Green Micro ATX motherboard with black heatsinks and silver CPU socket

MSI

MSI B450M BAZOOKA PLUS AMD motherboard

SKU CH-S6XT-R7JJE

Micro-ATX board for first and second generation Ryzen CPUs with DDR4 up to 3200 MHz, 64 GB capacity, one PCIe 3.0 x16 slot, 7.1 audio and Gigabit LAN

  • CPU Socket TypeSocket AM4
  • CPU TypeFirst and second generation AMD Ryzen processors with AM4 pi
  • ChipsetAMD B450
  • Memory StandardSupport dual-channel DDR4 1866/2133/2400/2667/2800/2933/3000
  • Maximum Memory Supported64GB
  • PCI Slots1 PCIe 3.0 x16 slot First and second generation AMD Ryzen pr
  • Socket AM4 fits first and second generation Ryzen CPUs
  • Micro ATX board measures 23.6 x 20.0 cm for compact builds
  • Dual-channel DDR4 supports up to 64 GB at 3333 MHz
  • Realtek ALC892 delivers 7.1-channel high-definition audio
  • One PCIe 3.0 x16 slot plus two PCIe 2.0 x1 slots for expansion

Socket AM4 platform

The MSI B450M BAZOOKA PLUS is a Micro ATX motherboard built on the AMD B450 chipset. It accepts first and second generation Ryzen processors with AM4 pins. The board measures 23.6 by 20.0 centimetres and fits standard Micro ATX chassis.

PCIe 3.0 x16 slot speed

The single PCIe 3.0 x16 slot runs at x16 with first and second generation Ryzen CPUs. When a Ryzen processor with RadeonVega graphics is installed the same slot operates at x8 speed. Two PCIe 2.0 x1 slots provide additional expansion.

64 GB DDR4 dual-channel limit

Four memory slots support dual-channel DDR4 up to 3333 MHz with a maximum capacity of 64 GB. Storage includes one M.2 interface and four SATA III ports. Networking uses a Realtek RTL8111H Gigabit LAN and audio is handled by a Realtek ALC892 7.1-channel codec.

Highlights

  • Socket AM4 fits first and second generation Ryzen CPUs
  • Micro ATX board measures 23.6 x 20.0 cm for compact builds
  • Dual-channel DDR4 supports up to 64 GB at 3333 MHz
  • Realtek ALC892 delivers 7.1-channel high-definition audio
  • One PCIe 3.0 x16 slot plus two PCIe 2.0 x1 slots for expansion

Specifications

BrandMSI
SeriesMSI B450M BAZOOKA PLUS
ModelMSI B450M BAZOOKA PLUS
CPU Socket TypeSocket AM4
CPU TypeFirst and second generation AMD Ryzen processors with AM4 pins and RadeonVega graphics
ChipsetAMD B450
Memory StandardSupport dual-channel DDR4 1866/2133/2400/2667/2800/2933/3000/3066/3200/3333MHz memory
Maximum Memory Supported64GB
PCI Slots1 PCIe 3.0 x16 slot
First and second generation AMD Ryzen processors support x16 speed
Ryzen processors with RadeonVega graphics support x8 speeds
2 PCIe 2.0 x1 slots
SATA RAID1XM.2 interface, 4xSATA III interface
Audio ChipsetRealtek ALC892 decoding chip
7.1-Channel high-quality sound effects
LAN Chipset1 Realtek RTL8111H Gigabit network interface card
Onboard USBAMD B450 chipset
8 USB 3.1 Gen1 (SuperSpeed USB) ports (4 Type-A ports on the backplane, 4 ports provided via the onboard USB 3.1 Gen1 port)
6 USB 2.0 (High-speed USB) ports (2 Type-A ports on the backplane, 4 ports provided via onboard USB 2.0 ports)

Questions about this item

What does the 64 GB maximum memory mean for my build?

The board supports up to 64 GB of dual-channel DDR4 across its two slots, so you can install two 32 GB modules for the full capacity.

How fast does the PCIe 3.0 x16 slot actually run with different CPUs?

First and second generation Ryzen processors with AM4 pins run the slot at x16; Ryzen processors with Vega graphics run it at x8 speed.

What are the exact board dimensions for case clearance?

The Micro ATX board measures 23.6 cm by 20.0 cm, so verify your case supports this footprint before ordering.
