTDQ-Z97K2

Micro ATX board for AM4 Ryzen CPUs with dual-channel DDR4 up to 4133 MHz, 32 GB max, one PCIe 3.0 x16 slot, four SATA III ports, 7.1 audio and gigabit LAN

  • CPU Socket TypeSocket AM4
  • CPU TypeSupports 1st, 2nd and 3rd Gen AMD Ryzen / Ryzen with Radeon
  • ChipsetAMD B450
  • Memory StandardAMD Ryzen Gen3 (R5/R7/R9): Supports dual-channel DDR4 2667/2
  • Maximum Memory Supported32GB
  • PCI Slots1 x PCIe 3.0 x16 slot Supports x16 speed 1st, 2nd and 3rd Ge
  • Supports 1st, 2nd and 3rd Gen Ryzen processors on Socket AM4
  • Dual-channel DDR4 up to 4133 MHz for fast memory performance
  • 32 GB maximum memory capacity for demanding workloads
  • 1-channel Realtek ALC892/ALC897 audio for immersive sound
  • Realtek 8111H Gigabit LAN for reliable wired networking

Socket AM4 platform

The MSI B450M-A PRO MAX is a Micro-ATX motherboard built around the AMD B450 chipset for Socket AM4 processors. It supports 1st, 2nd and 3rd Gen Ryzen desktop CPUs as well as Athlon and A-series APUs with Radeon graphics. The board targets budget-conscious builders assembling compact office or home systems.

32 GB dual-channel DDR4 headroom

Four DIMM slots accept up to 32 GB of dual-channel DDR4 memory with supported speeds ranging from 2667 to 4133 MHz on Ryzen 3000 series processors. The 32 GB ceiling suits mainstream multitasking and gaming, while heavier content-creation workloads will hit the capacity limit.

PCIe 3.0 and SATA III connectivity

A single PCIe 3.0 x16 slot provides graphics bandwidth at x16, x8 or x4 depending on the installed CPU generation. Storage connects through one M.2 interface and four SATA III ports. Rear I/O includes four USB 3.2 Gen1 ports, two USB 2.0 ports and a Realtek 8111H Gigabit LAN controller, while 7.1-channel audio is handled by the Realtek ALC892/897 codec.

Highlights

  • Supports 1st, 2nd and 3rd Gen Ryzen processors on Socket AM4
  • Dual-channel DDR4 up to 4133 MHz for fast memory performance
  • 32 GB maximum memory capacity for demanding workloads
  • 1-channel Realtek ALC892/ALC897 audio for immersive sound
  • Realtek 8111H Gigabit LAN for reliable wired networking

Specifications

BrandMSI
SeriesMSI B450M-A PRO MAX
ModelMSI B450M-A PRO MAX
CPU Socket TypeSocket AM4
CPU TypeSupports 1st, 2nd and 3rd Gen AMD Ryzen / Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with Radeon Graphics / Athlon with Radeon Vega Graphics and A-series / Athlon X4 Desktop Processors for Socket AM4
ChipsetAMD B450
Memory StandardAMD Ryzen Gen3 (R5/R7/R9): Supports dual-channel DDR4 2667/2800/2933/3000/3066/3200/3466/3733/3866/4000/4133MHz memory
Maximum Memory Supported32GB
PCI Slots1 x PCIe 3.0 x16 slot
Supports x16 speed
1st, 2nd and 3rd Gen AMD Ryzen
Supports x8 speed
Ryzen with Radeon Vega Graphics
2nd Gen AMD Ryzen with Radeon Graphics
A-series
Athlon X4
Supports x4 speed
AMD Athlon with Radeon Vega Graphics
PCIe 2.0 x1 slot
SATA RAID1XM.2 interface, 4xSATA III interface
Audio ChipsetRealtek ALC892/ALC897 Codecc
7.1-Channel High Definition Audio
LAN Chipset1 x Realtek 8111H Gigabit LAN controller
Onboard USBAMD B450 Chipset
6x USB 3.2 Gen1 (SuperSpeed USB) ports (4 ports on the back panel, 2 ports available through the internal USB connector)
6x USB 2.0 (High-speed USB) ports (2 ports on the back panel, 4 ports available through the internal USB connectors)

Questions about this item

Will my existing DDR4-3200 memory run at its rated speed on the B450M-A PRO MAX?

The board supports DDR4 up to 4133 MHz with Ryzen 3000 series CPUs, so 3200 MHz modules will operate at their rated frequency when paired with a compatible processor.

How can I confirm the Realtek ALC892 audio is functioning after assembly?

Connect speakers or headphones to the rear panel jacks, play audio in Windows Sound settings and verify 7.1-channel output appears in the Realtek Audio Console.

Does the box contain an M.2 mounting screw or Wi-Fi antenna?

The package includes the motherboard, a CMOS battery, one SATA cable and the rear I/O shield; no M.2 screw or Wi-Fi antenna is supplied.
