Dark rectangular Micro-ATX motherboard, black PCB with silver heatsinks and blue PCIe slots

MSI

MSI B460M PRO-VDH Intel motherboard LGA 1200 DDR4 128GB Micro ATX

SKU CH-TNMM-GPRD3

Micro ATX board for 10th Gen Intel Core and Pentium Gold / Celeron LGA 1200 CPUs with dual-channel DDR4 up to 128 GB, one PCIe 3.0 x16 slot, four SATA III ports, two M.2 interfaces.

  • CPU Socket TypeLGA 1200
  • CPU TypeSupports 10th Gen Intel Core and Pentium Gold / Celeron proc
  • ChipsetIntel B460
  • Memory StandardSupports dual-channel DDR4 2933MHz memory (maximum)
  • Maximum Memory Supported128GB
  • PCI Slots1x PCIe 3.0 x16 slot (from CPU) 2x PCIe x1 slots (from PCH)
  • Supports 10th Gen Intel Core and Pentium Gold processors via LGA 1200 socket
  • Dual-channel DDR4 memory up to 2933MHz with 128GB maximum capacity
  • PCIe 3.0 x16 slot from CPU plus two PCIe x1 slots from PCH
  • 1-channel Realtek ALC892 audio and Realtek RTL8111H Gigabit LAN
  • Six USB 3.2 Gen 1 ports and six USB 2.0 ports for peripheral connectivity

LGA 1200 Micro ATX motherboard

The MSI B460M PRO-VDH is an Intel B460 board built for the LGA 1200 socket. It supports 10th Gen Intel Core, Pentium Gold and Celeron processors. The board uses dual-channel DDR4 memory and fits Micro ATX cases.

Builders who need 128GB DDR4 on a compact board

This board suits users who want a Micro ATX form factor with four memory slots and a 128GB maximum capacity. It is not for buyers who want more storage interfaces than two M.2 and four SATA III ports. It is also not for builders who need a second full-size PCIe x16 slot.

128GB maximum memory capacity

The board supports up to 128GB of dual-channel DDR4 at 2933MHz. This ceiling decides whether the board fits a planned workload. If the build requires more memory, a different motherboard must be chosen.

Highlights

  • Supports 10th Gen Intel Core and Pentium Gold processors via LGA 1200 socket
  • Dual-channel DDR4 memory up to 2933MHz with 128GB maximum capacity
  • PCIe 3.0 x16 slot from CPU plus two PCIe x1 slots from PCH
  • 1-channel Realtek ALC892 audio and Realtek RTL8111H Gigabit LAN
  • Six USB 3.2 Gen 1 ports and six USB 2.0 ports for peripheral connectivity

Specifications

BrandMSI
SeriesMSI B460M PRO-VDH
ModelMSI B460M PRO-VDH
CPU Socket TypeLGA 1200
CPU TypeSupports 10th Gen Intel Core and Pentium Gold / Celeron processors for LGA 1200 socket.
ChipsetIntel B460
Memory StandardSupports dual-channel DDR4 2933MHz memory (maximum)
Maximum Memory Supported128GB
PCI Slots1x PCIe 3.0 x16 slot (from CPU)
2x PCIe x1 slots (from PCH)
SATA RAID2XM.2 interface, 4xSATA III interface
Audio ChipsetRealtek ALC892 Codec
7.1-Channel High Definition Audio
LAN Chipset1x Realtek RTL8111H Gigabit LAN Controller
Onboard USBIntel B460 Chipset
6x USB 3.2 Gen 1 5Gbps ports (4 Type-A ports on the back panel, 2 ports through the internal USB connector)
6x USB 2.0 ports (2 Type-A ports on the back panel, 4 ports through the internal USB 2.0 connectors)

Questions about this item

What is the maximum memory capacity supported by this motherboard?

The board supports up to 128GB of DDR4 memory across its slots.

How loud or hot does the board get when running continuously?

No active cooling or fan headers are specified, so thermal output depends on the CPU cooler and case airflow you install.

Which processor socket must my CPU match for this board to work?

The board uses the LGA 1200 socket, so the CPU must be a 10th Gen Intel Core, Pentium Gold or Celeron for that socket.
