Green Micro ATX motherboard with black heatsinks, silver CPU socket, four memory slots, two M.2 covers, six SATA ports

MSI

MSI B560M PRO-VDH WIFI Intel motherboard

SKU CH-EP8E-27ENV

Micro-ATX Intel B560 board with LGA 1200 socket, 128 GB DDR4 limit, 2.5 Gbps LAN and integrated Wi-Fi

  • CPU Socket TypeLGA 1200
  • CPU TypeSupports 10th Gen Intel Core™ Processors, 11th Gen Intel Cor
  • ChipsetIntel B560
  • Memory StandardSupports dual-channel DDR4 5066 (OC) MHz memory
  • Maximum Memory Supported128GB
  • PCI Slots1x PCIe x16 slot (From CPU) PCI_E1 (From CPU) Support up to
  • Supports 10th and 11th Gen Intel Core processors via LGA 1200 socket
  • Up to 128GB dual-channel DDR4 5066 (OC) MHz memory capacity
  • PCIe 4.0 x16 slot with 11th Gen CPU; PCIe 3.0 with 10th Gen CPU
  • Realtek 8125B 2.5Gbps LAN and built-in WiFi module with antenna included
  • Realtek AL897 7.1-Channel audio, 6x SATA III and 2x M.2 interfaces

Intel B560 micro-ATX board for LGA 1200 CPUs

This motherboard uses the Intel B560 chipset on a micro-ATX PCB. It accepts 10th and 11th Gen Intel Core processors plus Pentium Gold and Celeron chips in the LGA 1200 socket. Four DDR4 slots support up to 128 GB of system memory. The compact layout suits smaller cases while keeping core expansion options.

PCIe generation depends on the installed CPU

The single top x16 slot runs at PCIe 4.0 with an 11th Gen processor and falls back to PCIe 3.0 with a 10th Gen chip. Two additional x1 slots are wired to the chipset at PCIe 3.0 speeds. Six SATA III ports and two M.2 interfaces provide storage connectivity. This split means GPU bandwidth scales with the processor generation you choose.

2.5 Gbps LAN and USB 10 Gbps on the rear I/O

A Realtek 8125B controller delivers 2.5 Gbps Ethernet. The back panel includes two USB 3.2 Gen 2 Type-A ports at 10 Gbps plus two USB 3.2 Gen 1 Type-A ports at 5 Gbps. Internal headers add two more USB 3.2 Gen 1 ports. Realtek ALC897 codec handles 7.1-channel audio. The board ships with a Wi-Fi antenna, I/O shield, one SATA cable and a CMOS battery.

Highlights

  • Supports 10th and 11th Gen Intel Core processors via LGA 1200 socket
  • Up to 128GB dual-channel DDR4 5066 (OC) MHz memory capacity
  • PCIe 4.0 x16 slot with 11th Gen CPU; PCIe 3.0 with 10th Gen CPU
  • Realtek 8125B 2.5Gbps LAN and built-in WiFi module with antenna included
  • Realtek AL897 7.1-Channel audio, 6x SATA III and 2x M.2 interfaces

Specifications

BrandMSI
SeriesMSI B560M PRO-VDH WIFI
ModelMSI B560M PRO-VDH WIFI
CPU Socket TypeLGA 1200
CPU TypeSupports 10th Gen Intel Core™ Processors, 11th Gen Intel Core™ Processors, Pentium Gold and Celeron Processors
Processor socket LGA1200
ChipsetIntel B560
Memory StandardSupports dual-channel DDR4 5066 (OC) MHz memory
Maximum Memory Supported128GB
PCI Slots1x PCIe x16 slot (From CPU)
PCI_E1 (From CPU)
Support up to PCIe 4.0 for 11th Gen Intel CPU
Support up to PCIe 3.0 for 10th Gen Intel CPU
2x PCIe 3.0 x1 slots (From B560 chpiset)
SATA RAID2XM.2 interface, 6xSATA III interface
Audio ChipsetRealtek AL897 Codec
7.1-Channel High Definition Audio
LAN Chipset1x Realtek 8125B 2.5Gbps LAN controller
Onboard USBIntel B560 Chipset
2x USB 3.2 Gen 2 10Gbps Type-A ports on the back panel
4x USB 3.2 Gen 1 5Gbps ports (2 Type-A ports on the back panel, and 2 ports are available through the internal USB 3.2 Gen 1 5Gbps connector)
2x USB 2.0 Type-A ports on the back panel
USB Hubs GL850G
4x USB 2.0 ports are available through the internal USB 2.0 connectors

Questions about this item

Should I choose a B560 board that supports 5066 MHz DDR4 or one with a lower memory ceiling?

The 5066 MHz rating is the maximum overclocked speed this board can reach with 11th Gen Intel Core processors; 10th Gen CPUs will run memory at lower supported speeds.

What does the 2.5 Gbps LAN figure mean for everyday network use?

The Realtek 8125B controller provides up to 2.5 Gbps wired throughput, so file transfers and gaming traffic can exceed standard 1 Gbps limits when your router and cabling also support 2.5 Gbps.

How does the PCIe 4.0 x16 slot behave with different CPU generations?

With an 11th Gen Intel Core processor the primary x16 slot runs at PCIe 4.0; with a 10th Gen processor it falls back to PCIe 3.0, limiting graphics-card and high-speed add-in-card bandwidth accordingly.
