Green Micro ATX motherboard with silver heatsinks, black PCB, rear I/O shield, and bundled Wi-Fi antenna

MSI

MSI B760M BOMBER WIFI Intel motherboard

SKU CH-WXD8-7FXCR

Micro-ATX board for LGA 1700 CPUs with DDR5 up to 7800 MHz, 2.5 Gbps LAN and Wi-Fi

  • CPU Socket TypeLGA 1700
  • CPU TypeSupport Intel Core™ 14th/ 13th/ 12th Gen Processors, Intel P
  • ChipsetIntel B760
  • Memory StandardSupport 7800 + (OC)/7600 (OC)/7400 (OC)/7200 (OC)/7000 (OC)/
  • Maximum Memory Supported128GB
  • PCI Slots1X PCI-E x16 slots (quantity) 1X PCI-E x1 slot (quantity) PC
  • Supports Intel Core 12, 13, 14 Gen CPUs via LGA 1700 socket
  • DDR5 memory up to 7800 MHz overclocked with 128 GB maximum capacity
  • PCIe 4.0 x16 slot from CPU plus PCIe 4.0 x1 slot from chipset
  • Realtek ALC897 7.1-channel audio and RTL8125B 2.5 Gbps LAN
  • Rear USB includes four 5 Gbps Type-A ports and two USB 2.0 ports

LGA 1700 DDR5 micro-ATX board

The MSI B760M BOMBER WIFI is a micro-ATX motherboard built on the Intel B760 chipset for LGA 1700 processors. It supports Intel Core 12, 13 and 14 generation CPUs plus Pentium Gold and Celeron chips. Four DDR5 slots accept up to 128 GB of memory. The board targets builders who need a compact foundation for current Intel platforms.

Installation notes

Mounting follows the standard micro-ATX hole pattern and the rear I/O shield is supplied in the box. The primary PCIe x16 slot runs at Gen 4.0 from the CPU while the x1 slot and M.2 interfaces connect through the chipset. Builders should verify cooler clearance against the VRM heatsinks and ensure the front-panel USB headers match the case cables before committing to a build.

DDR5 and 2.5 GbE limits

DDR5 speeds range from JEDEC 4800 MT/s up to 7800 MT/s when overclocked, but actual stability depends on the memory kit and CPU memory controller. The Realtek 8125B LAN controller provides 2.5 Gbps wired throughput, which requires a matching switch or router port to exceed 1 Gbps. SATA III ports remain capped at 6 Gbps per drive regardless of the chipset generation.

Highlights

  • Supports Intel Core 12, 13, 14 Gen CPUs via LGA 1700 socket
  • DDR5 memory up to 7800 MHz overclocked with 128 GB maximum capacity
  • PCIe 4.0 x16 slot from CPU plus PCIe 4.0 x1 slot from chipset
  • Realtek ALC897 7.1-channel audio and RTL8125B 2.5 Gbps LAN
  • Rear USB includes four 5 Gbps Type-A ports and two USB 2.0 ports

Specifications

BrandMSI
SeriesMSI B760M BOMBER WIFI
ModelMSI B760M BOMBER WIFI
CPU Socket TypeLGA 1700
CPU TypeSupport Intel Core™ 14th/ 13th/ 12th Gen Processors, Intel Pentium Gold and Celeron Processors
LGA 1700
ChipsetIntel B760
Memory StandardSupport 7800 + (OC)/7600 (OC)/7400 (OC)/7200 (OC)/7000 (OC)/6800 (OC)/6600 (OC)/6400 (OC)/6200 (OC)/6000 (OC)/5800 (OC)/5600 (JEDEC)/5400 (JEDEC)/5200 (JEDEC)/5000 (JEDEC)/4800 (JEDEC) MHz
Maximum Memory Supported128GB
PCI Slots1X PCI-E x16 slots (quantity)
1X PCI-E x1 slot (quantity)
PCI_E1 Gen PCIe 4.0 supports up to (From CPU)
PCI_E2 Gen PCIe 4.0 supports up to (From Chipset)
SATA RAID2XM.2 interface, 4xSATA III interface
Audio ChipsetRealtek ALC897 Codec
7.1-Channel High Definition Audio
LAN ChipsetRealtek RTL8125B 2.5Gbps LAN
Onboard USB2X USB 2.0 (rear)
4X USB 2.0 (front)
4x USB 5Gbps Type A (Rear)
2x USB 5Gbps Type A (Front)

Questions about this item

How can I confirm the motherboard is working after installation?

Power on the system and verify the POST screen appears; check that the Realtek ALC897 audio device and RTL8125B 2.5Gbps LAN adapter are detected in the operating system.

What is included in the box and what must I source separately?

The package supplies the motherboard, a CMOS battery, one SATA cable and the rear I/O shield; a Wi-Fi antenna is also included. You will need to provide the CPU, DDR5 memory, storage drives, power supply and case.

Which memory speed should I select for this board?

The board supports DDR5 JEDEC speeds of 4800, 5000, 5200, 5400 and 5600 MHz out of the box, with overclocked options up to 7800 MHz depending on the memory kit and CPU used.
