Green micro ATX board with silver heatsinks and black PCB

MSI

MSI B760M BOMBER DDR4 Intel Motherboard

SKU CH-FV9D-23YQA

Micro-ATX board for LGA 1700 CPUs with dual-channel DDR4 up to 4800 MHz and 64 GB capacity

  • CPU Socket TypeLGA 1700
  • CPU TypeSupports 12th Gen Intel Core and Pentium Gold/Celeron proces
  • ChipsetIntel B760
  • Memory StandardSupports dual-channel DDR4 4800 (OC)/4600 (OC)/4400 (OC)/426
  • Maximum Memory Supported64GB
  • PCI Slots1X PCI-E x16 slots (quantity) 1X PCI-E x1 slot (quantity) PC
  • Supports 12th Gen Intel Core processors via LGA 1700 socket
  • Dual-channel DDR4 memory up to 4800 MHz overclocked with 64 GB maximum capacity
  • PCIe 4.0 x16 slot from CPU plus PCIe 4.0 x1 slot from chipset for expansion
  • Realtek ALC897 codec delivers 7.1-channel high-definition audio
  • Realtek RTL8125B controller provides 2.5 Gbps LAN connectivity

B760M BOMBER DDR4 for LGA 1700 builds

This Micro ATX motherboard uses the Intel B760 chipset to support 12th Gen Intel Core and Pentium Gold or Celeron processors in the LGA 1700 socket. It targets system builders who want a compact board with dual-channel DDR4 memory support and a 2.5Gbps wired network connection.

Dual-channel DDR4 tops out at 4800 MHz overclocked

The board runs DDR4 at JEDEC speeds from 2133 up to 3200 MHz and offers a long list of overclocked steps reaching 4800 MHz. Maximum capacity is 64 GB across two slots. PCIe 4.0 operates on the single x16 slot from the CPU and on the x1 slot from the chipset.

64 GB memory ceiling decides fit

If the planned system needs more than 64 GB of RAM this board cannot accommodate it. For builds staying at or below that limit the B760M BOMBER DDR4 provides the core connectivity: four SATA III ports, two M.2 interfaces, 7.1-channel audio and a mix of rear and front USB 2.0 headers.

Highlights

  • Supports 12th Gen Intel Core processors via LGA 1700 socket
  • Dual-channel DDR4 memory up to 4800 MHz overclocked with 64 GB maximum capacity
  • PCIe 4.0 x16 slot from CPU plus PCIe 4.0 x1 slot from chipset for expansion
  • Realtek ALC897 codec delivers 7.1-channel high-definition audio
  • Realtek RTL8125B controller provides 2.5 Gbps LAN connectivity

Specifications

BrandMSI
SeriesMSI B760M BOMBER DDR4
ModelMSI B760M BOMBER DDR4
CPU Socket TypeLGA 1700
CPU TypeSupports 12th Gen Intel Core and Pentium Gold/Celeron processors for LGA 1700 Socket
LGA 1700
ChipsetIntel B760
Memory StandardSupports dual-channel DDR4 4800 (OC)/4600 (OC)/4400 (OC)/4266 (OC)/4200 (OC)/4000 (OC)/3800 (OC)/3733 (OC)/3600 (OC)/3466 (OC)/3400 (OC)/3333 (OC)/3200 (JEDEC)/2933 (JEDEC)/2666 (JEDEC)/2400 (JEDEC)/2133 (JEDEC) MHz memory
Maximum Memory Supported64GB
PCI Slots1X PCI-E x16 slots (quantity)
1X PCI-E x1 slot (quantity)
PCI_E1 Gen PCIe 4.0 supports up to (From CPU)
PCI_E2 Gen PCIe 4.0 supports up to (From Chipset)
SATA RAID2XM.2 interface, 4xSATA III interface
Audio ChipsetRealtek ALC897 Codec
7.1-Channel High Definition Audio
LAN ChipsetRealtek RTL8125B 2.5Gbps LAN
Onboard USB2X USB 2.0 (rear)
4X USB 2.0 (front)

Questions about this item

Should I choose the 64GB maximum memory option for this board?

The board supports up to 64GB of dual-channel DDR4, so pick that capacity if you need the full limit for heavy workloads.

What does the 2.5Gbps LAN figure mean once the board is installed?

The Realtek RTL8125B controller provides a 2.5Gbps wired network link when connected to a matching switch or router.

How does the PCIe 4.0 interface cap graphics-card bandwidth on this board?

The primary PCIe x16 slot runs at PCIe 4.0 from the CPU, setting the practical ceiling for GPU throughput.
